ESSENTIAL INTERACTIVE SERIES
RECUMBENT BIKE
SF-RB422003
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESSENTIAL INTERACTIVE Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny ESSENTIAL INTERACTIVE Series

Summary of Contents for Sunny ESSENTIAL INTERACTIVE Series

  • Page 1 ESSENTIAL INTERACTIVE SERIES RECUMBENT BIKE SF-RB422003 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly.

  • Page 3: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 4: Hardware Package

    HARDWARE PACKAGE #14 Ф8.5x1.5xФ25xR33.5 4PCS #27 M8x16 9PCS #36 M8xL100 2PCS #35 D8x1.5xФ16 12PCS #50 M8*50 2PCS #37 M8 3PCS #87 S6 1PC #51 M8x60 1PC #89 S5 1PC #88 S13, S14, S15 1PC Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ✓...

  • Page 5: Parts List

    PARTS LIST Description Spec. Qty. Description Spec. Qty. Cross Pan Head Main Frame ST3.5x8 Self-Drilling Screw Handlebar Post Bushing Rear Support Tube Square Bushing Slide Rail Backrest Hex Socket Pan Seat Tube M8x50 Head Screw Handlebar Carriage Bolt M8x60 Adjustment Block Foam Grip Axle Adjustment Handle...
  • Page 6 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 1 Remove preassembled Carriage Bolts (No. 13) 4 Arc Washers (No. 14) and 4 Cap Nuts (No.
  • Page 7 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907- 8669). STEP 2 A: Connect the Pulse Connecting Wire (No. Pulse Connecting Wire 2 (No. 24) and connect the Sensor Wire (No.
  • Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 3 Connect the Pulse Connecting Wire (No. Pulse Connecting Wire 3 (No. 25). Lock the Rear Support Tube (No.
  • Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 5 Lock the Seat (No. 34) to the Seat Tube (No. 5) with 4 Screws (No. 27) and 4 Flat Washers (No.
  • Page 10 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 7 Remove the preassembled 4 Screws (No. 32) from the Meter (No. 33) using Spanner (No. 88).

  • Page 11: Adjustment Guide

    ADJUSTMENT GUIDE ADJUSTING THE SEAT POSITION ADJUSTING THE LEVEL To move the Seat (No. 34) forward or If at any point the bike does not feel level, you can adjust the Rear End Caps (No. backward, while seated on the bike, put your 19).

  • Page 12: Battery Installation And Replacement

    BATTERY INSTALLATION & REPLACEMENT BATTERY INSTALLATION AAA 1.5V The meter uses 2 batteries. Open the battery cover from the back of meter, then put 2 batteries into the battery compartment. Make sure the (+) and (-) ends of the batteries are in the correct position.

  • Page 13: Function Buttons

    EXERCISE METER FUNCTION BUTTONS: MODE: Press the button to select TIME, DISTANCE, and CALORIES to preset. Press the button for selection function display value on LCD or enter after setting. Press the button and hold for 3 seconds to reset all values except odometer to zero.
  • Page 14 3. Dispose the batteries safely, according to your state and regional guidelines. APP CONNECTION 1. Scan below QR code to enter the app store and download the Sunny Health & Fitness app to your mobile phone. 2. Press the Bluetooth switch to connect.
