Summary of Contents for Wisenet SNC-79447BW
- Page 1 1080p Wireless IR Camera User Manual SNC-79447BW...
- Page 2 5M AHD Analog Bullet Camera User Manual Copyright ©2019 Co., Ltd. All rights reserved. Hanwha Techwin Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
-
Page 3: Important Safety Instructions
overview IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth. (Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents as they may deform or cause damage to the product.) Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. -
Page 4: Safety Precautions
overview SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit. - Page 5 CAUTION Do not drop objects on the product or apply strong shock to it. Keep away from a location subject to excessive vibration or magnetic interference. Do not install in a location subject to high temperature, low temperature, or high humidity. Doing so may cause fire or electric shock.
-
Page 6: Table Of Contents
overview CONTENTS OVERVIEW Important Safety Instructions Safety Precautions Contents Part Names and Functions INSTALLATION Precautions Installing the camera Protection of Cable from Water Connecting the NVR APPENDIX Product Specification Product Overview 6_ overview... -
Page 7: Part Names And Functions
PART NAMES AND FUNCTIONS Equipped with the IR LED lights and the illumination sensor, the camera enables you to monitor at all times, day and night. The camera is suitable for both indoor and ourtdoor use. Do not fully expose the camera to rain. The camera must be installed under a shelter to avoid exposure to excessive rain or moisture. -
Page 8: Precautions
installation PRECAUTIONS Ensure you read out the following instructions before installing the camera: • Select an area (ceiling or wall) that can withstand 5 times the camera weight • Stuck-in or peeled-off cables can cause damage to the product or a fire. •... -
Page 9: Protection Of Cable From Water
PROTECTION OF CABLE FROM WATER If this product is mounted outdoor, water leakage may occur at gap between cables. As shown below, butyl rubber (available on the market) shall be used to protect from water. 1. Connect power supply and BNC power source. 2. -
Page 10: Product Specification
appendix PRODUCT SPECIFICATION Item Details Video Imaging Device 2M CMOS Sensor SP2309 Effective Pixels 1920x1080p (2MP) Scanning System Progressive Horizontal Resolution 1080P Min. Illumination 0 Lux (IR LED ON) Camera Output Wireless transmission Lens Focal Length 4 mm Max. Aperture Ratio F2.4 Angular Field of View D : 105°... -
Page 11: Product Overview
PRODUCT OVERVIEW unit : mm(inch) 67.5 (2.66˝) 133.6 (5.26˝) 124.6 (4.9˝) English _11... - Page 12 Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 13 FCC / Industry Canada RF Exposure Statement -For This device must not be co-located or operation in conjunction with any other antenna or transmitter except complying with IC multi-transmitter requirements. -For camera This equipment complies with FCC / IC radiation exposure limits set forth for an uncontrolled environment.
- Page 14 Tel : +82.1588.5772 Fax : +82.31.8018.3740 www.wisenetlife.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Tel +1.844 WISENET (844.947.3638) E-mail : cs@wisenetlife.com www.wisenetlife.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom Tel : 00800.8010.8022 / +31.(0)13.5792.790...
