- Page 1 K680W Fitting Kit Fitting Instructions for Basic Carrier Revision No: 2B...
- Page 2 Fitting Kit K680W MAX kgs (lbs) Nissan Pathfinder R51, 5dr SUV 05-12 75 kgs (165 lbs) Pathfinder R51, 5dr SUV 05-12 75 kgs (165 lbs) Pathfinder R51, 5dr SUV 05-12 75 kgs (165 lbs) Pathfinder R51, 5dr SUV 05-Sep 13...
-
Page 3: First Time Installation
Fitting Kit K680W First Time Installation Remove parts from inside the package and check. Contact your dealer if any parts are missing or damaged. Remove plastic screws as shown. Place bracket over holes. Fit the M6 socket head screw and M6 washer. - Page 4 Fitting Kit K680W Ensure the roof rack face towards the front of vehicle. Use keys to remove covers. While holding the key in the vertical position, pull the cover towards you to remove the cover. Repeat for all legs. Extend the leg out.
- Page 5 Fitting Kit K680W Remove as shown. Remove clamp from leg. Store items away in a safe place. Fitment Spacer 808A: Position as shown Repeat for all four positions.
- Page 6 Fitting Kit K680W Crossbars should be parallel to each other and sit perpendicular to the roof rails. Repeat on other crossbar. Place screw into position. Screw small end of M8 flange nut onto M8 screw approximately 3 turns. Repeat for all four positions.
- Page 7 Fitting Kit K680W Slide Hex Key back into position into one of the roof rack legs. Ensure the locks on the legs are in the locked position (horizontal). Slide cover into the leg, You will hear a 'click' when the cover is securely locked.
- Page 8 Fitting Kit K680W CAUTION: Recheck all fasteners immediately after a load is applied to the crossbars. Regularly check screws are tight.
-
Page 9: Maintenance
Fitting Kit K680W Maintenance Long loads should be secured with non- elastic straps to the front and rear of the vehicle. Objects with pointed ends (e.g. ski poles) should be carried with the pointed ends to the rear of the vehicle. - Page 10 Fitting Kit K680W Some glass/panoramic roofs and radio antennae may not be able to be used when the product is fitted. Do not modify this product. Refer to the maximum permitted load capacity specified in the fitting instructions. Do not exceed the vehicle manufacturers...
- Page 11 Fitting Kit K680W Pathfinder, 5dr SUV 05-12 (US) 390mm 1110mm 725mm 725mm 15 3/8ths" 43 11/16ths" 28 9/16ths" 28 9/16ths" Pathfinder, 5dr SUV 05-12 (ZA) 390mm 1110mm 725mm 725mm 15 3/8ths" 43 11/16ths" 28 9/16ths" 28 9/16ths" Pathfinder, 5dr SUV 05-12 (EU)
-
Page 12: Warranty And Disclaimer
Make a claim as soon as practicable by contacting the Whispbar dealer from whom you purchased the product, who will give you instructions on how to proceed. If you are unable to contact the Whispbar dealer, or the dealer is not able to remedy the defect, you should contact Yakima as soon as practicable at: Call: 0800 4776 722 (NZ) or 1800 143 548 (AU) Email: warranty@yakima.co.nz or warranty@yakima.com.au... - Page 13 Yakima or the Whispbar dealer will be borne by you. Following receipt of the product and purchase invoice or receipt, Yakima or the Whispbar dealer must inspect the product to determine whether the claim falls within the warranty. If: 4.1 the claim falls within the warranty, Yakima will remedy any defects in materials or workmanship becoming apparent during the...
