C
Read this entire installation manual to ensure proper installation. When finished
with the installation, file this manual with the owner or maintenance department.
Compliance and conformity to local codes and ordinances is the responsibility of
the installer.
Separate parts from packaging and make sure all parts are accounted for before
Packing List
discarding any packaging material. If any parts are missing, do not begin
IS
T H
E
S ID
installation until you obtain the missing parts.
U P
Before installing components, all connection supply lines must be flushed and
free of foreign material such as pipe dope, chips, solder, etc. Bradley will not be
responsible for leaking valves due to the presence of foreign material, or
distorted stop gaskets where excessive pressure (above 30 lbs. of torque) has
been applied to the stop cap.
After flushing has been completed, make sure that all water supply lines have
been completely turned off before beginning installation. After installation has
been completed, turn the water supply lines back on and test the unit for leaks
and adequate water flow.
Product warranties may be found under "Product Information" on our web site at
www.bradleycorp.com.
215-1063 Rev. A; EN 05-719
© 2005 Bradley Corporation
Page 1 of 4
11/18/05
H
WARNING
Installation
SXWS9151
Chase-Mounted Handicap SX
Panel Shower
Table of Contents
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Cleaning Stainless Steel . . . . . . . . . . . . . . . . . . . .4
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: (262) 251-5817
http:\\www.bradleycorp.com
Advertisement
Table of Contents
Related Manuals for Bradley SXWS9151
Summary of Contents for Bradley SXWS9151
- Page 1 Before installing components, all connection supply lines must be flushed and free of foreign material such as pipe dope, chips, solder, etc. Bradley will not be responsible for leaking valves due to the presence of foreign material, or distorted stop gaskets where excessive pressure (above 30 lbs.
- Page 2 SXWS9151 Installation Dimensions 44" 41-3/4" (1118mm) (1060mm) 72" (1829mm) to Finished Floor WALL Recommended OPENING 9" 33-11/16" (229mm) 43-1/2" 13" (856mm) (1105mm) (330mm) to Finished to Finished Floor Floor 11/18/05 Bradley Corporation • 215-1063 Rev. A; EN 05-719...
- Page 3 NOTE: Secure the components to the wall from the chase side. NOTE: Connect the valve assembly and install the control button per instructions included with the components. LOCKWASHER BRACKET THREADED ROD INSTALL CONTROL BUTTON HERE Bradley Corporation • 215-1063 Rev. A; EN 05-719 11/18/05...
- Page 4 It is emphasized that all products should be used in strict accordance with package instructions. 11/18/05 Bradley Corporation • 215-1063 Rev. A; EN 05-719...
