Model Number
106B
Performance
Measurement Range(for ±2.5V output)
Sensitivity(± 15 %)
Maximum Pressure(step)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material 304/304L Stainless Steel
Diaphragm 316L Stainless Steel
Sealing
Electrical Connector 10-32 Coaxial Jack
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
8.3 psi 57.2 kPa
300 mV/psi 43.5 mV/kPa
200 psi 1,379 kPa
2 kpsi 13,790 kPa
0.0001 psi 0.00069 kPa
≥ 60 kHz ≥ 60 kHz
≤ 9 µ sec ≤ 9 µ sec
0.5 Hz 0.5 Hz
≤ 1 % FS ≤ 1 % FS
≤ 0.002 psi/g ≤ 0.0014 kPa/(m/s²)
-65 to +250 °F -54 to +121 °C
≤ 0.05 %/°F ≤ 0.09 %/°C
3,000 °F 1,649 °C
2,000 g pk 19,600 m/s² pk
Positive Positive
≥ 1 sec ≥ 1 sec
12 to 30 VDC 12 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
3 to 8 VDC 3 to 8 VDC
Compression Compression
Quartz Quartz
304/304L Stainless Steel
316L Stainless Steel
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack
0.63 oz 18.0 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
- Emralon coating
E
Coating
Electrical Isolation
[1]
Optional Accessory: Model 065A47 Seal ring 0.497 OD x 0.437 ID x 0.025 thk Acetal (3)
J - Ground Isolated
Electrical Isolation(50 V)
[2]
- TEDS Capable of Digital Memory and
T
Communication Compliant with IEEE P1451.4
Output Bias Voltage
- Water Resistant Cable
W
Supplied Accessory: Model 060A12 Clamp nut, 9/16-18-2A thd, 9/16" hex (1)
- Water Resistant Cable
WM
Supplied Accessory: Model 060A14 Metric clamp nut, M14 x 1.25-6g thd, 14 mm hex, stainless steel
(1)
N OTES:
[1]Typical.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
[4]Used with optional mounting adaptor.
[5]Clamp nut installed prior to cable attachment

SUPPLIED ACCESSORIES:

Model 060A12 Clamp nut, 9/16-18-2A thd, 9/16" hex (1)
Model 060A14 Metric clamp nut, M14 x 1.25-6g thd, 14 mm hex, stainless steel (1)
Model 065A37 Seal ring 0.497 OD x 0.437 ID x 0.025 thk Brass (3)
Entered: ND Engineer: MJK
Date: 02/01/2022 Date: 02/01/2022 Date: 02/01/2022 Date: 02/01/2022 106-2010-80
3425 Walden Avenue, Depew, NY 14043
Revision: AA
ECN #: 52524
OPTION AL VERSION S
Emralon Emralon
8 8
10 Ohm 10 Ohm
8 8
10 Ohm 10 Ohm
3.7 to 8.7 VDC 3.7 to 8.7 VDC
