Iridium silver six-inch standard speed ptz dome
Hide thumbs Also See for PTZ505 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
the
Installation and Operation Manual
PTZ505 series Iridium Silver
Six-inch Standard Speed PTZ Dome
Optical
Zoom
Option D
18x
Option F
22x
Option H
22x
Option J
22x
Option P
30x
Option T
35x
Version 5
For updates to these instructions visit
excelPTZ
Total
Day/Night
Zoom
216x
YES
352x
YES
352x
YES
352x
YES
300x
YES
560x
YES
range
IR
Minimum
Sensitive
Lux
NO
1.0
NO
0.5
YES
0.5
YES
0.5
YES
0.001
YES
0.1
www.excelPTZ.com
TVL
Nite
Plus
480
NO
480
NO
480
NO
500
NO
480
YES
500
NO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTZ505 Series and is the answer not in the manual?

Questions and answers

Related Manuals for excelPTZ PTZ505 Series

Summary of Contents for excelPTZ PTZ505 Series

  • Page 1 Installation and Operation Manual PTZ505 series Iridium Silver Six-inch Standard Speed PTZ Dome Optical Total Day/Night Minimum Nite Zoom Zoom Sensitive Plus Option D 216x Option F 352x Option H 352x Option J 352x Option P 300x 0.001...

  • Page 2: Please Read The Following

    Please read this operation manual carefully before installing and using this unit !!!! Please read the following; 1. Please read the operation manual carefully before installing and operating the product. 2. The actual dome requires a 24v AC power supply. The rated input voltage of the camera is 12V!!!! This gets its power from the dome and does not require a separate PSU.

  • Page 3: Key Functions

    KEY FUNCTIONS The excelPTZ dome range – The PTZ505 range of domes are hi-tech CCTV products. They incorporate a high-clarity colour camera, panoramic speed-variable PAN/TILT, multifunctional decoder and on-board processor for logic handling. The domes are easy to connect, install, maintain and operate and have many features.

  • Page 4: Overview- Introduction To Fitting Ptz Equipment

    Getting the dome up and running! You MUST connect up the dome and your control equipment on a workbench or kitchen table before the actual site installation and CHECK YOU KNOW HOW TO INSTALL IT CORRECTLY!!!!!!!!!!!!!!!!!. By doing this you can set-up any DIP switches, adjust the camera, and learn about how it operates before taking it to site.
  • Page 5 The following diagram indicates the basic cable requirements for a PTZ system. Equipment Cable Needed Dome 1. Data signal CAT5 cable Keypad or You can also send the video signal back along a second pair in a CAT5 cable using baluns. Note you cannot send 24v AC power down CAT5.

  • Page 6: Rs485 Wiring Methods & Tips

    CAT 5 DOME CCT CAMERA 24V AC CAT5 Carries Video & LOCAL Control Data 240V --- Video & Power RG59+2 Video & Power BALUN DOME TRADITIONAL CAT5 Carrying Data CAMERA 240V JUNCTION BOX CO-AX RG59 Free Lead Supplied KEYPAD MONITOR Many installation companies can get the power and video signal correct, but struggle with the control of the dome using the keypad or DVR using the RS485 data.
  • Page 7 PLEASE NOTE - Using inferior cables, or installing the dome in an environment with strong electromagnetic interference, or connecting a lot of PTZ domes to the same cable carrying the RS485 signal will reduce the maximum transmitting distance. 3. RS485 Connection methods METHOD 1 –DAISY CHAIN CONNECTION.
  • Page 8 ..Main controller Daisy-Chain connection WITH SHORT SPURS for the RS485 PTZ control signal (one main radial with very short spurs to each dome off it, keeping the spurs to less than 10 meters) TIP - The connection of a 120 termination resistor: The termination resistor is ready fitted on the domes pcb, all you have to do set it is move the jumper from Pins 2 &3 to pins 1 &...
  • Page 9 If your STAR circuit is not too extensive with each spur in the region of 20-50 meters expect quite good reliable performance using this technique. If you experience any problems though, there is a RS485 distribution box available CODE PT750 to help overcome any problems. The Star circuit for wiring PTZ’...
  • Page 10 separate spurs, each spur can have up to 4 domes. This means that you could theoretically have up to 4 individual spurs of over 1000mtrs each to control up to 16 PTZ domes in total. Ideally you would put just one dome on each spur from the PTZ750 but up to 4 domes is generally acceptable.

  • Page 11: Setting Up The Dome Camera

    Setting up the Dome Camera 1. Connection of the System There are many ways to wire up a PTZ system. If you have read the introduction at the beginning of these instructions you should have got a good idea what your options are. Below is a general schematic diagram showing you some of these options.
  • Page 12 IDENTICALY so that if you have to swap the A & B lines over at the keyboard you know all domes are wired the same!! In the PTZ505 series adopts the following RS485 convention; ORANGE = RS485 + or A...
  • Page 13 PTZ730 keypad The PTZ730 and PTZ700 are two keypads that can be used with the PTZ505 series. On the rear of the keypads you will see the RS485 connections. Ensure they are connected correctly i.e the RS485 + A line and the RS485 – B line.

  • Page 14: Connecting The Video Out Of The Dome

    Connecting the video out of the dome. The dome has a short BNC lead attached to it, this is the lead that carries the video signal from the built-in camera. You need to extend this lead to the “ VIDEO-IN” of the DVR or monitor. Use a good quality RG59 coax cable or similar to do this.
  • Page 15 24V AC INPUT 24V AC RS485 RS485 INPUT - ‘ B’ + ‘ A’ YELLOW ORANGE RS485 RS485 - “ B” + “ A” RS485 INPUT ON RS485 INPUT ON DVR...

  • Page 16: Setting Up A Unique Address In A Dome

    If you’ re using more than one dome on a site Each dome has a unique “ address” so that if you are using more than one on a site the keyboard “ talks” to the right dome when you want it to PTZ. If you only have the one dome on the site then the default “...
  • Page 17 Dome ID-CODE Status Address DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6 DIP-7 DIP-8 DIP-9 DIP-10 … … … … … … … … … … … 1023 Table 1 2. Setup of the Protocol and the Default Baud Rate. As shown in Table 2, SW2 is used to set the protocol of communication and the baud rate used by the dome camera.
  • Page 18 Table 2 Some protocols and the states of the coding switches of normal baud rates of these protocols are shown as follows: Setup of the Baud Rate of Communication. As shown in Figure 2, SW2 is used to set the protocol of communication and the baud rate used by the dome camera.

  • Page 19: Using The Ptz730 Keypad With The Excelptz Series

    Using the PTZ730 keypad with the excelPTZ series NOTE 1: For more detailed instructions in setting up the keypad or using one of our other keypads, please refer to the instruction manual supplied with the product. NOTE 2: The PTZ730 keypad requires you to press the function key first followed by the value e.g <CAM>...

  • Page 20: Presets And Other Functions

    PRESETS and other functions. The dome has up to 64 presets that once programmed will stay in the domes non-volatile memory so they will be retained even after a power cut. What is a preset? A preset is a particular area or object that the dome was looking at and has been stored into its memory so when the preset is “...

  • Page 21: Presets -How To Set Up A Preset

    If you wish to use the auto scan function YOU MUST USE preset 52 as the starting point of the scan and preset 53 as the ending point of the scan. Note that when using the Pelco-D, Pelco-P or Santachi protocols, an alternative preset number 64 may be more suitable in some keypads.

  • Page 22: Deleting A Preset

    Tours – How to set them up and use them A tour is simply a collection of preset camera locations that are run in sequence with the dome stopping at each location for a brief period then moving on to the next preset. For example, you could use a tour so that an outside dome camera points at a gate, then at a side doorway then zooms out to get an overall shot of a car park finally zooming in on a delivery bay before repeating the whole cycle again.

  • Page 23: Controlling One Camera Then Another

    On Screen Graphics (OSD) – changing the modules settings The zoom module within the dome has a built in camera. You can adjust some of its parameters by entering its On-Screen-Graphics display. (OSD) To bring up the camera menu press CALL 57 Enter. The camera’ s OSD is then displayed on the screen.

  • Page 24: The Installation Of The System

    The Installation of the System 1. Type of Installation a) Wall Installation 103. 4 Figure 1 b) In-Ceiling Installation Figure 2 2. Installation Steps (taking wall installation as example) a) Preparation before installation --- dome setting Turning the dome cover anticlockwise (Figure 3) and take out the inner black cover (Figure 4).
  • Page 25 Figure 3 Figure 4 Install the inner black cover (Figure 5). Install the dome cover (Figure 6). Figure 5 Figure 6 b) Installation of the bracket Make four M8 holes on the wall, and put the four M8 bolts into the holes as Figure 7. Make a hole at the center of the four holes to connect the cable of the bracket as Figure 7.
  • Page 26 Aim the “ ” of the bracket to the “ ” of the dome as Figure 9. iii. Push the dome up and turning it anticlockwise as Figure 10. Figure 9 Figure 10 Lock the housing as Figure 11. Tighten M4×18 screws as Figure 12. Figure 11 Figure 12 Connect the control cable as Figure 15.

  • Page 27: Appendix A: General Information

    Appendix A: General Information The Cleaning of Clear Dome Cover To obtain constant clear images, the user should clean the down cover periodically. Be very careful when cleaning. Hold the down cover ring only to avoid touching the acrylic dome cover.
  • Page 28 www.kovert.com OPTION F Doc PTZ054.doc PTZ054 22x PTZ Module rev : 1.0 The new 22x PTZ module for the Pan, Tilt and Zoom ranges of domes. Camera Instruction Manual. 1. OSD Navigation. The way to navigate to the menu options is dependant on the model of PTZ that the module has been installed in.

  • Page 29: Zoom Start

    www.kovert.com OPTION F Doc PTZ054.doc PTZ054 22x PTZ Module rev : 1.0 2. The module Menu Structure. Once in the menu system of the camera module the following options are available. MENU OF CAM 1. BACKLIGHT (OFF,ON) 2. SLOW SHUTTER (OFF or 2 to 128) 3.

  • Page 30: Focus Mode

    www.kovert.com OPTION F Doc PTZ054.doc PTZ054 22x PTZ Module rev : 1.0 ZOOM STOP This option is the setting of the maximum zoom that the module will allow x1 to x220. For example if this is set to x22 the operator will only be able to zoom to the limit of the optical zoom and not the digital zoom up to x300.
  • Page 34 www.kovert.com OPTION H Doc PTZ051.doc PTZ051 22x IR PTZ Module rev : 1.0 The 22x IR PTZ module for the Pan, Tilt and Zoom ranges of domes. Camera Instruction Manual. 1. OSD Navigation. The way to navigate to the menu options is dependant on the model of PTZ that the module has been installed in.
  • Page 35 www.kovert.com OPTION H Doc PTZ051.doc PTZ051 22x IR PTZ Module rev : 1.0 2. The module Menu Structure. Once in the menu system of the camera module the following submenus are available. 2.1 The FOCUS Menu. This menu is for configuring the following module settings; FOCUS SET FOCUS MODE (AUTO,PUSH AUTO,MANUAL) FOCUS DIST (1CM,10CM,50CM,1M,3M,5M,10M)
  • Page 36 www.kovert.com OPTION H Doc PTZ051.doc PTZ051 22x IR PTZ Module rev : 1.0 2.2 AWB SET (automatic white balance). This menu is for configuring the following module settings; WB MODE (AUTO,PUSH AUTO,MANUAL,OUTDOOR,INDOOR,HUE CONTROL) AWB SET HUE CONTROL (0 TO 99 WHEN WB MODE IS SET TO HUE CONTROL) RED GAIN (0 TO 255 WHEN WB MODE IS SET TO MANUAL) BLUE GAIN (0 TO 255 WHEN WB MODE IS SET TO MANUAL) PUSH AUTO (OFF OR ON WHEN WB MODE IS SET TO PUSH AUTO)
  • Page 37 www.kovert.com OPTION H Doc PTZ051.doc PTZ051 22x IR PTZ Module rev : 1.0 AE MODE This option is used to select the exposure mode to be used by the camera. The options are AUTO, MANUAL, AGC MAN and IRIS MAN. When the AUTO mode is selected then the module will automatically adjust the iris and automatic gain control (AGC).
  • Page 38 www.kovert.com OPTION H Doc PTZ051.doc PTZ051 22x IR PTZ Module rev : 1.0 USER TITLE A ten digit alpha-numeric label which will appear on the OSD of the camera in the bottom left of the screen. SHARPNESS This adjusts the sharpness of the image from 0 (low) to 15 (high).
  • Page 39 www.kovert.com OPTION H Doc PTZ051.doc PTZ051 22x IR PTZ Module rev : 1.0 D & N MODE This option is used to set the module to either switch automatically between day and night mode depending on the level of light available. (AUTO) sets colour during the day and switches to black and white at night.
  • Page 40 www.kovert.com OPTION J Doc PTZ053.doc PTZ053 22x IR HR PTZ Module rev : 1.0 The 22x IR High Resolution PTZ module for the Pan, Tilt and Zoom ranges of domes. Camera Instruction Manual. 1. OSD Navigation. The way to navigate to the menu options is dependant on the model of PTZ that the module has been installed in.
  • Page 41 www.kovert.com OPTION J Doc PTZ053.doc PTZ053 22x IR HR PTZ Module rev : 1.0 2. The module Menu Structure. Once in the menu system of the camera module the following submenus are available. 2.1 The FOCUS Menu. This menu is for configuring the following module settings; FOCUS MODE (AUTO,PUSH AUTO,MANUAL) FOCUS SET FOCUS DIST (1CM,10CM,50CM,1M,1.5M,3M,5M,10M)
  • Page 42 www.kovert.com OPTION J Doc PTZ053.doc PTZ053 22x IR HR PTZ Module rev : 1.0 2.2 AWB SET (automatic white balance). This menu is for configuring the following module settings; WB MODE (AUTO,PUSH AUTO,MANUAL,OUTDOOR,INDOOR,HUE CONTROL) AWB SET HUE CONTROL (0 TO 99 WHEN WB MODE IS SET TO HUE CONTROL) RED GAIN (0 TO 255 WHEN WB MODE IS SET TO MANUAL) BLUE GAIN (0 TO 255 WHEN WB MODE IS SET TO MANUAL) PUSH AUTO (OFF OR ON WHEN WB MODE IS SET TO PUSH AUTO)
  • Page 43 www.kovert.com OPTION J Doc PTZ053.doc PTZ053 22x IR HR PTZ Module rev : 1.0 AE MODE This option is used to select the exposure mode to be used by the camera. The options are AUTO, MANUAL, AGC MAN and IRIS MAN. When the AUTO mode is selected then the module will automatically adjust the iris and automatic gain control (AGC).
  • Page 44 www.kovert.com OPTION J Doc PTZ053.doc PTZ053 22x IR HR PTZ Module rev : 1.0 USER TITLE A ten digit alpha-numeric label which will appear on the OSD of the camera in the bottom left of the screen. SHARPNESS This adjusts the sharpness of the image from 0 (low) to 15 (high).
  • Page 45 www.kovert.com OPTION J Doc PTZ053.doc PTZ053 22x IR HR PTZ Module rev : 1.0 2.6 DAY/NIGHT (day and night). This menu is for configuring the following module settings; DAY/NIGHT D/N MODE (AE,EXT,NIGHT,DAY,SENSOR) CDS LEVEL (0 TO 255 WHEN D/N MODE IS SET TO SENSOR) FILTER DELAY (1 TO 15) INITIAL SET (OFF OR ON) D &...
  • Page 46 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 The new 27x NitePlus PTZ module for the Pan, Tilt and Zoom ranges of domes. Camera Instruction Manual. Superior Auto Focus Superior Backlight Compensation 1. OSD Navigation. The way to navigate to the menu options is dependant on the model of PTZ that the module has been installed in.
  • Page 47 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2. The module Menu Structure. Once in the menu system of the camera module the following submenus are available. 2.1 The GENERAL Menu. This menu is for configuring the following module settings; GENERAL CAMERA ID (NUMERIC ID 0 TO 255) LANGUAGE (ENGLISH OR KOREAN)
  • Page 48 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2.2 The FOCUS menu. This menu is for configuring the following module settings; FOCUS FOCUS MODE (AUTO OR MANUAL) PUSH AUTO (OFF OR ON WHEN IN FOCUS MODE AUTO) FOCAL DIST (4M,2M,130CM,80CM,50CM,10CM,1CM) ZOOM START (x1 TO x27) ZOOM END (x1 TO x270)
  • Page 49 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2.3 AWB (automatic white balance). This menu is for configuring the following module settings; A W B WB MODE (AUTO,MANUAL,INDOOR,OUTDOOR,PUSH AUTO) RED CONT (0 TO 255) BLUE CONT (0 TO 255) PUSH AUTO (NOT USED) INITIAL (OFF OR ON) WB MODE...
  • Page 50 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2.4 A E (automatic exposure). This menu is for configuring the following module settings; AE MODE (AUTO) BRIGHTNESS (0 TO 48) FLICKERLESS (OFF OR ON) SHUTTER SPD (NOT USED) IRIS ADJUST (NOT USED) AGC ADJUST (NOT USED) AGC MAX SET (NOT USED)
  • Page 51 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2.5 D & N (day and night). This menu is for configuring the following module settings; D & N MODE (AUTO,DAY,NIGHT) D & N D & N DELAY (1 SEC TO 10 SEC) INITIAL (OFF OR ON) D &...

  • Page 52: Detect Mode

    www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2.7 MOTION (motion detection). This menu is for configuring the following module settings; MOTION DETECT MODE (OFF OR ON) DETECT AREA (CENTER,WHOLE,UPPER,OUT) SENSITIVITY (2 TO 15) INITIAL (OFF OR ON) DETECT MODE This option turns the motion detection system ON or OFF.

  • Page 53: Motion Det

    www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 2.8 DISPLAY. This menu is for configuring the following module settings; DISPLAY WHOLE OSD (OFF OR ON) FUNC OSD (OFF OR ON) MOTION DET (OFF OR ON) CAMERA ID (OFF OR ON) ZOOM MAG (OFF OR ON) ZOOM LABEL (OFF OR ON)
  • Page 54 www.kovert.com OPTION K Doc PTZ059.doc PTZ059 27x NitePlus PTZ Module rev : 1.0 Technical Specifications Signal System Scanning System 2:1 Interface Scanning Frequency (H) 15.625kHz Scanning Frequency (V) 50Hz Image Sensor ¼” Sony Super HAD CCD Sync. System Internal Total Pixels 795(H) x 596(V) 470K Effective Pixels 752(H) x 582(V) 440K...
  • Page 63 www.kovert.com OPTION T Doc PTZ038.doc PTZ038 35x PTZ Module rev : 1.0 The 35x PTZ module for the Pan, Tilt and Zoom ranges of domes. Camera Instruction Manual. 1. OSD Navigation. The way to navigate to the menu options is dependant on the model of PTZ that the module has been installed in.
  • Page 64 www.kovert.com OPTION T Doc PTZ038.doc PTZ038 35x PTZ Module rev : 1.0 2. The module Menu Structure. Once in the menu system of the camera module the following submenus are available. 2.1 The FOCUS Menu. This menu is for configuring the following module settings; FOCUS MODE (AUTO,PUSH AUTO,MANUAL) FOCUS SET FOCUS DIST (1CM,10CM,50CM,1M,1.5M,3M,5M,10M)
  • Page 65 www.kovert.com OPTION T Doc PTZ038.doc PTZ038 35x PTZ Module rev : 1.0 2.2 AWB SET (automatic white balance). This menu is for configuring the following module settings; WB MODE (AUTO,PUSH AUTO,MANUAL,OUTDOOR,INDOOR,HUE CONTROL) AWB SET HUE CONTROL (0 TO 99 WHEN WB MODE IS SET TO HUE CONTROL) RED GAIN (0 TO 255 WHEN WB MODE IS SET TO MANUAL) BLUE GAIN (0 TO 255 WHEN WB MODE IS SET TO MANUAL) PUSH AUTO (OFF OR ON WHEN WB MODE IS SET TO PUSH AUTO)
  • Page 66 www.kovert.com OPTION T Doc PTZ038.doc PTZ038 35x PTZ Module rev : 1.0 AE MODE This option is used to select the exposure mode to be used by the camera. The options are AUTO, MANUAL, AGC MAN and IRIS MAN. When the AUTO mode is selected the module will automatically adjust the iris and automatic gain control (AGC).
  • Page 67 www.kovert.com OPTION T Doc PTZ038.doc PTZ038 35x PTZ Module rev : 1.0 USER TITLE A ten digit alpha-numeric label which will appear on the OSD of the camera in the bottom left of the screen. SHARPNESS This adjusts the sharpness of the image from 0 (low) to 15 (high).
  • Page 68 www.kovert.com OPTION T Doc PTZ038.doc PTZ038 35x PTZ Module rev : 1.0 2.6 DAY/NIGHT (day and night). This menu is for configuring the following module settings; D/N MODE (AE,EXT,NIGHT,DAY,SENSOR) DAY/NIGHT CDS LEVEL (0 TO 255 WHEN D/N MODE IS SET TO SENSOR) FILTER DELAY (1 TO 15) INITIAL SET (OFF OR ON) D &...

This manual is also suitable for:
