Summary of Contents for Iiyama ProLite LH6542UHS
- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor for signage. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
- Page 3 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL6542UH, PL7542UH, PL8642UH We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of different countries from there.
-
Page 4: Table Of Contents
CONTROLS AND CONNECTORS : REMOTE CONTROL ...13 PREPARING THE REMOTE CONTROL........14 ID REMOTE CONTROL ..............15 BASIC OPERATION ..............16 CONNECTING YOUR THE MONITOR : ProLite LH6542UHS ..19 CONNECTING YOUR THE MONITOR : ProLite LH7542UHS ..20 CONNECTING YOUR THE MONITOR : ProLite LH8642UHS ..21 COMPUTER SETTING ..............25 OPERATING THE MONITOR .............26... -
Page 5: For Your Safety
DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
-
Page 7: Special Notes On Lcd Monitors
SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitors and do not indicate a problem. NOTE - When you first turn on the LCD monitor, the picture may not fit in the display area because of the type of computer that is used. In this case, adjust the picture position to the correct position. - You may find slightly uneven brightness on the screen depending on the desktop pattern you use. - Page 8 1 hour and there is evidence of a residual or “ghost” image, you should turn off the monitor for 1 hour in order to clear the residual image. For all LFD products, iiyama recommends displaying moving images and utilising a moving screen saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not in use to assist the prevention.
-
Page 9: Customer Service
If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. For safety reasons, turn off the power switch and unplug the monitor before you CAUTION clean it. -
Page 10: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. Power Cable* ... -
Page 11: Unpacking
UNPACKING CAUTION Moving the monitor requires at least two people. If not, it may drop and could result in a serious injury. BEFORE YOU OPERATE THE MONITOR 7... -
Page 12: Controls And Connectors : Monitor
CONTROLS AND CONNECTORS : MONITOR <Back Controller> Power Button MUTE INPUT MENU MUTE Mute Button Input Select INPUT Button + Button - Button Up Button Down Button MENU Menu Button <Front> Lighting : Normal Operation Green Flash : When SCHEDULE is enabled. Power Indicator If turn off the Power Button on the Remote Control and the Back Controller. - Page 13 <Back> ProLite LH6542UHS ProLite LH7542UHS BEFORE YOU OPERATE THE MONITOR 9...
- Page 14 ProLite LH8642UHS AC SWITCH MAIN Main Power Switch (ON) / (OFF) POWER AC IN AC-INLET AC Connector( : Alternating current) (AC-IN) RS232C OUT Mini Jack RS232C Connector RS232C IN Mini Jack RS232C Connector IR OUT IR Connector IR IN IR Connector HDMI OUT HDMI HDMI Connector RJ45 RJ45 Connector...
-
Page 15: Installation
INSTALLATION CAUTION Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualified service personnel. Moving the monitor requires at least two people. Before installing, please make sure the wall is strong enough to hold the necessary weight of the monitor and the mount. - Page 16 [PLACING THE STICKERS] If you feel the screw holes are too visible in portrait mode, please use the stickers to cover them. ProLite LH6542UHS ProLite LH7542UHS ProLite LH8642UHS Screw holes : 13 Screw holes : 13 Screw holes : 17...
-
Page 17: Controls And Connectors : Remote Control
CONTROLS AND CONNECTORS : REMOTE CONTROL Turns the monitor ON and OFF. Control playback of media files. : Play : Stop [PLAY] : Pause : Quick-Return : Fast-Forward Selects the source. Press button to select from HDMI1, HDMI2, DVI-D, SOURCE DisplayPort, VGA, SDM, Media Player, Browser, iiSignage, PDF Player or Custom. -
Page 18: Preparing The Remote Control
PREPARING THE REMOTE CONTROL To use the remote control, insert the two dry batteries. CAUTION Do not use any other batteries other than those specified in this manual for the Remote Control. Do not insert old and new batteries together in the Remote Control. Make sure that the terminals match the "+" and "-" indications in the battery compartment. ... -
Page 19: Id Remote Control
NOTE Refer to the above instructions when taking out the batteries. Replace with new batteries when the Remote Control does not work close to the monitor. Use AAA dry batteries. Risk of explosion if battery is replaced by an incorrect type. ... -
Page 20: Basic Operation
BASIC OPERATION Turning the monitor ON [Remote Control] The monitor is turned On and the Power Indicator turns to Green when you press the POWER button on the monitor or the Remote Control. The monitor is turned Off and the Power Indicator turns to Red when you press the POWER button on the monitor or the Remote Control. - Page 21 Move the cursor vertically [Remote Control] Select adjustment by pressing the button on the monitor or the button on the remote control while the menu page is displayed on the screen. [Monitor] MUTE INPUT MENU Move the cursor horizontally [Remote Control] Select menu or setting, or perform the adjustment by pressing the + / - button on the monitor or the...
- Page 22 Adjust the volume of sound [Remote Control] Press the + / - button on the monitor or the remote control to adjust the volume of sound when the menu page is not displayed on the screen. [Monitor] MUTE INPUT MENU ...
-
Page 23: Connecting Your The Monitor : Prolite Lh6542Uhs
* Cable is not supplied with the monitor. If you use low quality Cable, it may cause a result of electro- magnetic interference. Please contact the iiyama Support Centre in your country if you wish to connect the monitor via the VGA or DVI input. -
Page 24: Connecting Your The Monitor : Prolite Lh7542Uhs
* Cable is not supplied with the monitor. If you use low quality Cable, it may cause a result of electro- magnetic interference. Please contact the iiyama Support Centre in your country if you wish to connect the monitor via the VGA or DVI input. -
Page 25: Connecting Your The Monitor : Prolite Lh8642Uhs
* Cable is not supplied with the monitor. If you use low quality Cable, it may cause a result of electro- magnetic interference. Please contact the iiyama Support Centre in your country if you wish to connect the monitor via the VGA or DVI input. - Page 26 Turn off the power switch and unplug the monitor and peripherals before connection to avoid electric shock or damage. NOTE Refer to the user manual of peripherals at the same time. Ensure you have the necessary cables as required. ProLite LH6542UHS ProLite LH7542UHS 22 BEFORE YOU OPERATE THE MONITOR...
- Page 27 ProLite LH8642UHS [ About the daisy chain ] Monitor control connection RS-232C MONITOR1 MONITOR2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] BEFORE YOU OPERATE THE MONITOR 23...
- Page 28 [ To setup the network ] 1. Switch on the router and switch on its DHCP setting. 2. Connect the router to this monitor with an Ethernet cable. 3. Press HOME button on the remote control, then select Setup. 4. Select "Connect to network", then press OK button. 5.
-
Page 29: Computer Setting
Change to the desired signal timing listed on page 55: COMPLIANT TIMING. Windows XP/Vista/7/8/8.1/10 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows XP/Vista/7/8/8.1/10 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 30: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 55. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 45 for SCREEN ADJUSTMENTS. - Page 31 NOTE The BACK button on the remote control or the + button on the monitor can be used to return previous menu item. Any changes are automatically saved in the memory when the On Screen Display disappears. Turning off the power should be avoided while using the Menu. Adjustments for H./V.
-
Page 32: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Picture Picture Brightness Screen Contrast Audio Sharpness Configuration1 Black level Configuration2 Tint Advanced option Color Noise reduction Medium Gamma selection Native Color temperature Native Color controal Action Smart power Overscan Adjustment Item Problem / Option Button to Press Too dark Brightness* Too bright... - Page 33 Picture Picture Contrast Screen Sharpness Audio Black level Configuration1 Tint Configuration2 Color Advanced option Noise reduction Medium Gamma selection Native Color temperature Native Color controal Action Smart power Overscan Picture reset Action Adjustment Item Problem / Option Button to Press Set user color.
- Page 34 Screen Picture H position Screen V position Audio Clock Configuration1 Clock Phase Configuration2 Zoom mode Full Advanced option Auto adjust Action Screen reset Action Adjustment Item Problem / Option Button to Press Too left H Position* Too right Too low V Position* Too high Too narrow...
- Page 35 Audio Picture Balance Screen Treble Audio Bass Configuration1 Volume Configuration2 Audio out (line out) Advanced option Maximum volume Minimum volume Mute Audio source Digital Audio reset Action Audio Out Sync Adjustment Item Problem / Option Button to Press Left side speaker is louder. Balance Right side speaker is louder.
- Page 36 Configuration1 Picture Switch on state Force on Screen Panel saving Action Audio RS232 routing RS232 Configuration1 Boot on source Action Configuration1 reset Configuration2 Action Advanced option Factory reset Action Adjustment Item Problem / Option Button to Press The monitor will remain off when the power cord is Power off connected to a wall outlet. The dmonitor will turn on when the power cord is Forced on Switch on state...
- Page 37 Set the period of time the information OSD is Information OSD displayed on the upper right corner of the screen. Off / 1 - 60 seconds iiyama Logo does not display when the monitor is turned on. Logo iiyama Logo displayed when the monitor is turned on.
- Page 38 Advanced option Picture IR control Unlock Screen Power LED Light Audio Keyboard control Unlock Configuration1 Off timer Configuration2 Date and time Action Advanced option Schedule Action Language English OSD transparency Mode1 Power Save SDM settings Auto Advanced option reset Action Adjustment Item Problem / Option Button to Press...
- Page 39 Advanced option Picture IR control Unlock Screen Power LED Light Audio Keyboard control Unlock Configuration1 Off timer Configuration2 Date and time Action Advanced option Action Schedule Language English OSD transparency Power Save Mode1 SDM settings Auto Advanced option reset Action Adjustment Item Problem / Option Button to Press...
- Page 40 Advanced option Picture IR control Unlock Screen Power LED Light Audio Keyboard control Unlock Configuration1 Off timer Configuration2 Date and time Action Advanced option Schedule Action Language English OSD transparency Power Save Mode1 SDM settings Auto Advanced option reset Action Adjustment Item Problem / Option Button to Press...
- Page 41 APPLICATION Press the HOME button and number 1668 on the remote control. OPERATING THE MONITOR 37...
- Page 42 The Boot Logo is only available when you select “User” of Logo function in the OSD menu "Configuration2". For details, refer to download the Custom Boot Animation manual on the IIYAMA web site. For details, refer to download the iiSignage manual on the IIYAMA web site.
- Page 43 When you change the system settings, a problem like options system instability may occur. In that case, contact your dealer or iiyama service center for assistance. System Main info in About: System updates / Android version / Kernel version / Build number About Automatically search update .zip from USB or SD card.
- Page 44 <Android> * Android upgrade is not available on this model. • Settings : Go to settings app. • Apps : Show all apps. (Browser/Chromium/iiSignage/File Manager/Media Player/PDF player/ Settings) • Network : Set Ethernet. • Storage : Display current Android storage information. Preparation for using Media Player and PDF Player ...
- Page 45 [Media Player] · Play: Select playlist to play · Compose: Edit playlist · Settings: Setting play properties Compose 1. Select "Compose" on the page. First you select one playlist to play between FILE1 and FILE7. 2. Select the file and select edit or delete. 3. Save the edited file. -videos in /signage/video/ -photos in /signage/photo/ -music in /signage/music/ 4.
- Page 46 Settings Select "Settings" on the page. • Repeat mode: Play mode. Repeat once: All files are repeated once. Repeat all: All files in the same folder play repeatedly. • Slideshow Effect: Photo slideshow effect. Right to left: Change from right to left sliding. Fold: Change by rotating horizontally in the center. Corner: Change by enlarging from the upper left corner to the lower right corner.
- Page 47 [PDF Player] Compose 1. Select "Compose" on the page. First you select one playlist to play between FILE1 and FILE7. 2. Select the file and select edit or delete. 3. Save the edited file. -pdfs in /signage/pdf/ Slide bar • Source: Select storage (USB/SD card) • Playlist: Show playlist (Internal) • Select all: Select all storage files. • Delete all: Delete playlist files. • Add/Remove: Update playlist from source. •...
- Page 48 When Ver.3, Server/Account/PIN code is available. To be able to use the functionality , please download the iiSignage Software and User Manual from our Website https://iiyama.com/iisignage iiSignage software is using the network Port: 9989 , future information are available in the...
-
Page 49: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama. com). Adjust the image by following the procedure below to get the desired picture. - Page 50 Adjust the Auto Adjustment. (Auto Adjust) Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust. Adjust the V.Position so that the top and bottom of the picture frame will fit to the display area.
- Page 51 Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. NOTE In case the strong flicker or blurs remain on a part of the screen, repeat steps because the Clock may not be adjusted correctly. Adjust the H.Position after the Phase adjustment if the horizontal position moves during the adjustment. Adjust the Brightness and Color to get the desired picture after you complete the Clock and Phase adjustments.
-
Page 52: Standby Feature
STANDBY FEATURE The standby feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a standby step the monitor takes as described below. -
Page 53: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 54: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com for monitor recycling. 50 RECYCLING INFORMATION... -
Page 55: Appendix
APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS : ProLite LH6542UHS Size Category 65" Panel technology Size Diagonal: 64.5" (164cm) Pixel pitch 0.372mm H × 0.372mm V Brightness 500cd/m (Typical) Panel Contrast ratio 1300 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time 9ms (Typical, Gray to Gray) Display Colors Approx.1.07 Billion VGA/DVI: Horizontal: 30.0-80.0kHz, Vertical: 50-75Hz Sync Frequency HDMI/DisplayPort: Horizontal: 30.0-135.0kHz, Vertical: 50-75Hz... -
Page 56: Specifications : Prolite Lh7542Uhs
SPECIFICATIONS : ProLite LH7542UHS Size Category 75" Panel technology Size Diagonal: 74.5" (189cm) Pixel pitch 0.429mm H × 0.429mm V Brightness 500cd/m (Typical) Panel Contrast ratio 1400 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors Approx.1.07 Billion VGA/DVI: Horizontal: 30.0-80.0kHz, Vertical: 50-75Hz Sync Frequency HDMI/DisplayPort: Horizontal: 30.0-135.0kHz, Vertical: 50-75Hz Native Resolution... -
Page 57: Specifications : Prolite Lh8642Uhs
SPECIFICATIONS : ProLite LH8642UHS Size Category 86" Panel technology Size Diagonal: 85.6" (217cm) Pixel pitch 0.4935mm H × 0.4935mm V Brightness 500cd/m (Typical) Panel Contrast ratio 1200 : 1 (Typical) Viewable angle Horizontal : 178 degrees, Vertical: 178 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors Approx.1.07 Billion VGA/DVI: Horizontal: 30.0-80.0kHz, Vertical: 50-75Hz Sync Frequency HDMI/DisplayPort: Horizontal: 30.0-135.0kHz, Vertical: 50-75Hz Native Resolution... -
Page 58: Dimensions : Prolite Lh6542Uhs
DIMENSIONS : ProLite LH6542UHS 1062.0mm/41.8” 4xM8 SCREW HOLE 1462.5mm/57.6” (VESA MOUNT) 1432.5mm/56.4” 400.0mm/15.7” 106.0mm/4.2” DIMENSIONS : ProLite LH7542UHS 1360.0mm/53.5” 4xM8 SCREW HOLE 1683.5mm/66.3” (VESA MOUNT) 1653.5mm/65.1” 600.0mm/23.6” 97.0mm/3.8” 54 APPENDIX... -
Page 59: Dimensions : Prolite Lh8642Uhs
DIMENSIONS : ProLite LH8642UHS 1360.0mm/53.5” 4xM8 SCREW HOLE 1929.0mm/75.9” (VESA MOUNT) 1898.0mm/74.7” 600.0mm/23.6” 94.5mm/3.7” COMPLIANT TIMING Timing VGA 640x480 31.5 60.0 25.175 SVGA 800x600 37.9 60.0 40.000 XGA 1024x768 48.4 60.0 65.000 WXGA 1280x768 47.8 60.0 79.500 QVGA 1280x960 60.0 60.0 108.000 SXGA 1280x1024...
