Z3 Technology Z3Stream-01 User Instructions page 43

(UDP, RTP/RTSP or TS
Over RTP Only)
Authentication
(RTMP only)
User
(RTMP Only)
Password
(RTMP Only)
Custom Encode Options
(To access these options, Custom must be selected in the Encode Quality dropdown menu.)
Video Resolution
Video Bitrate
Video Profile
Frame Rate
Number of B-frames
___________________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Disable
Enable
352x240 – 1920x1080
Follow Input
100 – 12000K (450K)
High
Main
Baseline
Full
Half
Quarter
Sixth
None
1
2
th
ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ Z3Stream.com
to.
When in RTMP mode, the encoder supports entering
an authentication User Name and Password.
If this is desired, set to Enable. User and Password
text boxes then become active.
User name to enter when Authentication is
enabled.
Password to enter when Authentication is enabled.
The encode resolution. If this resolution is different
from the capture resolution, resizing will occur.
"Follow Input" generates the resolution based on
the capture resolution. [Note 1]
Textbox for entering video bitrate. For example:
1M = 1,000,000 bits per second
1000K = 1,000,000 bits per second
2.5M = Not a Valid Format
The H.264 profile of the bitstream.
Generally High is used for 1080p, Main for D1, and
Baseline for <D1.
Used to encode at less than the input frame rate
(for example, an input frame rate of 30fps with
Half selected would cause an output stream of
15fps). If interlaced input is used then this is used
to reduce the number of fields being encoded.
[Note 2]
The number of B-frames.
Selecting None disables B-frames.
