Model Number
106B51
Performance
Measurement Range(for ±5V output)
Useful Overrange
Sensitivity(± 15 %)
Maximum Pressure(step)
Maximum Pressure(static)
Resolution
Resonant Frequency
Rise Time
Low Frequency Response(-5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Vibration
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® PRESSURE SENSOR
ENGLISH SI
5 psi 35 kPa
10 psi 69 kPa
1000 mV/psi 145 mV/kPa
100 psi 690 kPa
500 psi 3448 kPa
0.05m psi .00034 kPa
≥ 40 kHz ≥ 40 kHz
≤ 12 µ sec ≤ 12 µ sec
0.5 Hz 0.5 Hz
≤ 1 % FS ≤ 1 % FS
≤ 0.002 psi/g ≤ 0.0014 kPa/(m/s²)
-65 to +250 °F -54 to +121 °C
-65 to +250 °F -54 to +121 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
3000 °F 1649 °C
500 g pk 4903 m/s² pk
1000 g pk 9807 m/s² pk
Positive Positive
≥ 1 sec ≥ 1 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Quartz Quartz
17-4 Stainless Steel 17-4 Stainless Steel
316L Stainless Steel 316L Stainless Steel
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
1.13 oz 32 gm
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
[1]
except where noted below. More than one option may be used.
E
- Emralon coating
Coating
Electrical Isolation
J
- Ground Isolated
[2]
N
- Negative Output Polarity
W
- Water Resistant Cable
Supplied Accessory : Model 060A11 Acetal clamp nut 3/4-16-2A thd 3/4" hex (1)
WM
- Water Resistant Cable
Supplied Accessory : Model 060A13 Metric Acetal clamp nut M20 x 1.5-6g thd 20 mm hex (1)
NOTES:
[1]For +10 volt output, minimum 24 VDC supply voltage required. Negative 10 volt output may be
limited by output bias.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.

SUPPLIED ACCESSORIES:

Model 060A11 Acetal clamp nut 3/4-16-2A thd 3/4" hex
Model 060A13 Metric Acetal clamp nut M20 x 1.5-6g thd 20 mm hex (1)
Model 065A36 Seal, .687" OD x .625" ID x .060", Derlin (3)
Entered: LK Engineer: BAM
Date: 4/7/2016 Date: 4/7/2016
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 45338
Emralon Emralon
8
10 Ohm 10
Sales: MFG Approved: RPF Spec Number:
Date: 4/7/2016 Date: 4/7/2016
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
8
Ohm
23894
