- Page 1 VMA333 TB6560 3A STEPPER MOTOR DRIVER BOARD USER MANUAL...
-
Page 2: Safety Instructions
Nor Velleman nv nor its dealers can be held responsible for any damage (extraordinary, incidental or indirect) – of any nature (financial, physical…) arising from the possession, use or failure of this product. -
Page 3: Pin Layout
VMA333 Overview operating voltage ....................10-35 VDC rated output current .................. ± 3 A - peak 3.5 A dimensions ....................50 x 75 x 35 mm weight ......................... 80 g Pin Layout terminal description EN+ EN- enable positive/negative CW+ CW-... - Page 4 VMA333 Connection. TB6560 driver board======4-wire stepper motor A+======red wire =A-=====blue wire B+======green wire B-======black wire void setup() { pinMode(3,OUTPUT); pinMode(A0,OUTPUT); // Set pin 9's PWM frequency to 3906 Hz (31250/8 = 3906) // Note that the base frequency for pins 3, 9, 10, and 11 is 31250 Hz //setPwmFrequency(9, 8);...
-
