We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Contents
4
4
6
6
6
6
6
7
7
8
9
9
10
11
11
12
12
13
18
18
20
21
26
26
26
27
28
28
29
31
33
33
34
40
42
3
Advertisement
Table of Contents
Related Manuals for Smeg CS9IMXA
Summary of Contents for Smeg CS9IMXA
-
Page 1: Table Of Contents
5.1 Clearances above and around domestic appliances 5.2 Positioning 5.3 Electrical connection 5.4 For the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • The appliance must never be cleaned by unsupervised children. 1.1 General safety instructions • Have authorised persons carry out installation and assistance Risk of personal injury interventions according to the • During use the appliance and its standards in force. - Page 3 Instructions Risk of damaging the appliance • If cracks or fissures form, or if the glass ceramic cooking surface • Do not use abrasive or corrosive breaks, turn off the appliance detergents on glass parts (e.g. immediately. Disconnect the powder products, stain removers power supply and call Technical and metallic sponges).
-
Page 4: Identification Plate
Instructions 1.2 Identification plate 1.6 How to read the user manual • The identification plate bears the This user manual uses the following reading technical data, serial number and brand conventions: name of the appliance. Do not remove Instructions the identification plate for any reason. General information on this user 1.3 Manufacturer liability manual, on safety and final... -
Page 5: Description
Description 2 Description 2.1 General Description 1 Backguard 5 Seal 2 Cooktop 6 Door 3 Control panel 7 Fan 4 Oven light Rack/tray support frame shelf... -
Page 6: Cooking Hob
Description 2.2 Cooking hob Power draw in booster function Zone Outside diameter (mm) Max. power draw (W)* (W) * 1400 2200 1850 3000 2300 3700 2600 3700 Power levels are approximate and can vary according to the pan used or the settings made. •... -
Page 7: Control Panel
Description 2.3 Control panel 1 Cooking zone control knobs 5 Function knob Useful for controlling the cooking zones of The oven's various functions are suitable for the induction hob. different cooking modes. After selecting the required function, set the cooking Turn the knobs clockwise to adjust the temperature using the temperature knob. -
Page 8: Available Accessories
Description The appliance features shelves for Tray positioning trays and racks at different heights. The insertion heights are indicated from the bottom upwards (see 2.1 General Description). 2.5 Available accessories Some models are not provided Useful for collecting fat from foods placed with all accessories. -
Page 9: Use
3 Use Improper use Risk of damage to surfaces 3.1 Instructions High temperature inside the oven • Do not cover the bottom of the oven during use cavity with aluminium or tin foil sheets. Danger of burns • If you wish to use greaseproof paper, place it so that it will not interfere with the •... -
Page 10: First Use
Glass ceramic hob High temperature inside the oven during use 5. Place a pan full of water on each of the front cooking zones and switch them on to Danger of fire or explosion the maximum power setting for at least 30 •... -
Page 11: Using The Cooktop
3.4 Using the cooktop To see whether the pan is suitable, bring a magnet close to the bottom: if it is attracted, On first connection to the electrical the pan is suitable for induction cooking. If mains, an automatic check will be you do not have a magnet, you can put a carried out that will switch on all small amount of water in the pan, place it... - Page 12 Cookware recognition Limiting the cooking duration The hob has an automatic device which When there is no saucepan on a cooking zone or if the saucepan is too small, no limits the duration of use. If the cooking zone settings are not energy will be transmitted and the symbol changed, the maximum duration of will appear on the display.
- Page 13 Advice on energy-saving Power levels • The diameter of the base of the pan must The power in the cooking zone can be correspond to the diameter of the adjusted to various levels. The table shows cooking zone. the levels suitable for various types of cooking.
- Page 14 Heating accelerator Keep warm Each cooking zone is equipped The Keep warm function allows with a heating accelerator that you to keep cooked food hot. allows the maximum power to be delivered for a time that is To activate the Keep Warm function: proportional to the selected •...
- Page 15 Power control Controls lock The hob is fitted with a power control The controls lock is a device that module that optimises/limits consumption. If protects the appliance from the overall set power level exceeds the accidental or inappropriate use. maximum limit permitted, the electronic circuit board will automatically manage the 1.
-
Page 16: Using The Storage Compartment
3.5 Using the storage compartment Preheating stage There is a storage compartment located at Cooking functions are always preceded by the bottom of the cooker; this can be used a preheating stage, which allows the to store pans or metal objects required to appliance to heat up to cooking use the cooker. - Page 17 Small grill Fan forced Using only the heat released from The combination of the fan and the the central element, this function circular heating element allows you to grill small portions of (incorporated in the rear of the meat and fish for making kebabs, oven) allows you to cook different toasted sandwiches and any types foods on several levels, as long as...
-
Page 18: Cooking Advice
• With the Grill function, we recommend Vapour Clean that you turn the temperature knob to the This function makes cleaning easier maximum value near the symbol to using the steam produced by a optimise cooking. small quantity of water poured onto the appropriate groove placed on •... -
Page 19: Programmer Clock
Advice for defrosting and proving 3.8 Programmer clock • Place frozen foods without their packaging in a lidless container on the first shelf of the oven. • Avoid overlapping the food. • To defrost meat, use the rack placed on the second level and a tray on the first level. - Page 20 Timed cooking Setting the time Timed cooking is the function If the time is not set, the oven will which allows a cooking operation not switch on. to be started and then ended after a specific length of time set by the On the first use, or after a power failure, the user.
- Page 21 6. Press the clock key to reset the 5. Press the menu key . The text programmer clock. will appear on the display in sequence with the pre-set cooking It is not possible to set a cooking duration added to the current time (for time of more than 10 hours.
- Page 22 4. Press the value decrease key It is not possible to set a programmed cooking time of more turn the buzzer off. than 24 hours. The minute minder timer can be set from 1 minute to a maximum of 23 After setting, hold the menu key hours and 59 minutes.
- Page 23 Cooking information table Runner posi- Weight Temperature Food Function tion from the Time (minutes) (Kg) (°C) bottom Lasagne 3 - 4 Convection 220 - 230 45 - 50 Pasta bake 3 - 4 Convection 220 - 230 45 - 50 Roast veal Fan assisted/Fan forced 180 - 190...
-
Page 24: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance Cleaning the cooktop Smudges from aluminium-based pans can 4.1 Instructions be easily cleaned off with a cloth dampened in vinegar. Improper use After cooking, remove any burnt residues, Risk of damage to surfaces rinse with water and dry thoroughly with a clean cloth. -
Page 25: Removing The Door
Cleaning and maintenance Weekly cleaning 4.3 Removing the door For easier cleaning, the door can be Clean and maintain the cooktop once a removed and placed on a tea towel. week using an ordinary glass ceramic cleaning product. Always follow the To remove the door proceed as follows: manufacturer’s instructions. -
Page 26: Cleaning The Door Glazing
Cleaning and maintenance 3. Some models have an intermediate glass pane. Remove the intermediate glass pane by lifting it upwards. 4.4 Cleaning the door glazing The glass in the door should always be kept thoroughly clean. Use absorbent kitchen roll. In case of stubborn dirt, wash with a 4. -
Page 27: Vapour Clean
Cleaning and maintenance 6. Reposition the internal glass pane. Take 4.6 Vapour Clean care to centre and insert the 4 pins into Vapour Clean is an assisted their housings in the oven door by cleaning procedure which applying slight pressure. facilitates the removal of dirt. - Page 28 Cleaning and maintenance • Pour approximately 40 cc of water into Vapour Clean setting the tray. Make sure it does not overflow 1. Turn the function knob to the symbol out of the cavity. and the temperature knob to the symbol 2.
-
Page 29: Extraordinary Maintenance
Cleaning and maintenance 4.7 Extraordinary maintenance Replacing the oven light bulb Removing and installing the oven seal Live parts Danger of electrocution To remove the oven seal: • Unhook the clips in the 4 corners and in • Unplug the appliance. the centre, then pull the oven seal. - Page 30 Cleaning and maintenance 4. Slide out and remove the light bulb. What to do if... The appliance does not work. • The circuit breaker is faulty: look in the fuse box and check that the circuit breaker is in working order. •...
-
Page 31: Installation
Installation 5 Installation 5.1 Clearances above and around domestic appliances This appliance must be installed by an less than 600 mm above the highest authorised person in accordance with this part of the cooktop shall be protected instruction manual, AS/NZS 5601.1 – for the full width and depth of the Gas installations (installation and pipe cooking surface area in accordance... -
Page 32: Positioning
Installation 5.2 Positioning 3. Additional requirements for Freestanding and Elevated Cooking Heavy appliance Appliaces – (Measurements D & E) Danger of crush injuries Where D, the distance from the periphery of the nearest burner to a • Place the appliance into the piece of horizontal combustible surface is less furniture with the aid of a second person. - Page 33 Installation Dimensions General information This appliance may be installed next to walls, one of which must be higher than the worktop, at a minimum distance of 50 mm from the side of the appliance, as shown in figures A and C relative to the installation classes.
- Page 34 Installation Positioning and levelling Heavy appliance Risk of damage to the appliance • Insert the front feet first and then the rear ones. • After making the gas and electrical connections, screw on the four feet supplied with the appliance. B - Class 2 subclass 1 (Built-in appliance) The appliance must sit level on the floor to ensure stability.
- Page 35 Installation Assembling the backguard Fastening to the wall The backguard provided is an The anti-tip devices must be integral part of the product. It must installed in order to prevent the be fastened to the appliance prior appliance tipping over. to installation.
- Page 36 Installation 3. Assemble the fastening bracket. 5. Align the base of the fastening bracket with the ground and tighten the screws to fix the measurements. 6. Use 50 mm for the distance from the side of the appliance to the bracket 4.
- Page 37 Installation 7. Move the bracket onto the wall and Wall fixing mark the position of the holes to be 1. Turn the screw placed behind the drilled in the wall. cooktop near the gas connection. 8. After drilling the holes in the wall, use 2.
-
Page 38: Electrical Connection
Installation 5.3 Electrical connection 4. Mark the wall in the position where the hole is to be drilled. Power voltage Danger of electrocution • Have the electrical connection performed by authorised technical personnel. • Use personal protective equipment. • The appliance must be connected to earth in compliance with electrical system safety standards. - Page 39 Installation The appliance can work in the following The aforementioned power cables modes: are sized taking into account the • 220-240 V 2~ coincidence factor (in compliance with standard EN 60335-2-6). Replacement U-bolt 3 x 10 mm² three-core cable. • 3220-240 V 3~ 4 x 4 mm²...
-
Page 40: For The Installer
Installation Accessing the terminal board It is recommended to slacken off To connect the power supply cable, you the cable clamp screw before must access the terminal board on the rear installing the power supply cable. casing: 1. Remove the screws fastening the plate 4.
