Specification
Model
DGT-IR-1089CN20
Pick up Element
1/3"CMOS
Effective Picture
728(H)×488(V)
Elements (H×V)
Horizontal Resolution
600TV Line
Minimum Illumination
0.1Lux
S/N Ratio
More than 48dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
PAL: 1/50s~1/100,000s
Gama Characteristic
0.45
IR Distance
20 Meters (with ￠ 5 X24PCS Infrared LED)
IR Status
Under 10Lux by CDS
IR Power On
CDS AUTO Control
Video Output
1Vpp, 75
Auto Gain Control
Auto
DC12V (+/-10%)/350mA
Power / / / / C urrent
Lens
Board Lens 3.6mm / F2.0
Dimension (mm)
175(W) x69(H) x55(D)mm
Weight (g)
830
Storage Temperature
-30~+60 ℃ RH95% MAX
Operating Temperature
-10~+45 ℃ RH95% MAX
Packing List
No
Name
1.
DGT-IR-1089CN20
Weatherproof IR Color Cameras
2.
User Guide
DGT-IR-1089CN20
Franchiser：
Model
Number
1
1
DGT-IR-1089CN20
Color Camera
IR Color Camera
Weatherproof
Notes : : : :
B efore providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
Advertisement
Related Manuals for Digital Equipment DGT-IR-1089CN20
Summary of Contents for Digital Equipment DGT-IR-1089CN20
- Page 1 Specification DGT-IR-1089CN20 Model DGT-IR-1089CN20 Color Camera Pick up Element 1/3"CMOS Effective Picture 728(H)×488(V) Elements (H×V) IR Color Camera Weatherproof Horizontal Resolution 600TV Line Minimum Illumination 0.1Lux S/N Ratio More than 48dB Scanning System 2:1 interface Synchronous System Internal, Negative sync.
- Page 2 Congratulations on your purchase of this product. * * * * Sensor ( ( ( ( C CD ) ) ) ) This User Guide suits DGT-IR-1089CN20 product. We Adopt CMOS 1/3 " CCD Sensor. adopt the latest CMOS technical of sensor and driver. The...
