Set digital outputs

To set digital output 1 to connect NO with COMMON, type "DO1=O".
To set digital output 1 to connect NC with COMMON, type "DO1=C".
To set digital output 2 to connect NO with COMMON, type "DO2=O".
To set digital output 2 to connect NC with COMMON, type "DO2=C".

Erase snapshots stored in Flash memory

Typing "erase image" will clear all snapshots saved in Flash memory.

Erase logo and graphic buttons

Typing "erase graph" will clear all images used on the homepage. If no new images are
uploaded, the system will switch to text mode and use default images instead.

Skip installation at next boot

Typing "lock" will inform Video Server to fix current network settings. It need not wait for
installation during the next boot.

Reset network for new settings

Typing "unlock" will make Video Server give up current settings and wait for installation.

Restore factory default settings

Typing "clear" will make Video Server restore factory settings but not restart. To validate
new settings, type "reset" to make the system restart.

Reset system

Typing "reset" will make Video Server perform a software reset.
- 66 -
