G4101
115 60 03-38 (306)
G
B
OWNER'S MANUAL
CHAIN SAW
G4101
Original Language
GB-1
01-G4101_GB_306_三.indd 1
13.6.25 5:29:05 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G4101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zenoah G4101

  • Page 1 G4101 115 60 03-38 (306) OWNER’S MANUAL CHAIN SAW G4101 Original Language GB-1 01-G4101_GB_306_三.indd 1 13.6.25 5:29:05 PM...
  • Page 2: Table Of Contents

    G4101 Contents SAFETY FIRST Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken into 1. Parts location ...........2 consideration to prevent possible serious bodily injury, and for 2. Specification ............3 this reason you are requested to read all such instructions care- fully and follow them without fail.
  • Page 3: Specification

    When using market oil (JASO FB grade oil or ISO-L- Size mm (in.): ..........400 (16) EGB grade oil) ......GASOLINE 25: OIL 1 When using ZENOAH genuine oil, JASO FD grade oil Saw chain: Oregon 95VPX Pitch mm (in.): ........8.26 (0.325) or ISO-L-EGD grade oil.....GASOLINE 50: OIL 1...
  • Page 4: For Safe Operation

    G4101 4. For safe operation WARNING This chainsaw has been especially designed for tree maintenance and should therefore only be used by trained operators when working on trees. When using this product for the first time, before beginning fingers encircling the chain saw actual work, learn to handling it from skilled worker.
  • Page 5 G4101 20. Operate the chain saw only in well handle, and the left hand on the front ventilated areas. Never start or run handle, when the engine is running. the engine inside a closed room or Use a firm grip with thumbs and fin- building and potentially explosive gers encircling the chain saw han- atmosphere.
  • Page 6: Explanation Of Symbols On The Machine

    G4101 5. Explanation of Symbols on the Machine For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be careful not to make any mistake. The port to fuel “MIX GASOLINE” Position: Beside Fuel cap...
  • Page 7: Installing Guide Bar And Saw Chain

    G4101 6. Installing Guide Bar and Saw Chain A standard saw unit package contains the items as illustrated. Power unit Plug wrench (Hexagon socket (S13/S16) + Slotted driver) Screwdriver for carburetor adjustment (Slotted driver) Bar protector Guide bar Saw chain Open the box and install the guide bar and the saw 3.
  • Page 8: Fuel And Chain Oil

    • The Zenoah engines are lubricated by oil specially spillage around the unit. formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added WARNING quality oil expressly labeled for air-cooled 2-cycle 1. Select flat and bare ground for fueling.
  • Page 9: Operating The Engine

    G4101 8. Operating the Engine 5. When engine has ignited, first push in the choke It is very dangerous to run a chainsaw that knob to “START” position and then pull the starter mounts broken parts or lacks any parts.
  • Page 10 G4101 1. Stop engine and screw L needle until it stops. Never Carburetor anti-freeze mechanism force. Then set it back the initial number of turns as Operating chain saws in temperatures of 0 – 5°C at times shown below. H needle is restricted within the number of high humidity may result in ice forming within the of turn as shown below.
  • Page 11: Sawing

    G4101 9. Sawing guard forward. The chain should stop WARNING immediately with the engine at full • Before proceeding to your job, speed. If the chain is slow to stop or read the section “For Safe Op- does not stop, replace the brake eration”.
  • Page 12: Maintenance

    G4101 A log lying on the ground First check to which side the limb is bent. Then make the initial cut from the bent side and finish by sawing from the opposite side. WARNING • Be alert to the springing back of a cut limb. Saw down halfway, then roll the log over and cut from the opposite side.
  • Page 13: Maintenance Of Saw Chain And Guide Bar

    G4101 2. Fuel filter 4. Spark plug (a) Using a wire hook, take out the filter from the filler port. 0.65 mm Champion : RCJ-7Y NGK : BPM7Y or BPM7A Fuel filter (b) Disassemble the filter and wash with gasoline, or Clean the electrodes with a wire brush and reset the gap replace with a new one if needed.
  • Page 14: Troubleshooting Guide

    Top plate cutting angle This saw is equipped with one of the following low kick- back bar/chain combinations: ■ Guide Bar Zenoah Part Number • Reverse the bar occasionally to prevent partial Saw Model Chain Type Guide Bar Saw Chain wear.
  • Page 15 SPECIFIED BY THE COMPANY, OR OTHER CAUSES BEYOND THE COMPANY'S CONTROL. THE PURCHASER SHALL BEAR COSTS OF TRANS- PORTING THE UNIT TO AND FROM THE ZENOAH THIS WARRANTY DOES NOT COVER THOSE PARTS DEALER. REPLACED BY NORMAL WEAR OR HARMLESS CHANGES IN THEIR APPEARANCE.
  • Page 16 01-G4101_GB_306_三.indd 16 13.6.25 5:29:15 PM...
