RESIDENTIAL AND OUTDOOR WOOD BURNING FIREPLACE
OWNER'S OPERATION AND INSTALLATION MANUAL
PFS
®
C
US
ICC-ES #ESR-2542
MODELS (V)S36 SERIES
SAVE THIS BOOK
This book is valuable. In addition to instructing you
on how to install and maintain your appliance, it also
contains information that will enable you to obtain re-
placement parts or accessory items when needed. Keep
it with your other important papers.
-
place or for use with a vented gas log approved to ANS
Z21.60 or Z21.84 standards or for use with a vent-free
gas log heater approved to ANS Z21.11.2 standard. A FMI
PRODUCTS, LLC hood must be installed when using a
vent-free log heater (see Accessories, page 16).
APPLIANCE.
FOR CANADA: The authority having jurisdiction (such
etc.) should be contacted before installation to deter-
mine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.fmiproducts.com
