IMPORTANT: PLEASE READ THESE
INSTRUCTIONS THOROUGHLY BEFORE USING
THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR
FUTURE REFERENCE.
IMPORTANT USER INFORMATION
These notes are provided in the interest of safety.
You must read them before installing or using the
appliance.
–This tumble dryer is intended for NORMAL DOMESTIC
USE ONLY.
- This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision. Children of less than 3 years should be kept away
unless continuously supervised.
- Adequate ventilation must be provided to avoid back flow of
gases into the room from appliances burning other fuels,
including open fires.
INSTRUCTIONS FOR USE
TUMBLE DRYER
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for White Knight C35AW
Summary of Contents for White Knight C35AW
- Page 1 INSTRUCTIONS FOR USE TUMBLE DRYER IMPORTANT: PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. IMPORTANT USER INFORMATION These notes are provided in the interest of safety. You must read them before installing or using the appliance.
- Page 2 - Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances burning gas or other fuel. –Please note it is not recommended that the dryer is placed directly next to ovens or cookers as the performance of the dryer may be affected.
- Page 3 –The special mains cable and plug assembly must only be replaced with a genuine part by the manufacturer or his service agents in order to avoid a hazard. - It is important to clean fluff from the window of the dryer and around the door seal after each drying cycle.
-
Page 4: Additional Information
WARNING: The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility ADDITIONAL INFORMATION Many outlets sell “universal” tumble dryer accessories. These may not fit satisfactorily and could impair the efficient operation of your tumble dryer and may even cause air-flow restrictions not covered by our guarantee. -
Page 5: Operation
THE CONTROLS A. THE TIMER Select the required drying time based on the recommendations on the control panel. B. HEAT SWITCH Select the required heat setting based on the recommendations on the control panel. PREPARATION Check care labels inside the garments. CARE LABELS YOU MAY FIND ON YOUR FABRICS Do not tumble dry woollen or wool mixture articles unless the article is labelled as being suitable. -
Page 6: Safety Cut-Out
The standard cotton programme is suitable to dry normal wet cotton laundry. It is the most efficient programme in terms of energy consumption for drying wet cotton laundry. If your appliance is Uni-directional, a full load will typically take 90 minutes and will use approximately 2.05kWh of electricity. - Page 7 TECHNICAL DATA OVERALL DIMENSIONS: Height: 67 cm Width: 50 cm Depth: 47 cm MAXIMUM DRY WEIGHT LOADS: Cotton 3kg ‘Easy care’ polyester/cotton 3kg (For minimum creasing 1.5kg) Delicates 3kg For electrical ratings see plate on back of dryer. For Model No. see serial plate inside door (needed when requesting service). Room temperature range 5˚C to 30˚C.
-
Page 8: Approved Service Agents
APPROVED SERVICE AGENTS: White Knight (Whirlpool) 0800 988 1323 (calls are free from landlines however calls from mobiles may be charged at your network provider’s rates) White Knight (0800 Repair): 0344 8797422 (Calls charged at basic rate). -
Page 9: This Appliance Must Be Earthed
THIS APPLIANCE MUST BE EARTHED This appliance is marked according to the European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). This guideline is the frame of a European wide validity of return and recycling on Waste Electrical and Electronic Equipment. - Page 10 VENT HOSE ASSEMBLY One end of the vent hose is fitted with an adaptor which can be pushed into the exhaust outlet at the bottom rear of the tumble dryer. The free end should be led to a suitable outlet. It may simply be hung through an open window or a more permanent connection made using the four holes in the adapter flanges.
- Page 11 Compact SDO Rev Suppliers name or trade mark WHITE KNIGHT Model identifier 35A - TYPE Rated capacity at full load Appliance type Air Vented Energy efficiency class Energy consumption of the appliance* 251kWh The figures above is based on 160 drying cycles of the standard cotton programme at full and partial load and the consumption of the low-power modes.
- Page 12 Compact SDO Uni Suppliers name or trade mark WHITE KNIGHT Model identifier 36A - TYPE Rated capacity at full load Appliance type Air Vented Energy efficiency class Energy consumption of the appliance* 248kWh The figures above is based on 160 drying cycles of the standard cotton programme at full and partial load and the consumption of the low-power modes.
