Summary of Contents for tilgin HG2302
- Page 1 Tilgin Home Gateway HG2300 series Quick Guide Tilgin HG2300 series Quick Guide...
- Page 2 Tel: +46 (0)8 572 38600 Fax: +46 (0)8 572 38500 For more company, product and contact info: www.tilgin.com This product is developed and manufactured by Tilgin IPRG AB. Document Product Number: 13650030 Content Version: PB1 Tilgin HG2300 series Quick Guide...
-
Page 3: Table Of Contents
Notice of Copyright and Patent Protection ....... 18 How to Mount the Home Gateway ........... 19 14.1 Desk Top Mount ............... 19 14.2 Wall Mount ................20 Used Acronyms ................ 23 Tilgin HG2300 series Quick Guide... -
Page 4: Introduction
The home gateway you have received enables services provided by your operator and can become the full service node in your home. This Quick Guide contains start-up instructions for installing Tilgin Home Gateways HG2300 series. When following the instructions to connect and start- up the home gateway it will automatically connect to your operators network for enabling services offered by your operator. -
Page 5: Home Gateway Overview
Home Gateway Overview 3.1. Home Gateway cable attachments See more instructions below (Picture shows HG2301) These ports are only available on HG2301/HG2304 Tilgin HG2300 series Quick Guide... -
Page 6: Home Gateway Interfaces
3.2. Home Gateway Interfaces Rear panel (Backside) (Picture shows HG2301) Tilgin HG2300 series Quick Guide... - Page 7 Power Input Black Connects the power adapter ON / OFF Button for turning the home gateway on or off Reset Button for factory reset Phone 1 Green Connects analogue phones or fax equipment Phone 2 White Tilgin HG2300 series Quick Guide...
-
Page 8: Leds Front Panel
Wireless function enabled. Wireless GREEN, Slow flash WPS in progress GREEN, Rapid flash WPS failed GREEN Short flash WPS succeeded No link GREEN, Rapid flash Traffic activity A,B,C,D GREEN, Stable Link 10/100M YELLOW, Stable Link 1000M Tilgin HG2300 series Quick Guide... -
Page 9: Installing Your Home Gateway
Home gateways must always be installed away from heat sources and direct sunlight. The flowchart below describes the procedures to install your home gateway and is in detail explained in the following pages Tilgin HG2300 series Quick Guide... -
Page 10: Connecting To The Internet (Wan)
30 minutes. If the LED still does not show stable green after 30 minutes, then reboot (push power ON/OFF-button). If problem persists, contact your operator. For more information about the LED status, see LEDs Front panel. Tilgin HG2300 series Quick Guide... -
Page 11: Connecting A Computer To Your Home Gateway
Connecting a computer by using WLAN (Wireless LAN) WPS method The Tilgin home gateway supports the Wi-Fi Protected Setup (WPS) feature to make it easy to set up a secure wireless home network. Two WPS methods are supported, PIN and Push Button Connect (PBC). -
Page 12: Configuring Wlan Client For Computer Devices
Default WLAN port settings Check that the parameters for WLAN are set according to SSID and WPA key found on the casing label on the back of the home gateway. SSID = Tilgin-<12 random characters> Example: Tilgin-1wa23sbg9skm Channel = Auto... -
Page 13: Connecting Phones / Equipment
DO NOT use an ordinary phone cable for this purpose. It requires a special Phone cable and can be different from country to country. This option must be supported in your country and by your operator. Tilgin HG2300 series Quick Guide... -
Page 14: Troubleshooting Tips
Please see information provided by your operator. If these actions still do not solve the problem, contact your operator or the vendor that supplied your home gateway. Tilgin HG2300 series Quick Guide... -
Page 15: Safety Information
All use of the product is subject to the Safety Recommendations above. Tilgin IPRG AB waives all and any liability for damages caused to i) the product or any other property or ii) yourself or any other individual as a consequence of using the product in ways that deviate from the safety recommendations set out above. -
Page 16: Power Supply
Power Supply Do not use any other power supply than the one delivered by Tilgin. Using the wrong power supply could be hazardous to you or the product. The power supply is approved by one or more of the following safety... - Page 17 Tilgin HG2300 series Quick Guide...
-
Page 18: Fcc Notice
20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance." Tilgin HG2300 series Quick Guide... -
Page 19: Technical Specifications
You may also contact your operator for more information on the environmental performances of these products. Power Saver Reminder If not using WLAN it is recommended to shut it down by pushing the ECO mode button (#1) (OFF). Tilgin HG2300 series Quick Guide... -
Page 20: Warranty
No warranty, express or implied, with respect to the product is extended directly to you from or on behalf of Tilgin IPRG AB. Limited warranties may be granted to you by the equipment provider in its capacity as reseller of the product. -
Page 21: How To Mount The Home Gateway
Put the foot stand/wall bracket on a level surface Place the device on the foot stand/wall bracket on the slot Fig 1 Snap the home gateway in the slots Fig 2 Fig. 1 Fig. 2 Tilgin HG2300 series Quick Guide... -
Page 22: Wall Mount
Fig 3 Connect the cables to the ports on the rear panel. Fig 4 Hang the device on the foot stand/wall bracket hooks. Fig 5 and Fig 6 Fig. 3 Tilgin HG2300 series Quick Guide... - Page 23 Fig. 4 Fig. 5 Tilgin HG2300 series Quick Guide...
- Page 24 Fig. 6 Tilgin HG2300 series Quick Guide...
-
Page 25: Used Acronyms
Light Emitting Diod PBC Method Push Button Connect method SSID Service Set Identifier VoIP Voice over IP Wide Area Network Wi-Fi Trademark for Wi-Fi Alliance WLAN Wireless Local Area Network Wi-Fi Protected Access Wi-Fi Protected Setup Tilgin HG2300 series Quick Guide... - Page 26 Empty page...
- Page 27 Empty page Tilgin HG2300 series Quick Guide...
- Page 28 Under the copyright laws this Quick Guide, artwork, software, and product designs may not be copied, in whole or part, without the written consent of Tilgin IPRG AB. Under the law, copying includes translation to another language or format.
