Samsung SCA20 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE
For mechanical disassembly and adjustment, refer to the "Mechanical Manual"
(DE-6
AD68-30200A).
8mm CAMCORDER
8mm CAMCORDER
SCA20/SCA23
SCA25
Manual
1. Precautions
2. Reference Information
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung SCA20

Summary of Contents for Samsung SCA20

  • Page 1: Table Of Contents

    8mm CAMCORDER SCA20/SCA23 SCA25 SERVICE Manual For mechanical disassembly and adjustment, refer to the “Mechanical Manual” (DE-6 AD68-30200A). 8mm CAMCORDER CONTENTS 1. Precautions 2. Reference Information 3. Product Specifications and Comparison Chart 4. Disassembly and Reassembly 5. Alignment and Adjustment 6.
  • Page 2 Alternatively, wear a discharging Wrist-strap device. (Be sure to remove it prior to applying power--this is an electric shock precaution.) Samsung Electronics...
  • Page 3 Always inspect for pinched, out- of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that leads and components do not touch thermally hot parts. Samsung Electronics...
  • Page 4 Reference Information 2. Reference Information 2-1 IC Blocks 2-1-1 IC101 (M52369FP) Samsung Electronics...
  • Page 5 Reference Information 2-1-2 IC601 (CXP87240A) Samsung Electronics...
  • Page 6 Reference Information 2-1-3 IC201 (CXA1700R) Samsung Electronics...
  • Page 7 Reference Information 2-1-4 IC501 (KA8322) Samsung Electronics...
  • Page 8 Reference Information 2-1-5 ICP01 (KS7213) Samsung Electronics...
  • Page 9 Reference Information 2-1-6 ICP03 (TDA8786A / AD CONVERTER) Samsung Electronics...
  • Page 10 Reference Information 2-1-7 ICP04 (KS7306 / DSP) Samsung Electronics...
  • Page 11 Reference Information 2-1-8 ICP05 (UPD784035 / AF MICOM) Samsung Electronics...
  • Page 12 Reference Information 2-1-9 ICZ01 (KS7314 / D.ZOOM) Samsung Electronics...
  • Page 13 SCA20 : Black and White electronic viewfinder SCA23/SCA25 : Color electronic viewfinder Lens SCA23/SCA25 : Combined 16x power zoom and 64x digital zoom SCA20 : Combined 16x power zoom and 32x digital zoom f=3.9 ~ 62.4 mm, F1.4 Auto wide macro Automatic focus system Inner...

  • Page 14: Product Specifications And Comparison Chart

    Product Specifications 3-2 Comparison Chart MODEL SCA20 SCA23 SCA25 FUNCTION 270,000 270,000 270,000 VIEWFINDER ZOOM X32D.ZOOM X64 D.ZOOM X64 D.ZOOM STEREO MONO MONO MONO Samsung Electronics...

  • Page 15: Disassembly And Reassembly

    4. Disassembly and Reassembly 4-1 Cabinet Disassembly 4-1-1 Cover Battery Removal ΠPUSH THE COVER BATTERY AND REMOVE IT IN THE DIRECTION OF ARROW. Fig. 4-1 Cover Battery Removal Samsung Electronics...
  • Page 16 Disassembly and Reassembly 4-1-2 Ass’y Cover Housing Removal ŒAPPLY POWER AND OPEN THE HOUSING ASS'Y. ´REMOVE 2 SCREWS. ˇREMOVE THE ASS'Y COVER HOUSING IN THE DIRECTION OF ARROW. Fig. 4-2 Ass’y Cover Housing Removal Samsung Electronics...
  • Page 17 TABS WITH A SMALL SCREW DRIVER. (SEE DATAIL "A") NOTE : WHEN REASSEMBLING, PUT THE 7 TABS INTO THE SLOT WHILE SLIDING IT AS SHOWN IN DETAIL "B". 2 LOCKING TABS PRECISION SCREW DRIVER DETAIL "A" DETAIL "B" Fig. 4-3 Ass’y Case Top Removal Samsung Electronics...
  • Page 18 Disassembly and Reassembly 4-1-4 Ass’y Front Removal (1) ˇ REMOVE THE ASS'Y FRONT IN THE DIRECTION OF ARROW. ´ REMOVE 1 SCREW ¨ DISCONNECT THE CONNECTOR FROM THE MAIN PCB. Œ REMOVE 1 SCREW. Fig. 4-4 Ass’y Front Removal (1) Samsung Electronics...
  • Page 19 ˆ REMOVE 1 SCREW AND THE COVER ROTATE BY TURNING IT. ¨ REMOVE 2 SCREWS AND THE ASS'Y MIC BOARD. ˇ REMOVE THE ASS'Y MIC Œ REMOVE 2 SCREWS. ´ DISCONNECT THE CONNECTOR FROM THE ASS'Y MIC BOARD. Fig. 4-5 Assy Front Removal Samsung Electronics...
  • Page 20 ˆ REMOVE THE ASS'Y CASE RIGHT IN THE DIRECTION OF ARROW "B". ´ REMOVE 2 SCREWS ¨ MOVE THE ZOOM SWITCH IN THE DIRECTION OF ARROW "A". ˇ REMOVE 3 SCREWS Œ REMOVE 1 SCREW Fig. 4-6 Ass’y Case Right Removal (1) Samsung Electronics...
  • Page 21 IN THE DIRECTION OF ARROWS "A","B". Œ REMOVE 2 SCREWS. ˆ REMOVE 2 CONNECTORS FROM THE MAIN PCB. ¨ REMOVE THE ASS'Y CASE LEFT IN THE DIRECTION OF ARROW "C". ´ REMOVE 1 SCREW. Fig. 4-7 Ass’y Case Left Removal (1) Samsung Electronics...
  • Page 22 Disassembly and Reassembly 4-1-8 Ass’y Case Left Removal (2) ´ REMOVE THE TERMINAL BOARD. Œ REMOVE 4 SCREWS Fig. 4-8 Ass’y Case Left Removal (2) Samsung Electronics...
  • Page 23 Disassembly and Reassembly 4-1-9 Ass’y Rear Board Removal (1) Œ REMOVE 1 SCREW. ˇ REMOVE THE ASS'Y CASE REAR IN THE DIRECTION OF ARROW. ´ REMOVE 1 SCREW. Fig. 4-9 Ass’y Rear Board Removal (1) Samsung Electronics...
  • Page 24 Disassembly and Reassembly 4-1-10 Ass’y Rear Board Removal (2) Œ REMOVE 1 SCREW. ´ REMOVE THE ZOOM SWITCH. ˇ REMOVE 2 SCREWS. ¨ REMOVE THE REAR BOARD. Fig. 4-10 Ass’y Rear Board Removal (2) 4-10 Samsung Electronics...
  • Page 25 ¨ REMOVE THE ASS'Y DECK IN THE DIRECTION OF ARROW. ˇ DISCONNECT THE FPC FROM THE MAIN PCB. Œ REMOVE 2 SCREWS ´ DISCONNECT THE FPC FROM THE ASS'Y DECK. Fig. 4-11 Ass’y Main Board and Ass’y Deck Removal Samsung Electronics 4-11...
  • Page 26 4-1-12 Ass’y Camera Removal (1) ´ REMOVE 2 SCREWS. ˇ DISCONNECT 3 FPC FROM THE MAIN PCB. Œ DESOLDER ¨ REMOVE THE ASS'Y CAMERA FROM THE MAIN PCB IN THE DIRECTION OF ARROW. Fig. 4-12 Ass’y Camera Removal (1) 4-12 Samsung Electronics...
  • Page 27 Disassembly and Reassembly 4-1-13 Ass’y Camera Removal (2) Œ REMOVE 1 SCREW ˇ REMOVE THE BRACKET-LENS. ´ REMOVE 1 SCREW. ¨ REMOVE 2 SCREWS. ˆ REMOVE THE ASS'Y PCB-CCD Fig. 4-13 Ass’y Camera Removal (2) Samsung Electronics 4-13...
  • Page 28 Disassembly and Reassembly 4-1-14 Ass’y EVF/CVF Removal Œ REMOVE 2 SCREWS ´ REMOVE THE ASS'Y EVF/CVF IN THE DIRECTION OF ARROW. Fig. 4-14 Ass’y EVF/CVF Removal 4-14 Samsung Electronics...
  • Page 29 Disassembly and Reassembly 4-2 Circuit Boards Location Fig. 4-15 Circuit Boards Location Samsung Electronics 4-15...
  • Page 30 MAIN PCB CNP02 CN001 TERMINAL PCB MAIN PCB CN901 CNE01 MAIN PCB CN602 CNE01 MAIN PCB CN603 CN801 FRONT PCB MAIN PCB CN851 MIC ASSY FRONT PCB CN802 MIC ASSY MAIN PCB CNP03 Fig. 4-16 Circuit Boards Location 4-16 Samsung Electronics...

  • Page 31: Alignment And Adjustment

    PB RF Head Switching -Trigger CTP501 Fig. 1 Test point 4. After completing the adjustment, open the pin 67 of IC601 and GND to release the TEST mode. Main PCB (Component side) Fig. 2 The location of test point Samsung Electronics...
  • Page 32 START/STOP(CONFIRM) Data store after finishing adjustment by DATA UP/DOWN button. - (DATA DOWN) When changing data value of adjust state. + (DATA UP) BLC (MODE UP) Mode change. FADE (MODE DOWN) DATE (FAR ) Focus adjustment. TITLE (NEAR) Samsung Electronics...
  • Page 33 5. Set OSD on state. NEGATIVE STEP 3 On screen display show “CD HALLA XX XX” CAMERA ADJUSTMENT mode has successfully been activated. Note : When ÒXX XXÓ is shown in service adjustment precedures, this indicates variable values. Samsung Electronics...
  • Page 34 Note : ÒData 1Ó is previous setting in memory, ÒData 2Ó is Example) “ 00 XXXX XX “ now adjustment setting, that changes during adjustment mode. After pressing ÒSTART/STOP (Confirm)Ó, it goes to memory. SCA20 SCA23 MODE DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT...
  • Page 35 R DETECT WINDOW H STOP POINT R DETECT WINDOW V START POINT R DETECT WINDOW V STOP POINT DSP ODM COMMEND NOT USED COLOR ADJUST START VALUE NOT USED NOT USED NOT USED CCD DEFECT COMPENSATION FACTOR ODM AE CLIP THRESHOULD VALUE Samsung Electronics...
  • Page 36 R INDOOR START VALUE OF W/B ADJUST R OUTDOOR CONTROL UP/DOWN MARGIN R INDOOR CONTROL UP/DOWN MARGIN B INDOOR CONTROL UP/DOWN MARGIN B OUTDOOR CONTROL UP/DOWN MARGIN INITIAL(POWER ON) R CTL START DATA INITIAL(POWER ON) B CTL START VALUE W/B TABLE MODE Samsung Electronics...
  • Page 37 VR ZOOM CENTER MARGEIN COLOR GAIN ADJUST SETUP AUTO ADJUST HALL CHECK THRESHOULD COLOR ADJUST TARGET VALUE HALL ADJUST GAIN TARGET HALL ADJUST CENTER NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED Samsung Electronics...
  • Page 38 NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED 6. Initial data of camera parts adjustment - CAMERA AF 2nd MICOM (UPD784035GC-818) DATA SCA20 SCA23 SCA25 MODE DATA1 DATA2 DATA1 DATA2 DATA1 DATA2...
  • Page 39 Alignment and adjustment SCA20 SCA23 SCA25 MODE DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT CHOR OUTDOOR B-Y NEGATIVE HUE AETAL AE TARGET (LOW BYTE) AETAH AE TARGET (HIGH BYTE) AGCMA AGC MAXIMUM CONTROL WBTAR WHITE BALANCE R TARGET...
  • Page 40 Alignment and adjustment SCA20 SCA23 SCA25 MODE DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT R DETECT WINDOW V STOP POINT DSP ODM COMMEND CLIP COUNTER THRESHOULD COLOR ADJUST START VALUE R TARGET UP/DOWN OF D ZOOM B TARGET UP/DOWN OF D ZOOM...
  • Page 41 Alignment and adjustment SCA20 SCA23 SCA25 MODE DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT R INDOOR START VALUE OF W/B ADJUST R OUTDOOR CONTROL UP/DOWN MARGIN R INDOOR CONTROL UP/DOWN MARGIN B INDOOR CONTROL UP/DOWN MARGIN B OUTDOOR CONTROL UP/DOWN MARGIN...
  • Page 42 Alignment and adjustment SCA20 SCA23 SCA25 MODE DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT NOT USED BK NOISE TH/GAIN OF EIS H APPERTURE GAIN OF EIS #0C OF EIS ON #OD OF EIS ON #OE OF EIS ON...
  • Page 43 Full auto : Press ÒSTART/STOP (CONFIRM)Ó button for full auto adjustment. The camera will move both zoom and focus lens. The adjustment is finished when the O.K! message appears on the TV screen. 8M~10M(About 30ft) (Be sure to maintain the distance.) LENS Samsung Electronics 5-13...
  • Page 44 (MODE DOWN)Ó button so that the OSD state is Ò05 P.CLK XX XXÓ. 5) Adjust the Ò + (DATA UP)/ - (DATA DOWN)Ó button so that frequency is NTSC : SCA20/A23/A25 (9.534964MHz ±50Hz). PAL : VP-A20/A22/A23 (9.453125MHz ± 50Hz). P.CLK ADJUSTMENT uminance Main PCB (component side) 4.
  • Page 45 1500 to 2000 lx. 6) Adjust the Ò + (DATA UP)/ - (DATA DOWN)Ó button so that the white vector moves to the B-Y axial on screen of the vectorscope. 7) The OSD shows ÒOK!Ó. Samsung Electronics 5-15...
  • Page 46 7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó button so that the blue level is 50IRE. 7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó button to memorize setting. 8) The OSD shows ÒOK!Ó. button to memorize setting. 8) The OSD shows ÒOK!Ó. 70IRE 50IRE 5-16 Samsung Electronics...
  • Page 47 6) Adjust the Ò + (DATA UP)/ - (DATA DOWN)Ó button so that the red vector is 104. 7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó button to memorize setting. 8) The OSD shows ÒOK!Ó. RED VECTOR 104 DEG. Samsung Electronics 5-17...
  • Page 48 7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó 7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó button to memorize setting. button to memorize setting. 8) The OSD shows ÒOK!Ó. 8) The OSD shows ÒOK!Ó. YELLOW VECTOR 165 DEG. BLUE VECTOR 346 DEG. 5-18 Samsung Electronics...
  • Page 49 1) VCR ÒPBÓ, Alignment tape (Lion pattern). 2) Viewfinder and VRE03. 3) Adjust the VRE03 so that the 3rd and 4th steps of the lion pattern can be distinguished. 2. V. Size 3. Bright 1. AFC EVF PCB (Component side) Samsung Electronics 5-19...
  • Page 50 CAMERA ADJUSTMENT mode has successfully EPR:XX EVR:XX been activated. Note : When ÒXX XXÓ is shown in service adjustment precedures, this indicates variable values. START/STOP BUTTON EJECT BUTTON DATE EJECT TITLE START/STOP P.AE <The location of RE51> FADE DISPLAY 5-20 Samsung Electronics...
  • Page 51 R SUB R-BRIGHT ADJUST B SUB B-BRIGHT ADJUST GAMMA 1 GAMMA1 GAIN FIXED GAMMA 2 GAMMA2 GAIN FIXED ADJUST MODE1 HD-TIME DELAY FIXED MODE2 SYSTEM SELECTION FIXED MODE3 H-POSITION FIXED Note : ÒXX XXÓ indicates variable values. Samsung Electronics 5-21...
  • Page 52 OSD state is Ò04 R SUB EPR:XX EVR:XXÓ. 5) Adjust the ÒD.ZOOM+/- (DATA UP/DOWN)Ó button so that R-OUT(Red) level is 8.0Vp-p. 6) Be sure to press the ÒDISPLAY(CONFIRM)Ó button to memorize setting. 7) The OSD shows ÒCONFIRM !Ó. 8.0V (RED LEVEL) 5-22 Samsung Electronics...
  • Page 53 5) Adjust the ÒD.ZOOM+/- (DATA UP/DOWN)Ó button so that the Yellow level is equal to the pedestal line. 6) Be sure to press the ÒDISPLAY(CONFIRM)Ó button to memorize setting. 7) The OSD shows ÒCONFIRM !Ó. PEDESTAL LINE YELLOW LEVEL Samsung Electronics 5-23...
  • Page 54 Test point and adjustment points : ADDRESS Adjustment name Test point Adjustment point Spec. 1.8 ± 0.1V DC BRIGHTNESS G-OUT 8.0Vp-p R-SUB BRIGHTNESS R-OUT 8.0Vp-p B-SUB BRIGHTNESS B-OUT 8.0Vp-p COLOR B-OUT B-OUT Test point ADJ. point CVF PCB (Component side) 5-24 Samsung Electronics...
  • Page 55 0:00:00 burst signal and ÒRedÓ signal is 0.30 : 0.66. The video signal ( color bars ) used for VCR block electrical adjustment are shown in figure 1. 0. EMPHA EPR:XX EVR:XX Samsung Electronics 5-25...
  • Page 56 UNLOADING OPEN COMMON GROUND IC601 30PIN IC601 29PIN IC601 28PIN LOADING EJECT UNLOADING PLAY LOADING STOP STOP IC601 IC601 IC601 POSITION Action Mode 30PIN 28PIN 29PIN EJECT EJECT UNLOADING STOP UNLOADING STOP LOADING STOP LOADING STOP PLAY,FF,REW,STILL... 5-26 Samsung Electronics...
  • Page 57 Audio block - See page 5-31 for the location of tests points and adjustments. 2. Press the ÒBLCÓ button of set for mode change. Note 4 : The OSD information. ÒXXÓ means arbitary values. It can be different number depend on the condition. 0. EMPHA EPR:XX EVR:XX Samsung Electronics 5-27...
  • Page 58 6) Be sure to press the ÒDISPLAY (CONFIRM)Ó button so that the TP203 is 4.38 ± 0.02MHz. button on unit to memorize setting. 6) Be sure to press the ÒDISPLAY (CONFIRM)Ó button on unit to memorize setting. 0.5 0.02Vp-p 5-28 Samsung Electronics...
  • Page 59 - When smaller than specified value : press the Ò- (DATA DOWN)Ó and then press the ÒDISPLAY (CONFIRM)Ó button. WHITE ( APPROX. 100% ) APPROX. WHITE ( APPROX. 100% ) 0.7V 1.0 0.05Vp-p APPROX. APPROX. 0.05Vp-p 0.7V 0.3V APPROX. 0.3V Samsung Electronics 5-29...
  • Page 60 0.5 ± 0.02Vp-p Y/C SEPARATION TP202 EVR data fixed Y-FM CARRIER FREQUENCY TP203 4.38 ± 0.02MHz Y-FM DEVIATION TP203 1.0 ± 0.05Vp-p REC Y LEVEL EVR data fixed PB OUTPUT LEVEL TP204 1.0 ± 0.05Vp-p Test point ADJ. point 5-30 Samsung Electronics...
  • Page 61 5) Press the Ò- (DATA DOWN)/ +(DATA UP)Ó button so that the output waveform is completed sine wave and the distortion is miniized. 6) Be sure to Press the ÒDISPLAY(CONFIRM)Ó button on unit to memorize setting. AUDIO OUTPUT DISTORTION MINIMIZE Test point Samsung Electronics 5-31...
  • Page 62 ÒXXÓ is different depend on the models as shown 5) Be sure to press the ÒDISPLAY (CONFIRM)Ó below. button on unit to memorize setting. NTSC - SCA20 : 20 - VP-A20 : 20 - SCA23 : 23 - VP-A22 : 22 - SCA25 : 25 - VP-A23 : 23 5) Be sure to press the ÒDISPLAY (CONFIRM)Ó...

  • Page 63: Exploded View And Parts List

    EVF (SC-A20) - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-14 CVF (SC-A23/A25) - - - - - - - - - - - - - - - - - - - - - - - 6-16 Samsung Electronics...

  • Page 64: Cabinet Assembly (1)

    Exploded View and Parts List 6-1 Cabinet Assembly (1) Samsung Electronics...
  • Page 65 Exploded View and Parts List Loc. No New Part No Description and Specification Remark AD98-11250F ASSY-CASE FRONT;SC-A23,- AD63-70068A SHEET-MIC;-,HIMERON,-,-,-,-,-,VP-A20 AD64-30930B CASE-FRONT;-,ABS,94HB,-,-,-,-,VP-A23 SCA23/25 only AD64-30930C CASE-FRONT;-,ABS,94V0,-,-,-,-,SC-A20 SCA20 only AD64-40676A WINDOW-REMOCON;-,PC,-,-,BLK,-,VP-A20 AD67-10191A LENS-HOOD;-,-,PC(BLK),-,-,-,VP-A20 AD90-10830Z ASSY-FRONT BOARD;VP-A20,FRONT(MOD) SCA23/25 only AD98-12024P ASSY-MIC;VP-A20,- AC63-30040A COVER-LI BATTERY;PP,HB,T1.5,BLK,H3.5,-,V AD61-30214A LOCKER-BATT EJECT;-,POM,-,BLK,-,VP-A20...

  • Page 66: Cabinet Assembly (2)

    Exploded View and Parts List 6-2 Cabinet Assembly (2) 127 128 Samsung Electronics...
  • Page 67 Remark AD64-30935A CASE-RIGHT;-,ABS94,HB,-,-,-,-,VP-A20 AC63-10007A GRIP-BELT ASSY;LEATHER,BLK,T1.5,-,SV-H66 AD61-22018A CAP-HOOD;-,ABS94,HB,-,-,VP-A20 AD61-20977A HOLDER-GRIP;-,PBT,-,BLK,-,VP-A57 AC61-20223A HOLDER-LOCK;SECC,T1.0,NAT,-,-,- AD60-10509A SCREW-TAP TITE;-,PWH,+,-,M2X5,5,- AD64-30936C CASE-REAR;-,ABS94,HB,-,-,-,-,SC-A23 SCA20/23 only AD64-30936D CASE-REAR;-,ABS94,HB,-,-,-,-,SC-A25 SCA25 only 66674-641-610 SPRING-KNOB POWER;SUS304 WPB AD59-10538A UNIT-REAR;VP-A20,- AD61-11038A BRACKET-REAR/RIGHT A;-,SECC,-,T0.6,-,-,V AD61-11039A BRACKET-REAR/RIGHT B;-,SECC,-,T0.6,-,-,V AD61-21087A HOLDER-POWER;-,POM,-,NTR,-,VP-A20 AD61-40419A STOPPER-POWER;-,ABS94,HB,-,-,VP-A20 AD61-60521A SPRING-REC;-,TS,SWPB,0.25,4.3,-,SC-80...

  • Page 68: Cabinet Assembly (3)

    Exploded View and Parts List 6-3 Cabinet Assembly (3) W501 W502 Samsung Electronics...
  • Page 69 Exploded View and Parts List Loc. No New Part No Description and Specification Remark AD96-10473H ASSY-8MM DECK;DE-6BNN,-” AD90-10829H ASSY-MAIN BOARD;SC-A23,NTSC” SCA23 only AD90-10823S ASSY-MAIN BOARD;SC-A20,NTSC” SCA20 only AD90-10833B ASSY-MAIN BOARD;SC-A25,NTSC” SCA25 only AD61-11036A CHASSIS-BOTTOM;-,STS,-,T0.6,-,-,VP-A20” AD61-11037A CHASSIS-TOP;-,STS,-,T0.6,-,-,VP-A20” AD98-11242F ASSY-CASE TOP;VP-A20,-” AD90-10826L ASSY-LENS;VP-A20/XEU,LENS”...

  • Page 70: Mechanical Parts (1)

    Exploded View and Parts List 6-4 Mechanical Parts (1) Samsung Electronics...
  • Page 71 Loc. No New Part No Description and Specification Remark AC60-12083A SCREW-MACHINE;B,BH,-,M1.7,L5,FE,WHT,-,- AD60-10500D SCREW-MACHINE;-,BWSH,+,UP,M2,L7,ZPCNYLOK AD60-10500E SCREW-MACHINE;-,BWSH,+,UP,M2,L5,ZPCNYLOK AC60-10017A SCREW-MACHINE;BH,+,M1.7,X3.5,FEFZY,SWCH1 AC60-12112A SCREW-BH;-,BH,+,M1.4,L2,- AC60-30015A WASHER-SLIT;ID 1.1,OD 2.6,T 0.4,POLYSLID AD96-10473P ASSY-HOUSING;DE-6B,- AD96-10473R ASSY-DRUM;DE-6B,NN-SS AC61-72009A CONTACT-EARTH BRUSH;SECC/PBSP/CR/C,-,-,- AD66-40153A ROLLER-IMP ASS’Y;-,YF-10,OD7,-,DE-6 AC63-32091A COVER-DRUM;DURACON(M90-44),-,-,-,-,-,DE- AC63-30009A COVER-REEL ASSY;ABS 95,HB,-,-,-,-,DE-6,- AC66-12035A IDLER-ASSY;-,-,DE-6 Samsung Electronics...

  • Page 72: Mechanical Parts (2)

    Exploded View and Parts List 6-5 Mechanical Parts (2) 6-10 Samsung Electronics...
  • Page 73 AC60-30017A WASHER-SLIT;ID 1,OD 2.6,T 0.4,POLYSLIDER AD31-12010A MOTOR-CAPSTAN;DE-6B SHS,-,- AC66-22123A GEAR-CAPSTAN(ASSY);-,-,-,-,-,DE-6 AC66-22124A GEAR-PULLEY(ASSY);-,-,-,-,-,DE-6 AC66-62001A BELT-TIMMING;POLYURETHAN,L137 T0.4,-,-,- AC66-32197A LEVER-CAM;SUS430-CP,T0.6,-,-,DE-6,- AC66-42005A ROLLER-CAM MAIN;SUS303,-,-,PI3.5X1.1 AC66-22092A GEAR-CAM MAIN;SUS304-CSP,M0.5,Z64,-,-,- AC66-82055A SLIDER-MAIN(ASSY);-,-,-,-,DE-6 AC66-32198A LEVER-EJECT;DURANEX #3300,-,-,-,DE-6,- AC34-22001C SWITCH-MODE ASSY;HMW0484-01WA,DE-6,-,-,- AC66-22126A GEAR-LOADING;DURACON(99-44),M0.4,Z37 WO, AC31-12001P MOTOR-LOADING ASSY;DE-6,-,- Samsung Electronics 6-11...

  • Page 74: Mechanical Parts (3)

    Exploded View and Parts List 6-6 Mechanical Parts (3) 6-12 Samsung Electronics...
  • Page 75 62724-0278-00 SPRING-REVIEW ARM;PS SUS304-WPB PI0.3 AC61-52014A POLE-BASE S(ASSY);ZDC2/SUS303,-,-,-,-,DE AC61-52015A POLE-BASE T(ASSY);ZDC2/SUS303,-,-,-,-,DE AC66-32221A BRAKE-SUB S(ASSY);-,-,-,-,DE-6,- AC66-12042A REEL-T(ASSY);-,-,-,DE-6 AC66-12041A REEL-S(ASSY);-,-,-,DE-6 AC66-32217A ARM-PINCH ROLLER(ASS;-,-,-,-,DE-6 AC66-32213A ARM-REVIEW ASSY;-,-,-,-,DE-6 AC66-32223A BRAKE-MAIN(T);DURACON(M904-44),-,-,-,-,- AC66-30120A BRAKE-SOFT T (ASSY);-,-,-,-,DE-6,- AC66-30093A ARM-TENSION (ASSY);SUS304-CSP POM FELT,- AC61-62022A SPRING-SOFT BRAKE(S);-,SUS304,-,-,-,-,- AC61-62023A SPRING-TENSION;-,SUS304-WPB,-,-,-,-,- Samsung Electronics 6-13...

  • Page 76: Evf (Sc-A20)

    Exploded View and Parts List 6-7 EVF (SC-A20) 6-14 Samsung Electronics...
  • Page 77 AD61-50725A GUIDE-EYE LENS;-,ABS94,HB,-,-,-,VP-A20 AD64-10845A KNOB-EVF;-,ABS94,HB,-,-,VP-A20 AD61-20918A CAP-FOCUS;-,MBR,-,BLK,-,VP-K70 AD64-30934A CASE-EVF R;-,ABS94,V0,-,-,-,-,VP-A20 AD64-30933B CASE-EVF L;-,ABS94,V0,-,-,-,COL,VP-A20 AC67-12070A LENS-EVF(MD);PMMA D19.1 ASP,-,-,-,-,- AD61-22017A HOLDER-EYE LENS A;-,ABS94,HB,-,-,VP-A20 AC90-10012V ASSY-CRT;CS96(SPORTS),- AD90-10828Y ASSY-EVF BOARD;A2-P/J,NT AC67-10066A LENS-EVF GJ;-,OPT,GRASS-F1,D11.5,-,CG819 AD61-21083A HOLDER-EYE LENS B;-,ABS94,HB,-,-,VP-A20 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB Samsung Electronics 6-15...

  • Page 78: Cvf (Sc-A23/A25)

    Exploded View and Parts List 6-8 CVF (SC-A23/A25) 6-16 Samsung Electronics...
  • Page 79 RUBBER-EYE CUP;SILICON,-,VP-A20,- AD61-50724A GUIDE-CAP;-,ABS94,HB,-,-,-,VP-A20 AD61-50725A GUIDE-EYE LENS;-,ABS94,HB,-,-,-,VP-A20 AD64-10845A KNOB-EVF;-,ABS94,HB,-,-,VP-A20 66463-605-910 LENS EVF;PMMA CLR AD61-21082A HOLDER-LENS;-,ABS94,HB,-,-,VP-A20/SEUK AD61-20918A CAP-FOCUS;-,MBR,-,BLK,-,VP-K70 AD64-30934A CASE-EVF R;-,ABS94,V0,-,-,-,-,VP-A20 AD90-10823T ASSY-CVF BOARD;A2-PJ,NTSC AD64-30933E CASE-EVF L;-,ABS94,V0,-,-,-,COL,SC-A23 SCA23 only AD64-30933F CASE-EVF L;-,ABS94,V0,-,-,-,COL,SC-A25 SCA25 only AD41-20301B FPC-CVF;POLYMIDE,T0.18,12P,VP-A57 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB Samsung Electronics 6-17...
  • Page 80 Exploded View and Parts List MEMO 6-18 Samsung Electronics...

  • Page 81: Electrical Parts List

    2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R722 2007-000462 R-CHIP;18ohm,5%,1/10W,DA,TP,2012 CP62 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R723 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608 CP63 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R725 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 CP64 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 R726 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608 CP65 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 R728 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608 CP66 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 R801 2007-000072 R-CHIP;47ohm,5%,1/16W,DA,TP,1608 CP67 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, Samsung Electronics...
  • Page 82 ICS01 AC14-12007X IC-LOGIC;TC4S66F,SSOP-5,5P RP63 2007-000096 R-CHIP;30Kohm,5%,1/16W,DA,TP,1608 ICS02 1201-000200 IC-OP AMP;3414,SOP,8P,173MIL,DUAL,-,PLAS RP65 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 ICS03 AC14-12007X IC-LOGIC;TC4S66F,SSOP-5,5P RP66 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608 ICS04 1201-000246 IC-OP AMP;3403,SOP,14P,173MIL,QUAD,20V/m RP67 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 ICZ01 AD14-10001N IC-LOGIC;KS7314X,QFP,80P RP68 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012 LP01 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm RP69 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 83 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608 C927 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R923 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 C928 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R924 2007-001695 R-CHIP;22Kohm,0.5%,1/16W,DA,TP,1608 C929 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1 R925 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 C930 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 R926 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 C931 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1 R927 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608 C932 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m R929 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 84 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 C552 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, R515 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608 C553 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, R516 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608 C554 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, R517 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 C555 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20 R518 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608 C601 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20 R519 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608 C602 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20 R523 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 85 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R660 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 C206 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20 R661 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 C207 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608, R662 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 C208 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,1608,1.6m R663 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 C209 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,- R664 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608 C212 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP R665 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 C214 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP Samsung Electronics...
  • Page 86 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608 C321 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1. R106 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608 C322 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1. R107 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608 C324 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1. R108 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 C325 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP R110 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 C326 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP R112 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608 C351 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T R113 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 87 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 R238 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 R239 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 R240 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 R243 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608 R244 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608 R246 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 R247 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608 R248 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608 R249 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 R250 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 R251 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608 R252 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 88 0504-000158 TR-DIGITAL;KSR2104,PNP,200MW,47K-47K,SOT AD90-10822G ASSY-TERMINAL;A2-P/J,SAMSUNG 0504-000158 TR-DIGITAL;KSR2104,PNP,200MW,47K-47K,SOT CN001 AD39-20826B LEAD CONNECTOR-ASSY;TP,51021,53023,7P,13 0504-000158 TR-DIGITAL;KSR2104,PNP,200MW,47K-47K,SOT D001 0402-001166 DIODE-RECTIFIER;RL203,200V,2.0A,DO-15,TP 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012 J001 AD37-22001B JACK-DC POWER;4.4MM,DDAE-9724,3P,BULK,BL 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012 JP001 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4mm,1/0.5 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012 PS001 3601-001089 FUSE-PC BOARD;125V,2A,SLOW-BLOW,CERAMIC, 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012 2007-000033 R-CHIP;0ohm,5%,1/8W,DA,TP,3216 Samsung Electronics...
  • Page 89 2007-000239 R-CHIP;1.5Kohm,1%,1/16W,DA,TP,1608 CE20 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 CE21 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP RE25 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608 CE22 2404-000204 C-TA,CHIP;3.3uF,20%,10V,-,3216,-,TP RE26 2007-000614 R-CHIP;24Kohm,1%,1/16W,DA,TP,1608 CE23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T RE27 2007-000683 R-CHIP;3.3Kohm,1%,1/16W,DA,TP,1608 CE25 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP RE28 2007-000067 R-CHIP;15Kohm,1%,1/16W,DA,TP,1608 CE26 2404-000251 C-TA,CHIP;470nF,20%,35V,-,3216,-,TP RE29 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 90 2801-003127 CRYSTAL-SMD;3.579545MHz,30ppm,28-ABN,16p AD90-10815L ASSY-B/L BOARD;SV-S99,NTSC CNE01 3711-002172 CONNECTOR-HEADER;BOX,3P,1R,1.5,STRAIGHT, FLE01 B4158-0033 LAMP;3AE4T4KL0502Y 5V 0.3W WHT QEB01 B4054-0053 FET;2SK1474-Z 20W 8A 100V MOS/N-CHANNEL AD90-10828Y ASSY-EVF BOARD;A2-P/J,NT SCA20 CE01 2203-000308 C-CERAMIC,CHIP;120PF,5%,50V,NPO,TP,1608, CE02 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20 CE03 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP CE04 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 CE05 2404-000175 C-TA,CHIP;2.2uF,20%,6.3V,WT,3216,1.1mm,T...
  • Page 91 Audio(Mono) - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-9 Camera Main/CCD - - - - - - - - - - - - - - - - - - - - - - - 8-10 Samsung Electronics...

  • Page 92: Block Diagrams

    Block Diagrams Overall Block Diagram (Camera) Samsung Electronics...

  • Page 93: Overall Block Diagram (Vcr)

    Block Diagrams Overall Block Diagram (VCR) Samsung Electronics...

  • Page 94: Dc/Dc Converter

    Block Diagrams DC/DC Converter Samsung Electronics...

  • Page 95: Drum Servo

    Block Diagrams Drum Servo Samsung Electronics...

  • Page 96: Capstan Servo

    Block Diagrams Capstan Servo Samsung Electronics...

  • Page 97: Video Playback

    Block Diagrams Video Playback Samsung Electronics...

  • Page 98: Video Record

    Block Diagrams Video Record Samsung Electronics...

  • Page 99: Audio(Mono)

    Block Diagrams Audio Samsung Electronics...

  • Page 100: Camera Main/Ccd

    Block Diagrams Camera Main/CCD 8-10 Samsung Electronics...
  • Page 101 CVF (SCA23/SCA25) - - - - - - - - - - - - - - - - - - - - - - EVF (SCA20) - - - - - - - - - - - - - - - - - - - - - - - - - - -...

  • Page 102: Pcb Diagrams

    PCB Diagrams Main (Component Side) Samsung Electronics...
  • Page 103 PCB Diagrams (Conductor Side) Samsung Electronics...

  • Page 104: Rear

    PCB Diagrams Rear (Component Side) (Conductor Side) Samsung Electronics...

  • Page 105: Front

    PCB Diagrams Front Terminal Samsung Electronics...

  • Page 106: Cvf (Sca23/Sca25)

    PCB Diagrams CVF (SCA23/SCA25) (Component Side) (Conductor Side) EVF (SCA20) (Component Side) (Conductor Side) Samsung Electronics...

  • Page 107: Ccd

    PCB Diagrams (Component Side) (Conductor Side) Samsung Electronics...
  • Page 108 PCB Diagrams MEMO Samsung Electronics...
  • Page 109 PCB Diagrams MAIN -2 ( COMPONENT - PATTERN ) Samsung Electronics...
  • Page 110 PCB Diagrams MAIN 2 (CONDUCTOR - PATTERN) 9-10 Samsung Electronics...
  • Page 111 PCB Diagrams CCD (pattern) (Component Side) (Conductor Side) Samsung Electronics 9-11...

  • Page 112: Wiring Diagram

    10. Wiring Diagram Samsung Electronics 10-1...
  • Page 113 Wiring Diagram MEMO 10-2 Samsung Electronics...

  • Page 114: Schematic Diagrams

    Adaptor - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11-14 11-14 Front - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Samsung Electronics 11-1...

  • Page 115: Block Identification Of Main Pcb

    Important safety notices : Components identified with the mark ! have the special characteristics for safety. When replacing any of these components. Use only the same type. 3 Block Identification of Main PCB (Component Side) (Conductor Side) 11-2 Samsung Electronics...

  • Page 116: Dc/Dc Converter

    Schematic Diagrams 11-1 DC/DC Converter Samsung Electronics 11-3...

  • Page 117: System Control/Servo

    Schematic Diagrams 11-2 System Control/Servo 11-4 Samsung Electronics...

  • Page 118: Video

    Schematic Diagrams 11-3 Video Samsung Electronics 11-5...

  • Page 119: Audio (Mono)

    Schematic Diagrams 11-4 Audio (Mono) 11-6 Samsung Electronics...

  • Page 120: Rear

    Schematic Diagrams 11-5 Rear Samsung Electronics 11-7...

  • Page 121: Terminal

    Schematic Diagrams 11-6 Terminal 11-8 Samsung Electronics...

  • Page 122: Camera Main/Eis

    Schematic Diagrams 11-7 Camera Main Samsung Electronics 11-9...

  • Page 123: Ccd

    Schematic Diagrams 11-8 11-10 Samsung Electronics...

  • Page 124: Evf(Sc-A20)

    Schematic Diagrams 11-9 EVF (SC-A20) Samsung Electronics 11-11...

  • Page 125: Cvf(Sc-A23/A25)

    Schematic Diagrams 11-10 CVF (SC-A23/A25) 11-12 Samsung Electronics...

  • Page 126: Adaptor

    Schematic Diagrams 11-11 Adaptor Samsung Electronics 11-13...

  • Page 127: Front

    Schematic Diagrams 11-12 Front 11-14 Samsung Electronics...
  • Page 128 Schematic Diagrams DRUM SPEED SERVO 11-2 System Control/Servo(11-4 Page RED) DRUM PHASE SERVO Samsung Electronics 11-15...
  • Page 129 Schematic Diagrams CAPSTAN SERVO (SPEED AND PHASE) 11-2 System Control/Servo (11-4 Page BLUE) CAPSTAN PHASE SERVO 11-16 Samsung Electronics...
  • Page 130 Schematic Diagrams DRUM SERVO (SPEED AND PHASE) 11-2 System Control/Servo (11-4 Page GREEN) Samsung Electronics 11-17...
  • Page 131 Schematic Diagrams ANALOG SIGNAL 11-7 Camera Main (11-9 Page RED) DIGITAL SIGNAL 11-18 Samsung Electronics...
  • Page 132 Schematic Diagrams 11-7 Camera Main (11-9 Page BLUE) Samsung Electronics 11-19...
  • Page 133 Schematic Diagrams 11-9 CCD (11-12 Page RED) CCD OUT 11-20 Samsung Electronics...
  • Page 134 Schematic Diagrams 11-9 CCD (11-12 Page BLUE) Samsung Electronics 11-21...
