Physical Description

Front Panel

Status LED's
and follow the trouble-shooting procedures. If the system still cannot operate normally,
please contact your reseller for technical service.
Network Interface
Ethernet
PPP with modem
PPP with null modem
Each time Video Server starts up, it will perform
power-on-self-test, abbreviated as POST, to
examine every hardware module. As soon as the
administrator plugs in the power connector both
LED's under the power LED will flash one by one
until the diagnosis is done. If the result is good,
both status LED's will turn off for a while and
then follows the pattern below. If any module
fails, refer to the Appendix A for the error pattern
Condition
before IP installed
after IP installed
during camera control
after POST
during camera control
before connected
after connected
during camera control
- 6 -
LED1 (Heartbeat) LED2 (Status)
OFF
Blink
Blink
Blink
Blink
ON
Blink
Blink
OFF
OFF
Blink
ON
Blink
ON
ON
Blink
