URL for External Device Control

Query status of digital inputs
/cgi-bin/getdi.cgi
Video Server will return status of four digital inputs in one line.
Drive digital outputs
/cgi-bin/setdo.cgi?do<number>=<state>
<number>: 1, 2 for DO1 and DO2
<state>: C, O denoting Normal Close or Normal Open respectively.
Move motorized camera in PTZ direction
/cgi-bin/control.cgi?<param>=<value>
param value
cam 1
2
3
4
move up
down
left
right
home
zoom wide
tele
focus near
far
auto
panspeed -5 ~ 5
tiltspeed -5 ~ 5
Recall camera position
/cgi-bin/recall.cgi?cam=<n>&recall=<position>
<n>: video channel from 1 to 4
<position>: the text string of a location that is preset in system configuration.
Refer to Camera preset configuration URL for preset function.
Description
Video 1
Video 2
Video 3
Video 4
Tilt up
Tilt down
Pan left
Pan right
Return to home position
Zoom in
Zoom out
Focus near
Focus far
Automatic focus
- 55 -
