No Output in Large Screen

1. Check whether input the signal.
2. Check whether the interfaces are in good connection.
3. Check whether the input wire and output wire are normal.

Display shows no bottom half part

Sending card does not support the bottom
half part
There are limits for different sending cards. As for Linsn TS802, if output
resolution is 1920 or higher, while every LAN port can support only 320
height LED screen, more than this value need to add D mouth reticle,
more than 640, need to add more sending cards as cascade.

LED Display Shakes

Sending card input recognition is not correct
It usually occurs when use sending card improperly or hot plug. It is
normal before, but LED display shakes after change the output
resolution. Generally, it will normally operate if reboot the device.
