INSTALLATION INSTRUCTION
Please read this instruction carefully before installation .
Extended wall plate for wall mounts with 16" wall
plate, fits wood stud spacing from 18" to 24".
Weight capacity: 70 kg (154 lbs) .
Thank you for purchase!We strive to provide products and services of exceptional quality.
We sincerely invite you to write a review with a good rating. For parts missed or installation problems,
please contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email
us by customerservice@mountingdream.com , so that we may solve the issue for you.
MODEL : MD5231
A3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD5231 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mounting Dream MD5231

  • Page 1 INSTALLATION INSTRUCTION MODEL : MD5231 Please read this instruction carefully before installation . Extended wall plate for wall mounts with 16" wall plate, fits wood stud spacing from 18" to 24". Weight capacity: 70 kg (154 lbs) . Thank you for purchase!We strive to provide products and services of exceptional quality.
  • Page 2 Avertissement de sécurité: bienvenue à choisir le support suspendu de téléviseur de la Vue Aérienne, pour garantir un usage sécurité du produit MD5231, préserver le risque contre vous-même et des tiers et éviter ledommage des biens, veuillez lire soigneusement ce manuel avant l'usage. Si vous ne pouvez pas comprendre cette notice ou en cas de doute sur la sécurité...
  • Page 3 Before getting started, let's make sure this mount is perfect for you! Is the width of your wall plate 16 inches? 16" Yes --- Perfect! No --- This mount is NOT compatible. Does your TV (including accessories) plus wall plate weigh more than 154 lbs (70kg)? NO --- Perfect! 154 lbs...
  • Page 4 For parts shortage or damage, please contact us directly by customerservice@mountingdream.com. Attention: New delivery will be timely arranged to replace missed or defective parts. Installation tools: Installation tools: Socket wrench Band tape Band tape 1/2"(13mm) Hammer Hammer Stud finder Pencil Pencil (7/32") Electrodrill...
  • Page 5 Step 1 Unfold the extension arms and fasten them by bolts (I) with Allen key (K). Step 2 Attach 16" wall plate to the wall plate unit, fasten them by using bolts (I) and washers (J) with Allen Key (K).
  • Page 6 Step 3 Wall plate installation in wood stud To avoid potential body injury or property damage: 1. Wall mount must be installed into wood stud's center, not drywall alone. 2. Drywall covering the wood stud must not exceed 16 mm (5/8 in.). 3.
  • Page 7 Product dimensions: 24" 18" 16" 25mm 40mm 641mm If you have any questions about the installation, please feel free to contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email us by customerservice@mountingdream.com . For more information, please visit our website:www.mountingdream.com...
