Operator's Guide - OConnor 2575D Pan and Tilt Head
engages the camera mounting plate, the camera is captive, but not
locked.
Alternatively, press down and hold the red platform hook release lever
on the front left hand side of the head, and position the camera
mounting plate on top of the head. Release the red hook release lever
until the platform hook automatically secures the camera mounting
plate.
5. Engage the platform release lever by rotating it towards the platform
until the red safety catch engages.
6. Install the remainder of the payload (lens, zoom and focus controls,
viewfinder, prompter etc).

Stability

WARNING!
When mounting the head on a tripod, it is possible to set
the tripod legs so that the center of gravity of the tilted
payload falls outside the footprint of the tripod, leading to
instability.
Use the mid-level or floor spreader to ensure that the tripod legs are spread
sufficiently so that the center of gravity of the tilted payload remains within the
footprint of the tripod.
