Summary of Contents for Apevia X-Master

  • Page 2: Table Of Contents

    1. Motherboard installation... Install 3½” and 5¼” drives... 3. Install PCI components... 4. Connect case leads to motherboard... 5. Case fan setup... 6. Optional device installation... Add case feet... Complete the installation... USB/1394/Audio cable pin-assignments... CONTENTS...
  • Page 3: Motherboard Installation

    X-Master Finished Appearance NOTE: CPU and memory installation is not covered in this manual. Please refer to each components’ documentation for instructions. 1. Motherboard installation: 1.2 Remove left-side panel from case 1.1 Remove thumbscrews from the rear of the chassis.
  • Page 4 1.3 Install your motherboard’s I/O shield into the rear I/O slot. NOTE: Touch an unpainted metal section of the chassis to discharge static electricity before handling PC components. An anti-static wrist strap should also be worn to further minimize the possibility of damage. 1.5 Align motherboard over the standoff screws and secure to the case using the included mounting hardware.
  • Page 5: Install 3½" And 5¼" Drives

    Install 3½” and 5¼” drives 2.1 In order to install optical and hard- disk drives, you will 1st need to re- move the front panel. Get a solid grip on the vent at the bottom of the panel and pull firmly. 2.3 Align rails with drive bay and insert.
  • Page 6: Install Pci Components

    (i.e. x1, x8, x16, etc.) The X-Master can accommodate PCI cards up to 9” in length. *Please note the position of your PCI card’s external power connector (if any). Some cards require extra...
  • Page 7: Connect Case Leads To Motherboard

    4. Connect case leads to motherboard: 4.1 Locate the front panel leads and connect leads to motherboard headers. Your motherboard’s documentation should provide the schematics. Triangular markings on the leads indicate positive wires. (Remove right-side panel to better access wiring.) 4.3 Connect leads to motherboard headers.
  • Page 8: Optional Device Installation

    6. Optional device installation: 6.1 The X-Master gives you the option of installing additional devices. (up to 2 x 80 or 120mm fans, or 2 hard drives.) Mount device to area of your choice and screw to case. (If adding a case fan to the lower area, chassis should be laid on its side so as not to impede airflow.)
  • Page 9: Complete The Installation

    8. Complete the installation: 8.1 With all components properly installed, gently return side panels to their original positions and replace all screws. Congratulations! You have completed assembly of the X-Master chassis. 9. USB/1394/Audio cable pin assignments:...
