Sub Assembly 2825R/26-400M-Dsp3, Front Panel Assembly - Amron Amcom II 2825R/24 Series User Manual

REF PART #
7 91A1AB24B15
10 1498-103
11 1498-102
12 1498-107
9 KLN-500B-1/4
16 LEDGREEN
17 LT2462-24-D51
15 LEDHOLDER-BLK.25
26 14003-1
27 450-0002-01
28 M3CA0208
29 14003-SD
9.5

Sub Assembly 2825R/26-400M-DSP3, Front Panel Assembly

REF PART #
1 2825R/24/26DSP3-001
3 SA818
4 SW-201
5 SW-208
23 SWB-0001
7 91A1AB24B15
15 LEDHOLDER-BLK.25
17 LT2462-24-D15
16 LEDGREEN
11 1498-102
10 1498-103
12 1498-107
13 14002B
14 14002R
9 KLN-500B-1/4
24 113-10K0-05
25 190-0500-15
26 14003-1
27 450-0002-01
28 M3CA0208
29 14003-SD
2825R-UM
2825R TWO DIVER RACK MOUNT COMMUNICATOR USER MANUAL
POTENTIOMETER 10K LINEAR
JACK BANANA BLACK
JACK BANANA RED
JACK BANANA YELLOW
KNOB BLACK AL .5DIA .25INSHAFT
LEDGREEN BRITE
LED BI-COLOR RED/GREEN
MOUNTING CLIP FOR 5MM LED
PANEL MIC
MEMBRANE FOR PANEL MIC
HOLDER FOR PANEL MIC
VINYL SEALING DISC FOR PANEL MIC
PANEL FRONT *** NOT FOR SALE ***
SPEAKER 8 OHM 15 WATT
SWITCH TOGGLE DPDT
SWITCH TOGGLE DPDT-MOM.
BOOT TOGGLE SOFT GRAY
POTENTIOMETER 10K LINEAR
MOUNTING CLIP FOR 5MM LED
LED BI-COLOR RED/GREEN
LEDGREEN BRITE
JACK BANANA RED
JACK BANANA BLACK
JACK BANANA YELLOW
5-WAY BINDING POST (BLACK)
5-WAY BINDING POST (RED)
KNOB BLACK AL .5DIA .25INSHAFT
POTENTIOMETER, 10K OHM
KNOB TURN COUNTING DIAL
PANEL MIC
MEMBRANE FOR PANEL MIC
HOLDER FOR PANEL MIC
VINYL SEALING DISC FOR PANEL MIC
42
DESCRIPTION
DESCRIPTION
REV 3.0
