Practical examples

Command line
MAB=1C;
1H*2\=(5)1O;
B\+C\+D\=W{192.
168.0.1:6000}{no
signal!};
2H=VAP15;
MCD=UF+SABCD+
N{video%c%a@%
y%M%d%h%m%s
};
The script file is limited to maximum 500 characters. The actual performance will
depend on the complexity of the command script. Administrators should reduce the
redundant check as possible. Overload conditional check and heavy actions may retard
the system operation.
Description
When any motion is detected on channel 1 or 2, "Normal Close"
of relay output 1 will short with "Common".
When DI1 high companied with DI2 transient from high to low,
"Normal Open" of relay output 1 will short with COMMON in 5
seconds.
If there is no signal on channel 2 or 3 or 4, a message "no
signal!" will be sent to port 6000 of 192.168.0.1 once.
When sensor input 2 is high, drive the camera mapped to video
1 to go to preset location 16.
If any motion is detected on channel 3 or 4, upload snapshots
taken on channel 1, 2, 3 and 4. If an event triggered at 19:05:30
2002/10/15, the snapshot files will be named as,
video1pre@20021015190530.jpg, video2pre@20021015190530.jpg
video3pre@20021015190530.jpg, video4pre@20021015190530.jpg
video1trg@20021015190530.jpg, video2trg@20021015190530.jpg
video3trg@20021015190530.jpg, video4trg@20021015190530.jpg
video1pos@20021015190531.jpg, video2pos@20021015190531.jpg
video3pos@20021015190531.jpg, video4pos@20021015190531.jpg
