  • Page 1 Version 1.2, July 2015 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the CP-2116E. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the device.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference.
  • Page 5 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
  • Page 6 CP-2116E Remote Control Panel This page left intentionally blank Page - ii Revision 1.2...

  • Page 7: Table Of Contents

    4.4.2. LCD Test ........................13 4.4.3. Touchscreen Test ..................... 13 4.4.4. GPIO Test ........................ 13 4.5. CHECKING THE STATUS OF THE CP-2116E ..............14 5. SYSTEM CONFIGURATION ..................... 15 5.1. UPGRADING THE CP-2116E PANEL ................. 15 5.1.1. Requirements ......................15 5.1.2.
  • Page 8 5.5.2.1. Visual Settings .................... 40 5.5.3. Import/Export Page ....................41 5.6. UPGRADE MENU ........................ 42 6. ADDING AN EVERTZ SYSTEM TO CONTROL ............... 43 6.1. CP-2116E CONTROL OF MVP SYSTEM ................43 6.2. ADDING SNMP SERVICES ....................45 6.3. ADDING AN EQX SERVER ....................46 6.4.
  • Page 9 Tektronix WFM ......................5 Figure 2-4: CP-2116E ........................5 Figure 2-5: One CP-2116E-H Mounted in a 2RU CPH-RMB with Supplied Blank Plate....6 Figure 2-6: Two CP-2116E-H Mounted in a 2RU CPH-RMB ............6 Figure 2-7: Mounting Installation for the CP-2116-DBK ..............6 Figure 2-8: Mounting Installation for the CP-2116-TEK ..............
  • Page 10 CP-2116E Remote Control Panel Figure 5-29: Opening config.cf Dialog Box .................. 38 Figure 5-30: Logs Tab ......................... 39 Figure 5-31: Opening logs.lf Dialog Box ..................39 Figure 5-32: Preferences Page ....................40 Figure 5-33: Import/Export Page ....................41 Figure 5-34: Install Firmware Page ....................42 Figure 6-1: Systems Page ......................

  • Page 11: Overview

    The CP-2116E-H is offered in a full width panel as a lower cost option to other Evertz advanced system control panels, or in a half width chassis which offers a mounting option for a standard owner supplied waveform monitor.
  • Page 12 CP-2116E Remote Control Panel This page left intentionally blank Page - 2 Revision 1.2...

  • Page 13: Installation

    CP-2116E Remote Control Panel INSTALLATION 2.1. REAR PANEL Figure 2-1 shows the rear view of the CP-2116E control panel. The following is a list of the ports and controls on the rear panel: SERIAL B JOYSTICK/GPIO SERIAL A ETHERNET A...

  • Page 14: Front Control Panel

    Figure 2-2: CP-2116E Front Control Panel Please note that the labels in Figure 2-2 will NOT be displayed on the front panel of your CP-2116E device. The labels listed above are for reference purposes only when describing the panel controls in the following sections of the manual.

  • Page 15: Power Connections

    2.4. MOUNTING The CP-2116E is equipped with rack mounting angles and fits into a standard 19 inch by 3.5 inch by 1.2 inch (483 mm x 89 mm x 32mm) rack space. Figure 2-3 to Figure 2-6 illustrates the various mounting options. Please refer to section 3.1.3 for information on physical specifications.

  • Page 16: Figure 2-5: One Cp-2116E-H Mounted In A 2Ru Cph-Rmb With Supplied Blank Plate

    Figure 2-6: Two CP-2116E-H Mounted in a 2RU CPH-RMB Cooling is achieved by passive air flow across and through the panel chassis. The following diagrams illustrate mounting installation for the CP-2116E-DBK & the CP-2116E-TEK. Figure 2-7: Mounting Installation for the CP-2116-DBK Page - 6 Revision 1.2...

  • Page 17: Figure 2-8: Mounting Installation For The Cp-2116-Tek

    CP-2116E Remote Control Panel Figure 2-8: Mounting Installation for the CP-2116-TEK Page - 7 Revision 1.2...
  • Page 18 CP-2116E Remote Control Panel This page left intentionally blank Page - 8 Revision 1.2...

  • Page 19: Technical Description

    CP-2116E Remote Control Panel TECHNICAL DESCRIPTION 3.1. SPECIFICATIONS 3.1.1. Control Ethernet: 10/100 base T.RJ45 connector Joystick: Parallel contact closure TTL levels, D9 male 3.1.2. Electrical Voltage: Autoranging 100V - 240V AC, 50/60Hz Power: 20 Watts Fuse Rating: 250V, 4A, time delay 3.1.3.
  • Page 20 CP-2116E Remote Control Panel This page left intentionally blank Page - 10 Revision 1.2...

  • Page 21: Front Panel Control

    FRONT PANEL CONTROL To enter the setup menu of the CP-2116E press and hold the first and last rotary encoders (S1 and S4) on the far left side of the panel for approximately 6 seconds. You will then be presented with several menus which allow testing and configuration of the panel.

  • Page 22: Configuring The Network Settings

    OR select the Apply soft-key (L12) button. 4. Bonding may be chosen if you wish the CP-2116E to use the same IP address on BOTH Ethernet ports. This setting is ONLY to be used if ONE Ethernet cable is plugged into a single network OR if two completely isolated networks are in use.

  • Page 23: Testing The Panel's Functionality

    CP-2116E Remote Control Panel 4.4. TESTING THE PANEL’S FUNCTIONALITY The Test screen enables the user to test the functionality of the LCD touch-screen and LCD buttons. Once the Test screen is displayed there are four main test options: Key Test, LCD Test, Touchscreen Test, and GPIO Test.

  • Page 24: Checking The Status Of The Cp-2116E

    Monitors the time elapse from the initial boot up sequence in hours:minutes:seconds format. • Workload: Monitors the workload. The Reboot option enables the user to restart the system. To shut down the CP-2116E, select the Power Off option. Page - 14 Revision 1.2...

  • Page 25: System Configuration

    “other languages…” option under the download link. 5.1.2. Getting Started 1. Set the IP address of the CP-2116E by holding down both rotary encoders (S1 and S4) on the far left of the panel for 6 seconds. c. Select the “Network” page.

  • Page 26: Upgrading Firmware On The Cp-2116E

    5.1.3. Upgrading Firmware on the CP-2116E 1. To upgrade firmware using the web interface, open a Firefox web browser and enter the IP address of the CP-2116E, then press the <enter> key. The CP2116e web interface will appear, as shown in Figure 5-1.

  • Page 27: Systems Menu

    CP-2116E Remote Control Panel 5.2. SYSTEMS MENU The Systems menu enables the user to upload product jar files, create services and templates, and add systems. Figure 5-3 illustrates the Systems drop down menu. Figure 5-3: Systems Drop Down Menu 5.2.1. Products Page The Products page, as illustrated in Figure 5-4, enables the user to upload product jar files to the control panel.

  • Page 28: Products Uploaded

    The Service Templates page enables the user to create a template, which can be reused for SNMP Services on the CP-2116E control panel. This template defines and assigns functions for specific SNMP devices for control. The Service Templates page also allows the user to edit existing templates.

  • Page 29: Figure 5-6: Service Template List

    CP-2116E Remote Control Panel The user can add, copy, or remove a template using the Service Templates buttons listed in Table 5-1: Button Image Description The New Template button enables the user to add and create a new New Template template.

  • Page 30: Service Template Controls

    CP-2116E Remote Control Panel Figure 5-7: Customizing a Template 5.2.2.1. Service Template Controls To modify the template, use the Service Templates controls as listed below: • Name: To assign a name to the template, enter a unique name into the Name field.
  • Page 31 CP-2116E Remote Control Panel • Delete Selected Parameters/Groups: Select the Delete Selected Parameters/Groups to delete a parameter/group. • Add a Group: To add a group to the list, select the Add a Group button. • Hide Tree View: Selecting the Hide Tree View button will hide the parameter tree view.

  • Page 32: Service Template Parameter Tree

    CP-2116E Remote Control Panel 5.2.2.2. Service Template Parameter Tree The Service Template Parameter Tree is used to select parameters and add them to the template. The user can navigate through the parameter tree by pressing the plus (+) and minus (-) buttons to expand or collapse the parameter items.

  • Page 33: Template Properties

    CP-2116E Remote Control Panel 5.2.2.3. Template Properties The user can adjust the template properties by entering the appropriate information into the fields below: • #: Double-clicking a number in this column will highlight the corresponding parameter in the Service Template Parameter Tree.

  • Page 34: Service Template Controls

    CP-2116E Remote Control Panel 2. Assign a new name to the template by entering a name into the Name field. 3. Assign a name for the designated LCD button using the Button Text field. 4. Select a product using the Product drop-down menu. Once the desired product is selected, the parameter tree will reflect the available parameter items for the selected product.

  • Page 35: Services Page

    The Services page enables the user to create a service or edit an existing service, which can be loaded onto the CP-2116E control panel. The user can define the frame, pin point a card in a particular slot, and assign an input using the Services page.

  • Page 36: Service Controls

    CP-2116E Remote Control Panel Figure 5-12: Customizing a Service 5.2.3.1. Service Controls To name and save the service, use the Service controls as listed below: • Name: To assign a name to the service, enter a unique name into the Name field.

  • Page 37: Add A Service Template To The Service List

    5.2.4. Systems Page The Systems page enables the user to view the devices that are currently available on the CP-2116E as well as add new devices. The user can also edit and/or change details, tags, and services for specific devices.

  • Page 38: Device Properties

    CP-2116E Remote Control Panel Figure 5-14: New System Window 5.2.4.1. Device Properties The user can adjust each device’s properties by entering the appropriate information into the fields below:  If the user double clicks the System, Type, Details, and/or Tags field, an Update System window will open as illustrated in Figure 5-15.

  • Page 39: Discovery Menu

    5.3. DISCOVERY MENU The Discovery menu, as illustrated in Figure 5-16 enables the user to set the appropriate discovery settings for the panel. The user can also configure the CP-2116E for thumbnails, and set the VistaLINK Alarm Server IP address.

  • Page 40: Settings Page

    CP-2116E Remote Control Panel 5.3.1. Settings Page The Settings page enables the user to lock the Discovery system and set the refresh rate of the device. Figure 5-17: Settings Page Lock Discovery: This parameter allows the user to enable or disable the Lock Discovery. If set to On, the Discovery system will not be permitted to add new hardware devices to the list of devices found.

  • Page 41: Ranged Discovery Page

    CP-2116E Remote Control Panel 5.3.2. Ranged Discovery Page This page enables the user to set the network range that the panel is to do its discovery in. Figure 5-18: Ranged Discovery Page Range: Enter the network range that the panel is to do its discovery in. Once the range is entered, select the Discover button.

  • Page 42: Vistalink Alarm Server

    CP-2116E Remote Control Panel To import a device label, follow the instructions outlined below: 1. Select the Browse button and navigate to the appropriate .csv file and then select the Open button. 2. Once the file name is displayed in the field next to the Browse button, select the Install button.

  • Page 43: Source Proc Menu

    An Alias name for the router source (which will be used if the device name and port are not provided). d. A Service created and saved on the CP-2116E panel. 2. Select the plus sign to create a new mapping.

  • Page 44: Destination Proc Page

    CP-2116E Remote Control Panel 3. Enter the PRECISE “short name” of the router device to map to in the Device Name field. 4. Enter the port number (the numerical input) to map to in the Port field. 5. Enter an Alias name for the router source. Please note that this parameter is optional. An Alias will be used if a device name and port are not provided.

  • Page 45: Macros Page

    CP-2116E Remote Control Panel 5.4.3. Macros Page The Macros page, as illustrated in Figure 5-24, enables the user to map a Macro to an SNMP Service. This will automatically fire the Macro on the VistaLINK Alarm Server when the Service is loaded.

  • Page 46: Help Menu

    CP-2116E Remote Control Panel 5.5. HELP MENU The Help menu enables the user to view panel and products information, retrieve logs, change preference settings, and import/export configurations. Figure 5-25: Help Menu 5.5.1. Help Page Selecting the Help menu enables the user to view the current panel version, product support, and retrieve configuration and logs.

  • Page 47: Product Support

    CP-2116E Remote Control Panel 5.5.1.2. Product Support The Product Support option provides a list of current product versions. Figure 5-27: Product Support Tab Clicking the Product Versions text will reveal a list of currently supported products and their version numbers.

  • Page 48: Configuration

    CP-2116E Remote Control Panel 5.5.1.3. Configuration The Configuration tab, as illustrated in Figure 5-28, enables the user to export the panel’s configuration settings. Figure 5-28: Configuration Tab Select the Export Configuration text and an Opening config.cf dialog box will be appear which will prompt the user to open or save the configuration file.

  • Page 49: Logs Tab

    CP-2116E Remote Control Panel 5.5.1.4. Logs Tab The Logs tab, as illustrated in Figure 5-30, enables the user to retrieve configuration logs. Figure 5-30: Logs Tab Select the Download Logs text and an Opening logs.lf dialog box will appear which will prompt the user to open or save the log file.

  • Page 50: Preferences Page

    CP-2116E Remote Control Panel 5.5.2. Preferences Page The user can select the Preferences option from the Help menu drop down menu. The Preferences page enables the user to change the visual settings of the panel. Figure 5-32: Preferences Page 5.5.2.1.

  • Page 51: Import/Export Page

    CP-2116E Remote Control Panel 5.5.3. Import/Export Page The user can select the Import/Export option from the Help menu drop down. This page, as illustrated in Figure 5-33, enables the user to import and export an advanced panel configuration. Figure 5-33: Import/Export Page To import a configuration, follow the instructions outlined below: 3.

  • Page 52: Upgrade Menu

    Remote Control Panel 5.6. UPGRADE MENU The Upgrade menu enables the user to upgrade the firmware on the CP-2116E panel. Select the Upgrade menu and the Install Firmware page will open as illustrated in Figure 5-34. Figure 5-34: Install Firmware Page For instructions on how to upgrade the panel’s firmware, please refer to section 5.1.3.

  • Page 53: Adding An Evertz System To Control

    6.1. CP-2116E CONTROL OF MVP SYSTEM Controlling an MVP system from the CP-2116E panel requires a few “one time” steps (as well as a normal procedure) to be completed on the MVP system prior to working with the CP-2116E: 1. Set up the MVP system to allow control from the CP-2116E. (This step should only be performed once upon initial setup): a.

  • Page 54: Figure 6-2: Create A Mvp System

    Select one of the layouts and then select the load button. d. The user can also change sources on the CP-2116E. This will allow you to pick a source that is already located on the MVP somewhere else, without making routes. The user can select which audio to route to the monitor outputs.

  • Page 55: Adding Snmp Services

    CP-2116E Remote Control Panel 6.2. ADDING SNMP SERVICES This section will guide the user through the set up of SNMP services. SNMP services are parameters from one or several pieces of terminal equipment that you wish an operator to control from the CP- 2116E panel.

  • Page 56: Adding An Eqx Server

    ADDING AN EQX SERVER All router management of the CP-2116E for use in an EQX Server based system is done through the EQX Server WCT (web config tool). Please see the EQX Server manual for details on working with the CP-2116E panel in that respect.

  • Page 57: Creating Source-Service Mapping

    In this way, SNMP Services (and therefore Terminal gear parameters) can be accessed from within the EQX Server portion of the CP-2116E and users do not have to filter through long lists looking for the correct Service name. For more information on Mapping, please refer to section 5.4.
  • Page 58 CP-2116E Remote Control Panel This page left intentionally blank Page - 48 Revision 1.2...

  • Page 59: Navigating The Control Panel

    NAVIGATING THE CONTROL PANEL Figure 7-1: Front Panel Display The default router control view of the CP-2116E features a single touch LCD screen with a maximum of four destinations displaying the following information: Destination Name, Current Source Name, Next Source Name, Profile Selected Name, Destination Page, and State of the Destination (Lock/Protected/etc).

  • Page 60: Figure 7-3: Src Keypad Display

    The Alpha-Numeric button when pressed will allow the user to type the name of the required source in the screen. As the user types the CP-2116E will automatically filter the source list to display any source that matches the characters typed. If a character is typed incorrectly the DEL button can be used to delete the characters.

  • Page 61: Destination (Dst) Button

    CP-2116E Remote Control Panel 7.2. DESTINATION (DST) BUTTON Figure 7-4: DST Layout DST button when pushed will display a list of available destinations in the display screen. The left shaft encoder is used to navigate through the destination list. When the required destination is highlighted, the Select button is used to confirm the choice and return the user to Quad Destination view.

  • Page 62: Figure 7-5: Dst Keypad Display

    The Alpha-Numeric button when pressed will allow the user to type the name of the required destination in the screen. As the user types the CP-2116E will automatically filter the destination list to display any destination that matches the characters typed. If a character is typed incorrectly the DEL button can be used to delete the characters.

  • Page 63: Up & Down Arrows

    CP-2116E Remote Control Panel 7.3. UP & DOWN ARROWS Figure 7-6: Up & Down Arrows Display The Destination navigation buttons allow the user to scroll Up or Down through the pages of destinations. The Current Page and Total Number of Pages is displayed in the bottom right corner of each LCD screen.

  • Page 64: Level Button

    CP-2116E Remote Control Panel 7.5. LEVEL BUTTON Figure 7-8: Level Button Display The Level button when pushed will allow the user to enable or display specific levels for a destination. This could be an audio level or video level thereby allowing the user to accomplish a Breakaway route.

  • Page 65: Figure 7-10: Select The All/None Button

    CP-2116E Remote Control Panel Figure 7-10: Select the ALL/NONE Button The Select ALL or None button will toggle the level state of the levels for the selected destination. If levels have been disabled the associated level buttons will turn Red. The screen will display a breakaway icon for the destination.

  • Page 66: Selecting The "More" Button

    CP-2116E Remote Control Panel The Breakaway button when selected will each level individually on the LCD screen for the selected destination. The user can then select a specific level and route a source to that level by pressing the SRC button. The Up arrow will return the user to return to the Quad Destination view.

  • Page 67: Figure 7-13: Selecting The "Chng Prfl" Button

    CP-2116E Remote Control Panel Figure 7-13: Selecting the “CHNG PRFL” Button The CHG PRFL button when pressed will display a list of Profiles that have been assigned to the panel from MAGNUM. A Profile contains sources, destinations, labels, and categories. These can be different on a per profile basis.

  • Page 68: Figure 7-15: Selecting The "Lock Dst" Button

    CP-2116E Remote Control Panel Selecting the Enable Toggle button will either enable or disable toggle for the selected destination. When Toggle is enabled the Current Source and Next Source for a destination will flip with each Take button press. The Back button can be used to return to the return to the Quad Destination view.

  • Page 69: Figure 7-16: Selecting The "Protect" Button

    CP-2116E Remote Control Panel Figure 7-16: Selecting the “PROTECT” Button The PROTECT button when pressed will toggle between Protecting or Un-protecting the selected destination. A destination that is protected will display a Shield icon in the top right corner of the destination quadrant.

  • Page 70: Figure 7-18: Selecting The "One Dst View" Button

    The Alpha-Numeric button when pressed will allow the user to type the name of the required source in the top portion of the screen. As the user types the CP-2116E will automatically filter the source list to display any source that matches the characters typed. If a character is typed incorrectly the DEL button can be used to delete the characters.

  • Page 71: Figure 7-19: Selecting The "Take" Button

    CP-2116E Remote Control Panel Figure 7-19: Selecting the “TAKE” Button The TAKE button whether in Quad Destination View or One Destination View when pressed will route the selected source to the selected destination. When a TAKE operation is available the TAKE button will appear PINK.

  • Page 72: Figure 7-21: Selecting The "Salvo" Button

    CP-2116E Remote Control Panel When in One Destination View the TOGGLE TAKE button can be used to toggle with each press between the Current Source and the Previous Source on the selected destination. Figure 7-21: Selecting the “SALVO” Button The SALVO button when pressed will display a list of Salvos in the screen that are available to the current profile active on the panel.

  • Page 73: Figure 7-22: Selecting The "Info" Button

    CP-2116E Remote Control Panel Figure 7-22: Selecting the “INFO” Button The INFO button when selected will display information for the selected Destination, DST, Port, Source, Lock/Protect Owner Information on the Left screen and Level, Source and Next Source information on the Right Screen. The Back button can be used to return to the Quad Destination view.
  • Page 74 CP-2116E Remote Control Panel The SRC INFO button when selected with display the Source Name and Physical Port information for the source that is on the selected destination. The Back button can be used to return to the Destination Info view.
