PFS
C
FMI CATALYTIC FIREPLACE SCAT36 SERIES
36" WOOD BURNING OUTDOOR FIREPLACE
These models meet the EPA Wood Burning Fireplace
Program Phase 2 emission level. NOTE: To ensure proper
fireplace operation, the catalyst should be replaced at a
minimum of 3 years and a maximum of 5 years.
f i r e - p a r t s . c o m
This book is valuable. In addition to instructing you
on how to install and maintain your appliance, it also
contains information that will enable you to obtain re-
placement parts or accessory items when needed. Keep
it with your other important papers.
This fireplace is approved for use as a wood burning fire-
place or for use with a vented gas log approved to ANS
Z21.60 and Z21.84 standards or for use with a vent-free gas
log heater approved to ANS Z21.11.2 standard. A FMI PROD-
UCTS, LLC hood must be installed when using a vent-free
log heater (see Accessories, page 21).
This wood burning fireplace complies with UL127-
CAN/ULC-S610-M87 standard as a FACTORY BUILT
FIREPLACE.
FOR CANADA: The authority having jurisdiction (such
as the municipal building department, fire department,
etc.) should be contacted before installation to deter-
mine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
CATALYTIC FIREPLACE OWNER'S
OPERATION AND INSTALLATION MANUAL
®
US
SAVE THIS BOOK
For more information, visit www.fmiproducts.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FMI SCAT36 Series
Summary of Contents for FMI SCAT36 Series
- Page 1 ANS Z21.60 and Z21.84 standards or for use with a vent-free gas log heater approved to ANS Z21.11.2 standard. A FMI PROD- UCTS, LLC hood must be installed when using a vent-free log heater (see Accessories, page 21).
-
Page 2: Table Of Contents
Before beginning installation of this fireplace, • Due to high temperatures, the read these instructions through completely. appliance should be located • This FMI PRODUCTS, LLC fireplace and out of traffic and away from its components are safe when installed furniture and draperies. -
Page 3: Specifications
SPECIFICATIONS GAS LINE RIGHT SIDE KNOCK ELECTRICAL OUTS OUTLET 1" AIRSPACE TO COMBUSTIBLE MATERIAL 0" TO NO COMBUSTIBLE 9.125" 3.5" MATERIAL ON FACE SPACERS 7.092" 8.717" AIR KIT 11.217" KNOCK OUT LEFT SIDE GAS LINE KNOCK COMBUSTIBLE OUTS WALL BOARD 0.75"... -
Page 4: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION 2. If fireplace is to be installed directly on carpeting, tile (other than ceramic) or any To determine safest and most efficient location combustible material other than wood for fireplace, you must take into consideration flooring, fireplace must be installed upon the following guidelines: a metal or wood panel extending full width 1. - Page 5 FIREPLACE INSTALLATION DRAIN PAN (DP36) WARNING: Hearth extension For outdoor installations, the fireplace enclo- is to be installed only as shown sure must allow for adequate drainage and in Figure 3. fresh air ventilation. It is recommended that a sealed, corrosion resistant catch pan with provision for drainage be installed under the Seal Gap fireplace within the fireplace enclosure (see...
-
Page 6: Venting Installation
CHIMNEY PIPE space (AK4F) or through a sidewall (AK4). FMI PRODUCTS, LLC chimney system See Figure 23 on page 15 for instruction of consists of 12", 18", 24", 36" and 48" snap- operating air kit. - Page 7 VENTING INSTALLATION Continued Secure to Collars with Metal Tape, Screws " or Straps (Min. of 1/4" x 20" in size) Galvanized Outer Pipe Air Inlet Hemmed Location Must Allow 8" Stainless For Bushes Inner Pipe or Snow LINEAL GAIN PART NO. DESCRIPTION GAIN 36"...
- Page 8 VENTING INSTALLATION Continued Continue to assemble chimney sections as 2. Chimney weight above offset rests on outlined, making sure that both inner and return elbow. Straps must be securely outer pipe sections are locked together. When nailed to rafters or joists (see Figure 9, installing double wall snap-lock chimney to- details A and B on page 9).
- Page 9 VENTING INSTALLATION Continued See Detail A Ceiling Support Pipe 12S-8DM 2" Min. See Detail B Straps Straps Straps Straps Detail A Detail B Return Elbow Angle Firestop Figure 9 - Ceiling Support Pipe 12S-8DM OFFSET RISE CHIMNEY LENGTH f i r e - p a r t s . c o m 48"...
- Page 10 VENTING INSTALLATION Continued FIRESTOP SPACERS (3600FS-8DM-1) 4. Remove shingles around opening mea- sured. Cut out this section. Firestop spacers are required at each point 5. Add next sections of pipe until end where chimney penetrates a floor space. penetrates roof line. Check to see that Their purpose is to establish and maintain proper clearances are maintained.
- Page 11 VENTING INSTALLATION Continued Terminations with 16" slip pipe sections are Overlap Storm Collar Shingles Top available. RTT-8DM, RTTL-8DM and RLTT- Flashing and Sides Only 8DM are approved for flashing installations. Cone When needed, these adjustable terminations Nail Only may be used in combination with pipe assem- Outer bly to achieve correct chimney height.
- Page 12 VENTING INSTALLATION Continued Level of Flue Gas Outlet 18" Min. 2' Min. Typ. 3' Min. 2' Min. 3' Min. 24" Min. Figure 18 - 10 Foot Rule 24" Min. FINISHING THE FIREPLACE Combustible materials, such as wallboard, gypsum board, sheet rock, drywall, plywood, Figure 17 - Multiple Chase Installation etc.
-
Page 13: Purefire Installation
PUREFIRE HOOD INSTALLATION 1. The PureFire hood supplied with this fire- Hood Refractory place is packaged in a separate box and Retainer placed in the firebox during shipping. 2. Remove hood from box. 3. Lift the hood up into the fireplace at an angle with the rear facing up. -
Page 14: Operation And Maintenance
PERSON. has been used for wood burn- ing, firebox and chimney must Note: A FMI PRODUCTS, LLC hood must be be cleaned of soot, creosote and installed when using an unvented gas log set f i r e - p a r t s . c o m ashes be a qualified chimney (see Accessories on page 21). - Page 15 Pushing handle in will lock door closed. WARNING: Risk of fire! Re- place grate with FMI PRODUCTS, Doors Fully Closed LLC model 125186-02 only. This grate has been designed to keep...
-
Page 16: Hearthcat™Emissions Control System
* EPA has determined, based on testing by an accredited independent laboratory and a certification of conformity by a nationally recognized certification body, that this model qualifies at the Phase 2 cardboard or salt driftwood. emissions level for U.S. EPA's Voluntary Fireplace Program. 125574-04 Refer to your FMI PRODUCTS, LLC Home- www.fmiproducts.com 125866-01A... - Page 17 Under normal operating condi- f i r e - p a r t s . c o m Neither FMI PRODUCTS, LLC nor the dealer tions, you should see little or no smoke coming who sells the PureFire Emissions Control out of the chimney.
-
Page 18: Parts
PARTS WOOD BURNING FIREPLACE MODELS (V)SCAT36, (V)SCAT36R, (V)SCAT36H AND (V)SCAT36HR f i r e - p a r t s . c o m 37/38 www.fmiproducts.com 125866-01A... - Page 19 PARTS WOOD BURNING FIREPLACE MODELS (V)SCAT36, (V)SCAT36R, (V)SCAT36H AND (V)SCAT36HR This list contains replaceable parts used in your fireplace. When ordering parts, see Replace- ment Parts on page 21 of this manual. NO. PART NO. DESCRIPTION QTY. Insulation Pan Fireplace Top Fireplace Surround 106642-01 Air Rod Retainer...
- Page 20 PARTS WOOD BURNING FIREPLACE MODELS (V)SCAT36, (V)SCAT36R, (V)SCAT36H AND (V)SCAT36HR This list contains replaceable parts used in your fireplace. When ordering parts, see Replace- ment Parts on page 21 of this manual. Right Side Rear Bottom Front Bottom Left Side REFRACTORY BRICK NO.
-
Page 21: Replacement Parts
When calling or writing, please have your broken component, please do not return it model and serial numbers of your fireplace to the store. Call FMI PRODUCTS, LLC at ready. 1-866-328-4537 to answer questions and Model and serial number information are in the replace parts under warranty. - Page 22 ACCESSORIES Continued STORM COLLAR SC1-1 SQUARE TOP TERMINATION WITH LOUVERS ET-8DM, ET-8HT SQUARE TOP TERMINATION WITH LOUVERS AND SLIP SECTION ANTI-DRAFT SHIELD ETL-8DM, ETL-8HT (Round Top Termination Only) ADS-8DM MESH SQUARE TOP TERMINATION ETO-8DM MESH SQUARE TOP TERMINATION WITH SLIP SECTION f i r e - p a r t s .
-
