High Resolution Weatherproof

IR Camera

User Manual

SCO-6085R

Need help?

Do you have a question about the SCO-6085R and is the answer not in the manual?

Questions and answers

Summary of Contents for Wisenet SCO-6085R

Page 1 High Resolution Weatherproof IR Camera User Manual SCO-6085R...
Page 2 High Resolution Weatherproof IR Camera User Manual Copyright ©2019 Hanwha Techwin Co., Ltd. All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
Page 3 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
Page 4 safety information 6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water on top of the camera. doing so may cause personal injury due to fire, electric shock, or falling objects. 7. Do not install the unit in humid, dusty, or sooty locations. doing so may cause fire or electric shock.
Page 5 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.
Page 6 important safety instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat.
Page 7 WARNING • To prevent damage which may caused by IR LED, don't stare at operating lamp. for below models only. SCO-6085R* Risk Group 1 WARNING IR emitted from this product. Do not stare at operating lamp.
Page 8 contents INTRODUCTION Features Components and Accessories Component names and functions CONNECTION Connecting to Monitor Connecting to Power Using Coaxial Communications CAMERA OPERATION Menu Configuration Menu Setup TROUBLESHOOTING Troubleshooting SPECIFICATIONS Specifications Dimension 8_ contents...
Page 9 introduction FEATURES y High Resolution Use of a 2 mega pixel CMOS device provides clear pictures with a resolution of 1920x1080. y Excellent Sensitivity - Color : 0.11Lux (F1.6, 1/30sec) B/W : 0Lux(IR LED on) y SSNR4 Function High performance DSP Chip removes noises of GAIN resulting from the low light level and shows a vivid, high definition video even in the dark place.
Page 10 introduction COMPONENTS AND ACCESSORIES Check if the following items are included in the product package. Camera Quick Manual Screws Card-type moisture Template Wrench absorbent 10_ introduction...
Page 11 COMPONENT NAMES AND FUNCTIONS Front Camera Sunshield Knob Sunshield : Fixing the sunshield onto the camera. Focus lever : Set focus of lens by turn the focus lever. Zoom lever : Set zoom magnification of lens by turn the zoom lever. Front cover Function Setup Switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item.
Page 12 introduction Back Function jack (ALARM OUT, GND) VIDEO OUTPUT jack : Video signals are output through this port. Connect this port to the Video IN port of a AHD DVR. Power input terminal : Connect the power as specified for each model here. 12_ introduction...
Page 13 Adjust the lens’s zoom and focus 1. Remove the sunshield from the camera. 2. Remove the front cover from the camera by turning it counterclockwise. 3. Unlock the Zoom or Focus lever before adjusting the lens. 4. Adjust the zoom & focus by moving the lever counterclockwise for (NEAR & WIDE) and clockwise for (TELE &...
Page 14 connection CONNECTING TO MONITOR Connect the Video OUT port on the rear panel of the camera to a AHD DVR. ALARM NETWORK BACKUP POWER AHD DVR Monitor y As the connecting method varies with the instruments, refer to the manual supplied with the instrument.
Page 15 When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm Resistance value(Ω/m) 0.084 0.053 0.033 0.021 Voltage Drop (V/m) 0.045 0.028 0.017 0.011 y As shown in the table above, voltage decreases as the wire gets longer. Therefore use of an excessively long adaptor output line for connection to the camera may affect the performance of the camera.
Page 16 connection : BNC ● - Video Cable The camera's video output port is connected to the DVR with a BNC coaxial cable, shown below. Recommended Cable Distance Specification 500m 5C2V It is recommended that pure copper coax cable is used and not copper coated steel, as this will cause issues with the communication over the coaxial cable.
Page 17 camera operation MENU CONFIGURATION MAIN SETUP VIDEO FORMAT ◦ ◦ CVBS ◦ ◦ ◦ BASIC DAY/NIGHT BACKLIGHT PROFILE ◦ ◦ ◦ INDOOR USER D-WDR ◦ ◦ ◦ ◦ ◦ INDOOR OUTDOOR WHITE BAL ◦ ◦ AWC → SET MANUAL ◦ ◦...
Page 18 camera operation MAIN SETUP  1. VIDEO FORMAT Select the Change the status 2. PROFILE function using BASIC using the Function the Function 3. D-WDR Setup switch. Setup switch. 4. WHITE BAL 5. EXPOSURE 6. BACKLIGHT 7. SPECIAL 8. EXIT SAVE 1.
Page 19 PROFILE 1. When the SETUP menu screen is MAIN SETUP displayed, select ‘PROFILE’ by using 1. VIDEO FORMAT the Function Setup switch so that the  2. PROFILE BASIC arrow indicates ‘PROFILE’ . 3. D-WDR 2. Select a desired mode using the 4.
Page 20 camera operation D-WDR When there are both bright and dark areas at the same time, this mode makes both areas distinctive. 1. When the SETUP menu screen is displayed, select ‘D-WDR’ by using the Function Setup switch so that the arrow indicates ‘D-WDR’ . 2.
Page 21 Select one of the following 5 modes, as appropriate for your purpose.  y ATW : Select this when the color temperature is between 1,800K and 10,500K. y OUTDOOR : Use it in a color temperature range of 1,800K to 10,500K.(including Natrium).
Page 22 camera operation EXPOSURE 1. When the SETUP menu screen is displayed, select ‘EXPOSURE’ by using the Function Setup switch so that the arrow indicates ‘EXPOSURE’ . 2. Select a desired mode using the EXPOSURE SETUP Function Setup switch. BRIGHTNESS  IIIIIIIIII IIIIIIIIII y BRIGHTNESS : Adjusts the video...
Page 23 y AGC (OFF/LOW/MIDDLE/HIGH/VERY HIGH) : The higher the gain level, the brighter the screen - but the greater the noise. y SSNR4 : This function reduces the background noise in a low luminance environment. - OFF : Deactivates SSNR4. Noise is not reduced. - ON : Activates SSNR4 so that noise is reduced.
Page 24 camera operation If the white balance menu is set to manual, then HLC performance can be limited. If you use the defog and HLC functions at the same time, saturation can occur in a bright environment. Because there can be a difference in the effectiveness of HLC according to the amount of light area in the screen, optimize the installation angle for the best HLC performance.
Page 25 Enter a title, move the cursor to ‘POS’ and press the ➎ Function Setup switch. The entered title appears on FRONT DOOR the screen. Select the position to display the title on the screen by using the Function Setup switch and press the Function Setup switch.
Page 26 camera operation - SHARPNESS : Select a mode to adjust the thickness of an image’s sharpness. Increase or decrease the level of each mode to adjust the level of sharpness. y OFF : Released state y ON : The setting range is 1 ~ 32. - RETURN : Return to the SPECIAL menu.
Page 27 If you set the AGC mode to off on the exposure menu, you cannot switch the day/night mode to auto. When a bright light source is in the screen or there are frequent brightness changes, if you use the auto night/day mode, and set the switching time to short (3, 5 sec), a hunting can be caused.
Page 28 camera operation y PRIVACY: Mask an area you want to hide on the screen. If the SPECIAL menu screen is ➊ PRIVACY AREA displayed, use the Function Setup ▶ AREA AREA switch so that the arrow indicates MODE ‘PRIVACY’ . MASK COLOR GREEN Select a desired mode using the...
Page 29 y ALARM OUT : When object ALARM OUT movement is EXTERNAL ▶ detected, the detection signal RETURN will be outputted. ` EXTERNAL : Send signals through external terminals. ` OSD : Display signals on the screen. ` RETURN : Return to the MOTION DET menu. y SENSITIVITY : Set the sensitivity of the motion detection.
Page 30 camera operation EXIT Select a desired EXIT mode using the Function Setup switch depending on the camera purpose. y SAVE : Save the current settings and exit the MAIN SETUP menu. y NOT SAVE : Do not save the current settings and exit the MAIN SETUP menu. y RESET : Revert camera to factory settings.
Page 31 troubleshooting TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. y Check that the power cord and line connection between the camera and monitor are properly connected.
Page 32 specifications SPECIFICATIONS SCO-6085RN/SCO-6085RP Video Imaging Device 1/2.8” 2M CMOS Effective Pixels 1945(H)x1097(V) Color : 0.11Lux (F1.6) (30IRE) Min. Illumination B/W : 0Lux(IR LED on) Video Output BNC(AHD / CVBS Selectable) Resolution 1920 x 1080 Max, Framerate 30fps @1080p(N), 25fps @ 1080p(P) Lens Type Focal Length (Zoom Ratio) 3.2~10mm(3.1x) manual varifocal Max.
Page 33 SCO-6085RN/SCO-6085RP Coaxial Protocol ACP(AHD Coax Protocol), CVBS: Pelco-C(Coaxitron) Video Transmission 500m(5C2V Coaxial Cable) Distance Environmental Operating Temperature / -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH Humidity Certification IP66, IK10 Electrical Input Voltage 24VAC, 12VDC 24VAC : Max 5.4W typical 3.4W Power Consumption 12VDC : Max 5.4W...
Page 34 DIMENSION Unit: mm (inch) 34_ specifications...
Page 35 MEMO...
Page 36 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
