Page 1
Especially, please read all of the information on page 3, 4, 5 for your safety. Please keep this manual in an easily accessible place and refer to it anytime. VK73******* www.lg.com Made in Korea MFL68700108...
Table of contents Important safety instructions ................3~5 How to use ...................... 6~21 Assembling vacuum cleaner ..................6~7 Operating vacuum cleaner ....................8 Using carpet and floor nozzle / Hard floor nozzle ............. 9 Using carpet master nozzle and mini turbine nozzle ............10 Using 2 in 1 nozzle ......................
2. Children should be supervised to ensure that they do not play with the appliance. 3. If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard 4. This appliance can be used by children aged from 8...
Page 4
Personal injury or product damage could result. Personal injury or product damage could result. In these cases, contact LG Electronics Service Agent to • Keep children away and beware of obstructions avoid hazard. when rewinding the cord to prevent personal injury.
Page 5
• Only use parts produced or recommended by LG been given supervision or instruction concerning Electronics Service Agents. use of the appliance by a person responsible for Failure to do so could result in product damage.
How to use Assembling vacuum cleaner Hose handle (depend on model) Spring latch Telescopic pipe (depend on model) (depend on model) (depend on model) (depend on model) (depend on model) ➊ Carpet and floor nozzle (depend on model) ➋ Telescopic pipe Push the telescopic pipe into the nozzle.
Page 7
Click! Button Fitting pipe Flexible hose Attachment point ➌ Connecting the hose to the vacuum cleaner Push the fitting pipe on the flexible hose into the attachment point on the vacuum cleaner. To remove the flexible hose from the vacuum cleaner, press the button situated on the fitting pipe, then pull the fitting pipe out of the vacuum cleaner.
How to use Operating vacuum cleaner Plug Cord reel button Regulator MAX line ➊ How to operate ➋ Emptying the dust tank ➌ Park mode ➍ Storage • Pull out the power • Always empty the • To store during •...
How to use Using carpet and floor nozzle / Hard floor nozzle Carpet Pedal Floor ➊ Carpet and floor nozzle(depend on model) ➋ Hard floor nozzle (depend on model) • The 2 position nozzle • Efficient cleaning of hard floors This is equipped with a pedal which allows you to (wood, linoleum, etc) alter its position according to the type of floor to be...
How to use Using carpet master nozzle and mini turbine nozzle Air regulator Cleaning carpet master Long carpet Open Short carpet Bottom two position ➌ Carpet master (depend on model) ➍ Mini turbine nozzle (depend on model) • Cleaning turbine brush nozzle. •...
How to use Using 2 in 1 nozzle Upholstery nozzle Dusting brush ➎ Upholstery nozzle(depend on model) ➏ Dusting brush(depend on model) Upholstery nozzle is for vacuuming Dusting brush is for vacuuming picture upholstery, mattresses etc. frames, furniture frames, books and other irregular surfaces.
How to use Using accessory nozzles Crevice tool Upholstery nozzle Dusting brush ➐ Crevice tool(depend on model) ➑ Upholstery nozzle(depend on model) ➒ Dusting brush(depend on model) Crevice tool is for vacuuming Upholstery nozzle is for Dusting brush is for in those nomally hard-to- vacuuming upholstery, vacuurning picture frames,...
How to use Using sani punch nozzle Features How to use This nozzle picks up even dust inside through beating. Follow the directions below for properuse. The bottom part can be separated to be cleaned. Since the Assembly bottom does not stick to the surface, vacuuming iseasy. Connect the nozzle to the telescopic pipe.
Page 14
This Sani Punch nozzle is for effective cleaning of beds and blankets to remove mites and dust. Effective cleaning Carpet Bulky & heavy blanket Light blanket & sheet When using on the carpet When using on the floor Sani-punch is used for carpet. It is easier to clean a light blanket or sheetby pushing the nozzle in the direction of the arrow.
Page 15
For simple cleaning of the vacuum nozzle, detach the Sani Punch nozzle from the telescopic pipe and attach the crevice tool to vacuum dust. Bottom Inside You can remove dust by hand, if you can't remove dust which is inside of nozzle by crevice tool. Since the vibrator inside is composed of precision parts, never disassemble the body.
Page 16
Follow the instruction below for through washing. (Do not soak the entire body of the vacuum nozzle in water, it may cause the vibrator to malfunction) Bottom plate Punch bar Bottom plate Punch bar ➊ Press the button on the ➋...
Page 17
➊ Push the button 2-3 times ➋ When the dust is fully filled when the dust is filled in after cleaning, take the bin the dustbin while cleaning. and turn it counterclockwise to disconnect ➌ Waste the dust in the bin ➍...
How to use Emptying dust tank Tank separation button ① Push the button ② Pull out Tank handle MAX line Dust tank cap The dust tank needs emptying when the dust tank NOTICE level reaches the MAX line. • If suction power decreases after emptying the •...
How to use Cleaning dust tank Tank separation button ① Push the button ② Pull out Tank handle • Press tank separation button and pull out the dust tank. • Raise the dust tank cap. • Wash the dust tank. •...
• The air filter and the motor safety filter should be cleaned as above the figure. WARNING Dry fully for more than 24 hours in shade. NOTICE If filters are damaged, do not use them. In this cases, contact LG Electronics Service Agent. Wash filters at least Once a month.
How to use Cleaning exhaust filter Exhaust filter cover Exhaust filter Button Lever Exhaust filter cover Click! • The exhaust filter is a reuseable filter. • To clean the exhaust filter, open the exhaust filter cover by pushing the button. •...
What to do if your vacuum cleaner does not work Check that the vacuum cleaner is plugged in correctly and that the electrical socket is working. What to do when suction power decreases • Turn off the vacuum cleaner and unplug it. •...
