over heating
If the Stack and Shred 100X/100M is used continuously for over 10 minutes the shredder may
overheat and the cool down indicator will flash red (
When the shredder is ready to be used the thermometer symbol will no longer illuminate. If the
shredder needs to cool down while shredding, no action is needed. The shredder will automatically
restart shredding paper once it has cooled down after periods of continuous use. All you need to do
is ensure paper is loaded into the chamber and the bin is empty when the machine is cooling down.
4. self-cleaning cutters
After emptying and replacing a full bin, the shredder will run in forward for 4 seconds, stop for 2 seconds
and then reverse for 4 seconds to clear away any remaining paper from the cutter mechanism. This
unique 'self-cleaning' mechanism is additional jam prevention technology from Swingline.
rare occasions of jamming
If after this auto jam clearance cycle the shredder still has a paper jam, it will stop and the jam
indicator illuminate (
( ) buttons. If this is unsuccessful, open the loading door, remove the remaining stack of paper,
then pull the jammed paper free of the cutting mechanism.
automatic jam clearance
In the unlikely event of the shredder jamming, the Stack and Shred 100X and 100M will
automatically reverse and forward the engine three times to clear a jam. During this operation the
Paper Jam indicator will flash (
5. bin full
The shredder will not function when the bin is full and the bin full symbol (
You should empty the bin.
• Pull open the bin slowly to empty.
• Push the empty bin back into place and press the auto button to resume shredding.
lubrication of the shredder
Only use oil sheets to lubricate. ACCO Brands accepts no liability for product performance or
safety when other types of lubricants are used on any part(s) of this machine. Insert the oil sheet
into the manual feed slot and NOT in the auto-feed chamber. Using an oil sheet in the auto-feed
chamber will contaminate the feed rollers preventing the auto-feed mechanism shredding. Follow
the maintenance instructions if the rollers become contaminated. Do not directly oil the shredder.
service
We recommend these machines are serviced every 6 to 12 months by a Swingline service
engineer – see back of this booklet for the contact details of your local service centre and for
enquiries about maintenance contracts.
6. maintenance
The rollers on the auto-feed mechanism may become dirty over time, please wipe clean with a dry
cloth to maintain maximum product performance.
The auto-start infra-red sensor, located in the paper feed entry-slot, can occasionally become
covered in paper-dust causing the shredder to run despite no paper being fed into the machine.
Switch the shredder off at the rear of the machine and carefully clean the sensor using a cotton-swab.
shredder accessories
Accessory
Recycling Waste Sack
10
). Try clearing the jam using the reverse (
).
Part Number Box Quantity
1765031
). Please allow the shredder to cool down.
) and continuous jam boost
) is illuminated.
20
