0 to ±30v, 1 mhz variable-gain linear amplifier

Table of Contents

The Model AV-110D-PS variable-gain linear amplifier accepts input voltages in the

range of 0 to ±2V, and has a variable gain of 0 to +15 (or ±15 on units with the -INV

option). The maximum output voltage is ±30V. The AV-110D-PS will drive load

impedances of 50 Ω or higher. The amplifier bandwidth is 1 MHz.

This model is available with the following options:

-D Option:

Dual channel option. Adds a second independent amplifier channel.

-INV Option: Adds an inverting mode, in addition to the standard non-inverting mode.

-OS Option: Allows an internally generated 0 to ±15V DC offset to be added to the

output.

-XOS Option: Allows an internally generated 0 to ±30V DC offset to be added to the

output.

INTRODUCTION
