Summary of Contents for Iiyama Pro Lite LH3275HS
- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor for signage. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for your...
- Page 3 CE MARKING DECLARATION OF CONFORMITY This LCD monitor complies with the requirements of the EC/EU Directive 2014/53/EU “RED Directive”, 2009/125/EC “ErP Directive” and 2011/65/EU “RoHS Directive”. The electro-magnetic susceptibility has been chosen at a level that gives correct operation in residential areas, business and light industrial premises and small-scale enterprises, inside as well as outside of the buildings.
- Page 4 Compatible with IEEE 802.11ax standard, providing wireless data rate up to 1201Mbps. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: https://iiyama.com You can access the Web page of different countries from there.
-
Page 5: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............5 CLEANING ..................5 BEFORE YOU OPERATE THE MONITOR ..........6 FEATURES..................6 CHECKING THE CONTENTS OF THE PACKAGE ......7 UNPACKING ...................7 CONTROLS AND CONNECTORS..........8 INSTALLATION ................13 FUNCTIONS OF THE REMOTE CONTROL ........16 PREPARING THE REMOTE CONTROL........17 ID REMOTE CONTROL ..............18... -
Page 6: For Your Safety
DO NOT PUT ANY OBJECT INTO THE MONITOR Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fire, electric shock or damage. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located. Please also ensure that you do not place any heavy objects on the monitor, and that all cables are routed such that children may not pull the cables and possibly cause injury.
-
Page 8: Special Notes On Lcd Monitors
SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitors and do not indicate a problem. NOTE - When you first turn on the LCD monitor, the picture may not fit in the display area because of the type of computer that is used. In this case, adjust the picture position to the correct position. - You may find slightly uneven brightness on the screen depending on the desktop pattern you use. - Page 9 1 hour and there is evidence of a residual or “ghost” image, you should turn off the monitor for 1 hour in order to clear the residual image. For all LFD products, iiyama recommends displaying moving images and utilising a moving screen saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not in use to assist the prevention.
-
Page 10: Customer Service
If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. For safety reasons, turn off the power switch and unplug the monitor before you CAUTION clean it. -
Page 11: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR FEATURES Supports Resolutions up to 1920 × 1080 : ProLite LH3275HS Supports Resolutions up to 3840 × 2160 : ProLite LH4375UHS / ProLite LH5075UHS / ProLite LH5575UHS / ProLite LH6575UHS / ProLite LH7575UHS / ProLite LH8675UHS ... -
Page 12: Checking The Contents Of The Package
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. Power Cable (2pcs)* ... -
Page 13: Controls And Connectors
CONTROLS AND CONNECTORS <Front> Normal Operation Lighting : Standby Mode Flash : 3-second intervals : Signal Standby Mode Power Indicator 5-second intervals : Network Standby Mode 7-second intervals : When SCHEDULE is enabled. Power Off Remote Sensor Remote Sensor LED color Status Description Lights off... - Page 14 <Back> ProLite LH3275HS ProLite LH4375UHS / ProLite LH5075UHS BEFORE YOU OPERATE THE MONITOR 9...
- Page 15 ProLite LH5575UHS ProLite LH6575UHS 10 BEFORE YOU OPERATE THE MONITOR...
- Page 16 ProLite LH7575UHS / ProLite LH8675UHS BEFORE YOU OPERATE THE MONITOR 11...
- Page 17 AC Connector( : Alternating current) AC IN AC-INLET ) (AC-IN) AC SWITCH MAIN POWER Main Power Switch (ON) / (OFF) RJ45 RJ45 Connector AUDIO OUT ø 3.5mm Mini Jack Headphone Connector DisplayPort IN DisplayPort DisplayPort Connector DisplayPort OUT DisplayPort DisplayPort Connector HDMI1 IN HDMI HDMI Connector...
-
Page 18: Installation
INSTALLATION CAUTION Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualified service personnel. Moving the monitor requires at least two people. Before installing, please make sure the wall is strong enough to hold the necessary weight of the monitor and the mount. - Page 19 [PLACING THE STICKERS] If you feel the screw holes are too visible in portrait mode, please use the stickers to cover them. ProLite LH3275HS ProLite LH4375UHS ProLite LH5075UHS ProLite LH5575UHS Screw holes : 4 Screw holes : 5 Screw holes : 7 Screw holes : 7 14 BEFORE YOU OPERATE THE MONITOR...
- Page 20 ProLite LH6575UHS ProLite LH7575UHS ProLite LH8675UHS Screw holes : 7 Screw holes : 16 Screw holes : 20 : 13 : 18 BEFORE YOU OPERATE THE MONITOR 15...
-
Page 21: Functions Of The Remote Control
FUNCTIONS OF THE REMOTE CONTROL Turns the display ON and OFF. Control playback of media files. : Play : Stop [PLAY] : Pause Fast-Rewind : Fast-Forward Selects the source. Press button to select from HDMI1, HDMI2, HDMI3*, DisplayPort, SDM*, SOURCE Browser, CMS, File Manager, Media Player, PDF Player or Custom. -
Page 22: Preparing The Remote Control
PREPARING THE REMOTE CONTROL To use the remote control, insert the two dry batteries. CAUTION Do not use any other batteries other than those specified in this manual for the Remote Control. Do not insert old and new batteries together in the Remote Control. Make sure that the terminals match the "+" and "-" indications in the battery compartment. ... -
Page 23: Id Remote Control
NOTE Refer to the above instructions when taking out the batteries. Replace with new batteries when the Remote Control does not work close to the monitor. Use AAA dry batteries. Risk of explosion if battery is replaced by an incorrect type. ... -
Page 24: Basic Operation
BASIC OPERATION Turning the monitor ON The monitor is turned On and the Power Indicator turns Transparent when you press the POWER button on the monitor or the Remote Control. The monitor is turned Off and the Power Indicator turns to Red when you press the POWER button on the monitor or the Remote Control. Press again to turn On the monitor. - Page 25 Move the cursor horizontally Select menu or setting, or perform the adjustment by pressing the button on the remote control while the menu page is displayed on the screen. Adjust the volume of sound Press the + / - button on the remote control to adjust the volume of sound when the menu page is not displayed on the screen.
-
Page 26: Connecting Your Monitor : Prolite Lh3275Hs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. -
Page 27: Connecting Your Monitor : Prolite Lh4375Uhs / Prolite Lh5075Uhs / Prolite Lh5575Uhs / Prolite Lh6575Uhs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. -
Page 28: Connecting Your Monitor : Prolite Lh7575Uhs / Prolite Lh8675Uhs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. - Page 29 [ Connection example with the peripheral device ] CAUTION Turn off the power switch and unplug the monitor and peripherals before connection to avoid electric shock or damage. NOTE Refer to the user manual of peripherals at the same time. Ensure you have the necessary cables as required. ProLite LH3275HS ProLite LH4375UHS ProLite LH5075UHS...
- Page 30 ProLite LH7575UHS ProLite LH8675UHS [ About the daisy chain ] * Not available for ProLite LH3275HS Monitor control connection RS-232C MONITOR1 MONITOR2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] Digital video connection DisplayPort MONITOR1 MONITOR2 [DP] [DP IN] O ...
-
Page 31: Computer Setting
[ To setup the network ] 1. Switch on the router and switch on its DHCP setting. 2. Connect the router to this monitor with an Ethernet cable. 3. Press HOME button and 1668 on the remote control, then select Settings. 4. -
Page 32: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 63. You are also able to adjust the picture by following the button operation shown below. -
Page 33: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Picture Picture Brightness Contrast Sharpness Black level Tint Color Noise redution Gamma selection NATIVE Adjustment Item Problem / Option Button to Press Too dark Brightness* Too bright Too dull Contrast* Too intense Too soft Sharpness* Too sharp Black is too dark Black level* Black is too bright... - Page 34 Picture Picture Black level Tint Color Noise reduction Gamma selection NATIVE Color temperature NATIVE Color control Action Picture reset Action Adjustment Item Problem / Option Button to Press Set user color. User1 Too weak Color control* Too strong User2 2000K-10000K Return to Menu.
- Page 35 Screen Screen Zoom mode Full Custom zoom Action Screen reset Action Adjustment Item Problem / Option Enlarge the picture horizontally to fill the screen if the picture source is 4:3 (standard definition). When the Full picture source is 16:9 (high definition), it is not scaled. Display all pictures in 4:3 aspect ratio. Zoom mode* Display the picture dot by dot. Real 21:9 Display all pictures in 21:9 aspect ratio. Custom Customize zoom screen.
- Page 36 Audio Audio Balance Treble Bass Volume Audio out(line out) Maximum volume Minimum volume Mute Adjustment Item Problem / Option Button to Press Left side speaker is louder. Balance Right side speaker is louder. Too weak Treble Too strong Too weak Bass Too strong Too soft...
- Page 37 Configuration1 Configuration 1 Android launcher Action Switch on state Force On Panel saving Action RS232 routing RS232 Boot on source Action Configuration1 re.. Action Factory reset Action Adjustment Item Problem / Option Android launcher Enable Android launcher in settings to access feature. The monitor will turn on when the power cord is connected Forced on to a wall outlet.
- Page 38 Set the period of time the information OSD is Information OSD displayed on the upper right corner of the screen. Off / 1 - 60 seconds iiyama Logo and animation does not display when the monitor is turned on. iiyama Logo and animation display when the monitor is Logo and animation turned on.
- Page 39 Configuration2 Configuration 2 Animation setting Action Monitor ID Group ID Monitor information Action DP version 1.2MST DP Monitors HDMI version Auto Configuration2 reset Action Adjustment Item Problem / Option Set the version of the HDMI. HDMI version* 2.0 / 1.4 / Auto Cancel Return to Menu.
- Page 40 Advanced option Advanced Option No signal image Action IR control Action Power LED light Tiling Action Off timer Schedule Action HDMI with One Wire HDMI with One Wire powe.. Adjustment Item Problem / Option Button to Press Customize the image for the no signal screen. Image / Office metting guide / Title / Room / Date & Time / Duration (30 No signal image mins / 1h / 1.5h / 2h / 2.5h / 3h / off) / Text color (White / Black) / Show...
- Page 41 Advanced option Advanced Option No signal image Action IR control Action Power LED light Tiling Action Off timer Schedule Action HDMI with One Wire HDMI with One Wire powe.. Adjustment Item Problem / Option Frame compensation. Enable is turned off. Frame comp. Enable Enable Frame compensation. Enable is turned off.
- Page 42 Advanced option Advanced Option No signal image Action IR control Action Power LED light Tiling Action Off timer Schedule Action HDMI with One Wire HDMI with One Wire powe.. Adjustment Item Problem / Option Set when turn off the monitor. Off Timer Off / 1 - 24 hours Up to 7 schedules can be set. Schedule list Start time * Set start time.
- Page 43 Advanced option Advanced Option HDMI with One Wi.. Auto signal detection Action Language English OSD transparency Power saving Mode 1:WOL off, source i.. Auto power off SDM settings Auto Advanced option reset Action Adjustment Item Problem / Option Button to Press English Deutsch German...
- Page 44 APPLICATION Press the HOME button and number 1668 on the remote control. Browser File Manager MediaPlayer ESharePro Settings Apps Network Storage OPERATING THE MONITOR 39...
- Page 45 <Settings> Network & internet Network & internet Wi-Fi Ethernet Ethernet is disabled Hotspot Adjustment Item Problem / Option Set the wifi function Enable / disable and pairing to WiFi device. Wifi list Display a list of WiFi networks Network name Add network Security Wi-Fi Advanced options Turn on wifi automatically Notify for public networks Wifi preferences...
- Page 46 Apps & Notification Apps & notifications App info 17 apps installed Default apps Opera Permission manager Control app access to your data Adjustment Item Problem / Option App info Display all applications. Browser app Default apps Home app Set the default apps. Opening links Premission manager App permissions...
- Page 47 Signage display Signage display General settings display name, screen shot Server settings email notification, FTP, ADB over network Source settings edit media player, edit browser player, edit pdf player, custom app Network application proxy, OTSP network port System tools clear storage, reset import&export, clone, external storage System updates OTA, local update Adjustment Item...
- Page 48 Security Security Device admin apps No active apps Unknown sources Allow installation of apps from all sources Adjustment Item Problem / Option Device admin apps Display credential storage information. Unknown sources Disable / Enable installation of apps from unknown sources. System System Languages &...
- Page 49 About device About device Legal information Model LH5075UHS-B1AG Android version Build number t7_an400_arm64-userdebug11 RQ3A.210805.001.A1 eng.yangpe.20220812.144633 test-keys Build version V00.05 Adjustment Item Problem / Option Third-party licenses Legal information System Webview licenses Model Model Serial number Main info in About: Legal / Model / Android Hardware version version / Build number / Build version Android version...
- Page 50 <Android> * Android upgrade is not available on this model. • Settings : Go to settings app. • Apps : Show all apps. (Browser/File Manager/CMS/Media Player/ESharePro) • Network : Set Ethernet. • Storage : Display current Android storage information. NOTE Supported file system: FAT32 Supported file format:...
- Page 51 [Media Player] · Play file: Select the file to play · Play order: Set the play order of the files · Play mode: Set the playback mode · Picture style: Set the picture size · Create list: Create a new playlist · Play list: Edit playlist Play file 1. Select "Play file" on the page. 2. Select the file and press OK button. Multiple files can be selected. 3. Press the "Open" button to play. ...
- Page 52 Edit bar • Move up: Move the files to the top of the list. • Move down: Move the files to the bottom of the list. • Delete: Delete files. • Delete all: Delete all playlist files. • Back: Return. Remote control • Option key: Display edit bar • OK key: Select / deselect file Play list 1. Select "Play list" on the page. 2.
- Page 53 [PDF Player] Play file 1. Select "Play file" on the page. 2. Select the file and press OK button. Multiple files can be selected. 3. Press the "Open" button to play. Media Hotkey • Play: To play the PDF file. Pause: To pause the PDF file. • • Stop: Return. Arrow key • : Previous page • : Next page Play order Select "Play order" on the page. •...
- Page 54 Edit bar • Move up: Move the files to the top of the list. • Move down: Move the files to the bottom of the list. • Delete: Delete files. • Delete all: Delete all playlist files. • Back: Return. Remote control • Option key: Display edit bar • OK key: Select / deselect file [File Manager] Browse the files stored in the internal storage, USB and SD card. [EShare Pro] EShare is a multiscreen interaction application which makes the user experience natural and enjoyable for home entertainment, business presentation, and educational training.
-
Page 55: Standby Feature
STANDBY FEATURE This product features the standby function. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. There is a standby step the monitor takes as described below. The standby function, including any timer settings is configured by the operating system. Check your operating system manual for information on how this can be configured. -
Page 56: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 57: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: https://iiyama.com for monitor recycling. 52 RECYCLING INFORMATION... -
Page 58: Appendix
APPENDIX Design and specifications are subject to change without prior notice. SPECIFICATIONS : ProLite LH3275HS-B1AG Size Category 32" Panel technology IPS (In-Plane-Switching) Size Diagonal: 31.5" (80cm) Pixel pitch 0.12125mm H × 0.36375mm V Brightness 500cd/m (Typical), 300cd/m (Default / Energy Saving) Panel Contrast ratio 1200 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 8ms (Typical, Gray to Gray) -
Page 59: Specifications : Prolite Lh4375Uhs-B1Ag
SPECIFICATIONS : ProLite LH4375UHS-B1AG Size Category 43" Panel technology IPS (In-Plane-Switching) Size Diagonal: 42.5" (108cm) Pixel pitch 0.2451mm H × 0.2451mm V Brightness 500cd/m (Typical), 300cd/m (Default / Energy Saving) Panel Contrast ratio 1200 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors... -
Page 60: Specifications : Prolite Lh5075Uhs-B1Ag
SPECIFICATIONS : ProLite LH5075UHS-B1AG Size Category 50" Panel technology Size Diagonal: 49.5" (125.7cm) Pixel pitch 0.285375mm H × 0.285375mm V Brightness 500cd/m (Typical), 300cd/m (Default / Energy Saving) Panel Contrast ratio 5000 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 9.5ms (Typical, Gray to Gray) Display Colors... -
Page 61: Specifications : Prolite Lh5575Uhs-B1Ag
SPECIFICATIONS : ProLite LH5575UHS-B1AG Size Category 55" Panel technology IPS (In-Plane-Switching) Size Diagonal: 54.6" (139cm) Pixel pitch 0.315mm H × 0.315mm V Brightness 500cd/m (Typical), 300cd/m (Default / Energy Saving) Panel Contrast ratio 1200 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors... -
Page 62: Specifications : Prolite Lh6575Uhs-B1Ag
SPECIFICATIONS : ProLite LH6575UHS-B1AG Size Category 65" Panel technology IPS (In-Plane-Switching) Size Diagonal: 64.5" (164cm) Pixel pitch 0.372mm H × 0.372mm V Brightness 500cd/m (Typical), 310cd/m (Default / Energy Saving) Panel Contrast ratio 1200 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors... -
Page 63: Specifications : Prolite Lh7575Uhs-B1Ag
SPECIFICATIONS : ProLite LH7575UHS-B1AG Size Category 75" Panel technology IPS (In-Plane-Switching) Size Diagonal: 74.5" (189cm) Pixel pitch 0.4296mm H × 0.4296mm V Brightness 500cd/m (Typical), 305cd/m (Default / Energy Saving) Panel Contrast ratio 1200 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors... -
Page 64: Specifications : Prolite Lh8675Uhs-B1Ag
SPECIFICATIONS : ProLite LH8675UHS-B1AG Size Category 86" Panel technology IPS (In-Plane-Switching) Size Diagonal: 85.6" (217cm) Pixel pitch 0.4935mm H × 0.4935mm V Brightness 500cd/m (Typical), 285cd/m (Default / Energy Saving) Panel Contrast ratio 1400 : 1 (Typical) Viewable angle Horizontal : 89 degrees, Vertical: 89 degrees (Typical) Response time 8ms (Typical, Gray to Gray) Display Colors... -
Page 65: Dimensions : Prolite Lh3275Hs
DIMENSIONS : ProLite LH3275HS 4xM4 SCREW HOLE (VESA MOUNT) 725.5mm/28.6” 54.0mm/2.1” 698.5mm/27.5” 10.0mm/0.4” 200.0mm/7.9” 320.5mm/12.6” 62.5mm/1.7” DIMENSIONS : ProLite LH4375UHS 4xM6 SCREW HOLE (VESA MOUNT) 968.0mm/38.1” 54.0mm/2.1” 200.0mm/7.9” 941.0mm/37.1” 10.0mm/0.4” 419.5mm/16.5” 64.5mm/2.5” 60 APPENDIX... -
Page 66: Dimensions : Prolite Lh5075Uhs
DIMENSIONS : ProLite LH5075UHS 4xM6 SCREW HOLE (VESA MOUNT) 55.0mm/2.2” 1122.5mm/44.2” 1096.0mm/43.2” 11.0mm/0.4” 400.0mm/15.7” 499.0mm/19.7” 62.5mm/2.7” DIMENSIONS : ProLite LH5575UHS 4xM6 SCREW HOLE (VESA MOUNT) 1237.5mm/48.7” 55.0mm/2.2” 1209.5mm/47.6” 11.0mm/0.4” 400.0mm/15.7” 100.0mm/3.9” 75.0mm/3.0” 555.0mm/21.9” 63.5mm/2.5” APPENDIX 61... -
Page 67: Dimensions : Prolite Lh6575Uhs
DIMENSIONS : ProLite LH6575UHS 1456.5mm/57.3” 56.0mm/2.2” 4xM8 SCREW HOLE 1428.5mm/56.2” 12.0mm/0.5” (VESA MOUNT) 400.0mm/15.7” 100.0mm/3.9” 75.0mm/3.0” 662.5mm/26.1” 65.5mm/2.6” DIMENSIONS : ProLite LH7575UHS 1359.0mm/53.5” 1679.5mm/66.1” 4xM8 SCREW HOLE 1649.5mm/64.9” (VESA MOUNT) 600.0mm/23.6” 100.0mm/3.9” 75.0mm/3.0” 66.5mm/2.6” 62 APPENDIX... -
Page 68: Dimensions : Prolite Lh8675Uhs
DIMENSIONS : ProLite LH8675UHS 1652.0mm/65.0” 4xM8 SCREW HOLE 1927.0mm/75.9” (VESA MOUNT) 1895.0mm/74.6” 100.0mm/3.9” 600.0mm/23.6” 75.0mm/3.0” 66.5mm/2.6” COMPLIANT TIMING Timing VGA 640x480 31.5 60.0 25.175 SVGA 800x600 37.9 60.0 40.000 XGA 1024x768 48.4 60.0 65.000 QVGA 1280x960 64.0 60.0 108.000 SXGA 1280x1024 64.0 60.0 108.000...
