Introduction - Vertex Standard VXR-7000 Operating Manual

The VXR-7000 is commercial quality 50-watt FM repeater designed to provide reliable, continuous-duty two-way
communications over a wide range of environmental conditions.
Designed to be a stylish base station, with high-grade components utilized throughout, the VXR-7000 utilizes the
latest computer-aided design and manufacturing processes to ensure a high level of reliability for users. Important
channel frequency data is stored in EEPROM, and is easily programmable by a Servicing Technician or Dealer using
an IBM compatible personal computer and the VPL-1 Programming Cable and CE27 Software.
Please take a few minutes to read this manual carefully. The information presented here will allow you to derive
maximum performance from your VXR-7000. After reading it, keep this manual handy for quick reference, in case
questions arise later on.
Important Note: Internal service work, programming, and accessory installations should only be performed by your
authorized Vertex Standard Dealer. Dangerous conditions and/or possibly illegal operation may result from improper
setup, programming, or internal modifications.
To comply with FCC RF exposure compliance requirements, the following antenna installation and device operat-
ing configurations must be satisfied:
The device is to be installed and operated at a "fixed location." The term "fixed location" means that the device is
physically secured at one location and is not able to be easily moved to another location. The antenna system to be
used with this device must be installed outdoors, on a permanent structure, such that a minimum separation of 6
meters (19.7 feet) is maintained from any area where persons may be walking, sitting, and/or working.
If the above antenna requirements are followed, this FCC device is considered categorically excluded from routine
RF exposure evaluation for demonstrating compliance.
The installer of the antenna to be used with this device may be required to perform an MPE evaluation and an
Environmental Assessment (EA) of the location at the time of licensing per CFR 47 Part 1.1307. Fixed mounted
antennae that are co-located with other antennae must satisfy the co-location requirements of Part 1.1307.
Important Notice for North American Users Regarding 406 MHz Guard Band
The U.S. Coast Guard and National Oceanographic and Atmospheric Administration have requested the coopera-
tion of the U.S. Federal Communications Commission in preserving the integrity of the protected frequency range
406.0 to 406.1 MHz, which is reserved for use by distress beacons. Do not attempt to program this apparatus,
under any circumstances, for operation in the frequency range 406.0 - 406.1 MHz if the apparatus is to be used in
or near North America.
VXR-7000 FM R
EPEATER
IMPORTANT NOTICE
O M
PERATING ANUAL

Introduction

1
