  • Page 1 TOSHIBA Satellite T130/T110 Satellite Pro T130/T110 PORTEGE T130/T110 Portable Personal Computer User's Manual...
  • Page 2 Copyright © 2009 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.

  • Page 3: Safety Instructions

    Incorporated in the United States and/or other countries. Bluetooth is a registered trademark owned by its proprietor and used by TOSHIBA under license. ConfigFree is a trademark of TOSHIBA Corporation. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

  • Page 4: When Using Your Computer

    When Using Your Computer Do not operate your portable computer for an extended period of time with the base resting directly on your body. With extended operation, heat can potentially build up in the base. Allowing sustained contact with the skin could cause discomfort or, eventually, a burn.

  • Page 5: Fcc Information

    Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer's external monitor port, USB port, serial port, parallel port, PS/2 mouse/keyboard port and microphone jack.
  • Page 6 EU Declaration of Conformity TOSHIBA declares that this product conforms to the following Standards: Supplementary Information: This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe, Hammfelddamm 8, 41460 Neuss, Germany.
  • Page 7 For more detailed information about the collection and recycling programmes available in your country, please visit our website (http:// eu.computers.toshiba-europe.com) or contact your local city office or the shop where you purchased the product. Disposal of batteries and/or accumulators...
  • Page 8 Compliant. If the model you purchased is compliant, it is labeled with the ENERGY STAR logo on the computer and the following information applies. TOSHIBA. is a partner in the Environmental Protection Agency's (EPA) ENERGY STAR Program and has designed this computer to meet the latest ENERGY STAR guidelines for energy efficiency.

  • Page 9: Important Notice

    Dispose of used batteries according to the manufacturer's instructions. Use only the battery pack that came with the computer or an optional battery pack. Use of wrong battery could damage your computer. TOSHIBA assumes no liability for any damage in such case. User’s Manual...

  • Page 10: General Precautions

    General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the general precautions below and to note the cautions included in the text of the manual.
  • Page 11 Creating a computer-friendly environment Place the computer on a flat surface that is large enough for the computer and any other items you are using, such as a printer. Leave enough space around the computer and other equipment to provide adequate ventilation.

  • Page 12: Instruction Manual For Safety And Comfort

    Pressure or impact damage Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Mobile phones Please be aware that the use of mobile phones can interfere with the audio system.

  • Page 13: Table Of Contents

    Special features ......... . 1-9 TOSHIBA Value Added Package ......1-11 Utilities and Applications.
  • Page 14 TOSHIBA Disc Creator........4-7...
  • Page 15 Using the Hard Disk Drive (HDD) Protection ....4-15 TOSHIBA HDD Protection Properties..... . . 4-16 Details .
  • Page 16 TOSHIBA support........

  • Page 17: Display Controller

    Appendix E Starting the TOSHIBA PC Health Monitor..... . E-2 If a TOSHIBA PC Health Monitor message is displayed ..E-2...

  • Page 18: Preface

    This manual tells you how to set up and begin using your TOSHIBA Satellite T130/T110, Satellite Pro T130/T110, PORTEGE T130/T110 Series computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.

  • Page 19: Conventions

    Preface Chapter 4, Operating devices: Touch Pad, Sound System, wireless communication and LAN. It also provides tips on care of the computer, and CD/DVDs. Chapter 5, the keypad overlay and hot keys. Chapter 6, Power and Power-Up power resources and battery save modes. Chapter 7, HW Setup HW Setup program.

  • Page 20: Key Operation

    Key operation Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, CTRL + C means you must hold down CTRL and at the same time press C.

  • Page 21: Introduction

    Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA. Equipment checklist Carefully unpack your computer. Save the box and packing materials for future use.

  • Page 22: Software

    Online Manual (This manual) Other software may be preinstalled dependant on the model purchased. Documentation ■ Satellite T130/T110, Satellite Pro T130/T110, PORTEGE T130/T110 Series Personal Computer User Information Guide ■ Instruction Manual for Safety and Comfort If any of the items are missing or damaged, contact your dealer immediately.

  • Page 23: Features

    User’s Manual Your computer is equipped with one processor and processor type varies depending on model. To check which type of processor is included in your model, open the TOSHIBA PC Diagnostic Tool Utility by clicking Start TOSHIBA Utilities PC Diagnostic Tool.
  • Page 24 Introduction Main Memory Disclaimer Video RAM Legal Footnote (Memory (Main System)) For more information regarding Memory (Main System), please refer to the Legal Footnotes section in Appendix F or click the *3 above. Power Battery Pack Legal Footnote (Battery Life) For more information regarding Battery Life, please refer to the Legal Footnotes section in Appendix F or click the *4 above.
  • Page 25 Disks Hard disk Disclaimer 1 Gigabyte (GB) means 10 Hard disk Drive Legal Footnote (Hard Disk Drive (HDD) Capacity) For more information regarding Hard Disk Drive (HDD) Capacity, please refer to the Legal Footnotes section in Appendix F or click the *5 above. Display The computer's LCD panel supports high-resolution video graphics.

  • Page 26: Pointing Device

    Introduction Graphics Controller Legal Footnote (Graphics Processor Unit ("GPU")) For more information regarding the Graphics Processor Unit ("GPU"), please refer to the Legal Footnotes section in Appendix F or click the *7 above. Keyboard Built-In Pointing Device Built-In Touch Pad Ports HDMI out port External Monitor...
  • Page 27 Slots Bridge Media Slot Multimedia Web Camera Sound System Headphone jack Microphone Jack Communications Wireless LAN User’s Manual This slot lets you insert an SD™/SDHC™ memory card, Memory Stick™(PRO™/PRO Duo™ ), xD-Picture Card™, and MultiMediaCard™. Record/Send still or video images with this integrated Web Camera.
  • Page 28 Introduction ■ The transmission speed over the wireless LAN, and the distance over which the wireless LAN can reach, may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, client design and software/hardware configurations. The transmission rate described is the theoretical maximum speed as specified under the appropriate standard - the actual transmission speed will be lower than the theoretical maximum speed.

  • Page 29: Special Features

    Special features The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use. Hot Keys Keypad Overlay Instant Security Display Automatic Power Off HDD Automatic Power Off System Automatic Sleep Mode/...
  • Page 30 Introduction Low Battery Automatic Hibernation TOSHIBA HDD Protection The TOSHIBA HDD Protection function does not guarantee that the hard disk drive will not be damaged. Hibernation Mode Sleep Mode *1 Click Options. 1-10 When battery power is exhausted to the point...

  • Page 31: Toshiba Value Added Package

    TOSHIBA Value Added Package This section describes the TOSHIBA Component features pre-installed on the computer. TOSHIBA Power Saver TOSHIBA Zooming Utility TOSHIBA PC Diagnostic Tool TOSHIBA Flash Cards TOSHIBA Components Common Driver TOSHIBA Accessibility User’s Manual TOSHIBA Power Saver provides you with the features of more various power supply managements.

  • Page 32: Utilities And Applications

    HW Setup Power On Password TOSHIBA Disc Creator TOSHIBA ConfigFree ConfigFree is a suite of utilities to allow easy 1-12 TOSHIBA Assist is a graphical user interface that provides easy access to help and services. This program lets you customize your hardware settings according to the way you work with your computer and the peripherals you use.
  • Page 33 ■ Lock Computer: Lock your computer without turning it off. This has the same function as Lock of the Start menu. ■ TOSHIBA Assist: Open the TOSHIBA Assist if it is already installed in your computer. Introduction 1-13...

  • Page 34: Options

    Two memory modules can be installed in this computer. An additional battery pack can be purchased from your TOSHIBA dealer. Use it as a spare to increase your computer operating time. If you use your computer at more than one site...

  • Page 35: Chapter 2 The Grand Tour

    Chapter 2 The Grand Tour This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer. Legal Footnote (Non-applicable Icons) For more information regarding Non-applicable Icons, please refer to the Legal Footnotes section in Appendix F or click the *1 above. Please handle your computer carefully to avoid scratching or damaging the surface.
  • Page 36 1. DC IN LED 2. Power LED 3. Battery LED 4. Disk LED 5. Bridge media slot LED Front of the computer with display closed (Satellite T110, Satellite Pro T110, DC IN LED Power LED Battery LED Disk LED Bridge media slot...

  • Page 37: Left Side

    The left side of the computer (Satellite T130, Satellite Pro T130, PORTEGE T130) 1. Security Lock 2. External Monitor Port 3. Cooling Vents The left side of the computer (Satellite T110, Satellite Pro T110, PORTEGE T110) Security Lock User’s Manual When the Arrow indicator lights green, you can use the dark gray labeled keys on the keypad overlay as cursor keys.
  • Page 38 The Grand Tour External Monitor Port Cooling Vents Do not block the cooling vents. Keep foreign metal objects, such as screws, staples and paper clips, out of the cooling vents. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury.

  • Page 39: Right Side

    2. Microphone Jack 3. Universal Serial Bus (USB 2.0) ports The right side of the computer (Satellite T110, Satellite Pro T110, PORTEGE T110) Bridge Media Slot Keep foreign metal objects, such as screws, staples and paper clips, out of the Bridge media slot. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury.
  • Page 40 The Grand Tour Headphone Jack Microphone Jack Universal Serial Bus (USB 2.0) ports Keep foreign metal objects, such as screws, staples and paper clips, out of the USB connectors. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury. LAN Jack ■...

  • Page 41: Backside

    The following figure shows the computer's back panel. The backside of the computer (Satellite T130, Satellite Pro T130, PORTEGE T130) The backside of the computer (Satellite T110, Satellite Pro T110, PORTEGE T110) Underside The following figure shows the underside of the computer. You should ensure that the display is closed before the computer is turned over to avoid causing any damage.
  • Page 42 The Grand Tour 1. Memory Module Cover 2. Battery Lock 3. Battery Pack The underside of the computer (Satellite T110, Satellite Pro T110, PORTEGE T110) Memory Module Cover Battery Lock Battery Pack Battery Release Latch Speakers 4. Battery Release Latch 5.

  • Page 43: Front With The Display Open

    Front with the display open This section shows the front of the computer with the display open. Refer to the appropriate illustration for details. To open the display, lift the front of the display. Position the display at a comfortable viewing angle. 1.

  • Page 44: Display Screen

    1. Display Screen 2. Web Camera LED 3. Web Camera Lens 4. Built-in microphone 5. Power Button The front of the computer with the display open (Satellite T110, Satellite Pro T110, Display Screen Web Camera LED Web Camera Built-In Microphone 2-10 6.
  • Page 45 Power Button LCD Sensor switch Do not put any magnetic objects close to this switch as they may cause the computer to automatically enter Hibernation Mode and shut down even if the Panel Power Off feature is disabled. Touch Pad Touch Pad Control Buttons Wireless LAN...

  • Page 46: Ac Adaptor

    Always use the TOSHIBA AC adaptor that was included with your computer, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor could cause fire or damage to the computer possibly resulting in serious injury.

  • Page 47: Chapter 3 Getting Started

    Chapter 3 Getting Started This chapter provides basic information to get you started using your computer. It covers the following topics: Be sure also to read the Instruction Manual for Safety and Comfort. This guide, which is included with the computer, explains product liability. ■...

  • Page 48: Connecting The Ac Adaptor

    ■ Always use the TOSHIBA AC adaptor that was included with your computer or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor could cause fire or damage to the computer possibly resulting in serious injury.
  • Page 49 1. Connect the power cord to the AC adaptor. Either a 2-pin or 3-pin adaptor/cord will be included with the computer depending on the model. 2. Connect the AC adaptor's DC output plug to the DC IN 19V jack on the right side of the computer.

  • Page 50: Opening The Display

    Getting Started Opening the display The display panel can be opened to a wide range of angles for optimal viewing. 1. While holding down the palm rest with one hand so that the main body of the computer is not raised, slowly lift the display panel - this will allow the angle of the display panel to be adjusted to provide optimum clarity.

  • Page 51: Turning On The Power

    ■ When opening the panel, please be careful not to force it beyond the point where it moves easily. ■ Be careful not to open the display panel too far as this could put stress on the display panel's hinges and cause damage. ■...
  • Page 52 Getting Started ® Windows 7 setup The Windows turn on the power. Follow the on-screen instructions on each screen in order to properly install the operating system. When it is displayed, be sure to read the Software License Terms carefully. Turning on the power ®...

  • Page 53: Turning Off The Power

    Turning off the power The power can be turned off in one of the following modes: Shut down (Boot), Hibernation or Sleep Mode. Shut Down mode (Boot mode) When you turn off the power in Shut Down mode no data is saved and the computer will boot to the operating system's main screen.
  • Page 54 Getting Started ■ When the AC adaptor is connected, the computer will go into Sleep Mode according to the settings in the Power Options. ■ To restore operation from Sleep Mode, press the power button or press any key. The latter action works only if Wake-up on Keyboard is enabled in HW Setup.

  • Page 55: Hibernation Mode

    ■ When the computer is shut down in Sleep Mode, the power indicator flashes Amber. ■ If you are operating the computer on battery power, you can lengthen the operating time by turning it off into Hibernation Mode, as Sleep Mode consumes more power.

  • Page 56: Restarting The Computer

    Getting Started Automatic Hibernation Mode The computer will enter Hibernation mode automatically when you press the power button or close the Display Screen. First, however, make the appropriate settings according to the steps below. 1. Open the Control Panel. 2. Open System and Security and open Power Options. 3.

  • Page 57: System Recovery Options

    System Recovery Options A hidden partition is allocated on the hard drive for the System Recovery Options. The System Recovery Options feature will be unusable if this partition is deleted. System Recovery Options The System Recovery Options feature is installed on the hard disk when shipped from the factory.

  • Page 58: Create Optical Recovery Media

    5. Double Click the Recovery Media Creator icon on the Windows desktop, or select the application from Start menu. 6. After TOSHIBA Recovery Media Creator starts, select the type of media and the title you wish to copy to the media then click the Create button.

  • Page 59: Restoring The Preinstalled Software From The Recovery Hdd

    1. Turn off your computer. 2. Hold down the 0 (zero) key on the keyboard and turn on your computer. When "TOSHIBA Leading Innovation >>>" appears, release the 0 (zero) key on the keyboard. 3. A menu appears. Follow the on-screen instructions.

  • Page 60: Restoring The Preinstalled Software From Recovery Media

    1. Load the Recovery Media in the optional optical media drive and turn off the computer's power. 2. Hold down the F12 key and turn on the power. When "TOSHIBA Leading Innovation >>>" appears, release the F12 key. 3. Use the upper or lower cursor key to select the CD/DVD in the display menu.

  • Page 61: Chapter 4 Operating Basics

    Chapter 4 Operating Basics This chapter describes the basic operations of your computer, highlights the precautions that should be taken when using it. Using the Touch Pad To use the Touch Pad, simply touch and move your fingertip across it in the direction you want the on-screen pointer to go.

  • Page 62: Using The Web Camera

    Operating Basics Do not press on the Touch Pad too hard or press a sharp object such as a ball point pen against the Touch Pad. The Touch Pad could be damaged. For some functions, you can tap the Touch Pad instead of pressing a control button.

  • Page 63: Using The Software

    Using the software TOSHIBA Web Camera Application is pre-configured to start when you turn on Windows TOSHIBA 1. CAMERA RESOLUTION 2. CAPTURE SETTING 3. CAPTURE STILL IMAGE Delete Recorded File Choose a thumbnall of recorded file and click this Open/Close Preview...

  • Page 64: Using The Toshiba Face Recognition

    Operating Basics Using the TOSHIBA Face Recognition TOSHIBA Face Recognition uses a face verification library to verify the face data of users when they log in to Windows. The user can thus avoid having to enter a password or the like, which makes the login process easier.

  • Page 65: How To Delete The Face Recognition Data

    To delete the Face Recognition Data, follow the steps as described below: 1. To launch this utility, click Start Utilities 2. Select a user which is deleted in the Management screen. User’s Manual All Programs Face Recognition. The Management screen is displayed. Operating Basics TOSHIBA...

  • Page 66: How To Launch The Help File

    To launch the help file, click Start Utilities Windows Logon via TOSHIBA Face Recognition This section explains how to login to Windows with TOSHIBA Face Recognition. Two authentication modes are provided. ■ 1:N Mode Login screen : If the face authentication tile is selected by default, you can log in without using the keyboard or mouse.

  • Page 67: Using The Microphone

    You cannot use the TOSHIBA Disc Creator "Audio CD" function to record music to the DVD-R/-RW or DVD+R/+RW media. ■ Do not use the "Disc Backup" function of TOSHIBA Disc Creator to copy ■ DVD-Video and DVD-ROM with copyright protection. DVD-RAM media cannot be backed up with the "Disc Backup"...

  • Page 68: Wireless Communications

    TOSHIBA Disc Creator cannot record in packet format. ■ You might not be able to use the Disc Backup function of TOSHIBA Disc Creator to backup a DVD-R/-RW or DVD+R/+RW disc that was made with other software on a different DVD-R/-RW or DVD+R/+RW recorder.

  • Page 69: Wireless Lan

    ■ Do not use the Wireless LAN (Wi-Fi) or Bluetooth functionalities near a microwave oven or in areas subject to radio interference or magnetic fields. Interference from a microwave oven or other source can disrupt Wi-Fi or Bluetooth operation. ■ Turn Wi-Fi and Bluetooth functionalities off when near a person who may have a cardiac pacemaker implant or other medical electric device.

  • Page 70: Security

    TOSHIBA strongly recommend the customer to enable the encryption function. ■ TOSHIBA is not liable for the eavesdropping of data due to the use of Wireless LAN and the damage thereof. Bluetooth Stack for Windows by TOSHIBA...

  • Page 71: Wireless Activity Led

    Set the Wireless LAN function to off in airplanes and hospitals. Check the indicator. It will stop glowing when the wireless communication function is off. Wireless activity LED The wireless activity LED indicates the status of the wireless communication functions. Indicator status LED off LED glows...

  • Page 72: Connecting Lan Cable

    Operating Basics Connecting LAN cable ■ Do not connect any other cable to the LAN jack except the LAN cable. Otherwise, malfunctions or damage may occur. ■ Do not connect any power supplying device to the LAN cable that is connected to the LAN jack.

  • Page 73: Starting The Usb Sleep And Charge Utility

    You can set mode1/mode2/mode3/mode4/disable USB sleep and charge function also in BIOS Setup menu. Enabling USB Sleep and Charge This utility can be used to enable and disable the USB Sleep and Charge function. User’s Manual All Programs TOSHIBA Operating Basics Utilities 4-13...

  • Page 74: Power Supply Mode Settings

    Operating Basics Check the "USB Sleep and Charge" check box. In the default state this function is disabled. Power supply mode settings There are several USB Sleep and Charge function modes. "Mode 4(Default)" should normally be used. Set one of the other modes (try from "Mode 3"...

  • Page 75: Moving The Computer

    This computer has a function for reducing the risk of damage on the hard disk drive. Using an acceleration sensor built into the computer, TOSHIBA HDD Protection detects vibration, falls and shocks, and similar signs of movement of the computer, and automatically moves the Hard Disk Drive head to a safe position to reduce the risk of damage that could be caused by head-to-disk contact.

  • Page 76: Toshiba Hdd Protection Properties

    State Normal Protection TOSHIBA HDD Protection Properties You can change the TOSHIBA HDD Protection settings by using the TOSHIBA HDD Protection Properties window. To open the window, click Start All Programs Settings. The window can also be started from the icon on the Taskbar or from the Control Panel.

  • Page 77: Details

    Intensely shaking the computer or other subjecting it to strong impacts may cause damage to the computer. Details To open the Details window, click the Setup Detail button in the TOSHIBA HDD Protection Properties window. Detection Level Amplification When the AC adaptor is disconnected or the lid is closed, HDD Detection assumes that the computer will be carried and sets the detection level to the maximum for 10 seconds.

  • Page 78: Chapter 5 The Keyboard

    Chapter 5 The Keyboard The computer's keyboard layouts are compatible with a 104/105-key enhanced keyboard. By pressing some keys in combination, all the 104/ 105-key keyboard functions can be executed on the computer. The number of keys on your keyboard depends on which country/region's keyboard layout your computer is configured with.

  • Page 79: F1 ... F12 Function Keys

    The Keyboard F1 ... F12 function keys The function keys (not to be confused with FN) are the 12 keys at the top of your keyboard. These keys function differently from other keys. F1 through F12 are called function keys because they execute programmed functions when pressed.

  • Page 80: Hot Keys

    Press FN + F10 or FN + F11 to access the computer's integrated keypad. When activated, the keys with grey markings on their bottom edge become either numeric keypad keys (FN + F11) or cursor control keys (FN + F10). Please refer to the information on how to operate these keys, taking care to note that the power on default for both settings is off.
  • Page 81 Number Lock: Enables or disables the Number Lock function. Scroll Lock: Enables or disables the Scroll Lock function. Zoom: Changes the display resolution. TOSHIBA Zooming Utility (reduce): Reduces the icon size on the desktop or the font size within one of the supported application windows. User’s Manual...

  • Page 82: Fn Sticky Key (Depends On The Model You Purchased)

    Volume up: Pressing FN + 4 to increase the volume in increment. FN Sticky key (Depends on the model you purchased) You can use the TOSHIBA Accessibility Utility to make the FN key sticky, that is, you can press it once, release it, and then press an "F number" key.

  • Page 83: Keypad Overlay

    The Keyboard Keypad overlay Your computer's keyboard does not have an independent numeric keypad, but its numeric keypad overlay functions like one. The keys in the centre of the keyboard with gray letters make up the numeric keypad overlay. The overlay provides the same functions as the numeric keypad on the 104/105-key enhanced keyboard described previously.

  • Page 84: Temporarily Using Normal Keyboard (Overlay On)

    Temporarily using normal keyboard (overlay on) While using the overlay, you can temporarily access the normal keyboard without turning off the overlay: 1. Hold FN and press any other key. All keys will operate as if the overlay were off. 2.

  • Page 85: Chapter 6 Power And Power-Up Modes

    Chapter 6 Power and Power-Up Modes The computer's power resources include the AC adaptor and internal batteries. This chapter gives details on making the most effective use of these resources including charging and changing batteries, tips for saving battery power, and power up modes. Power conditions The computer's operating capability and battery charge status are affected by the power conditions: whether an AC adaptor is connected, whether a...

  • Page 86: Power Indicators

    Power and Power-Up Modes Table Power conditions Universal Battery charge is above low battery trigger point adaptor Battery charge is connected below low battery trigger point Battery charge is exhausted No Battery installed Power indicators As shown in the above table, the Battery/Power indicators on the system indicator alert you to the computer's operating capability and battery charge status.

  • Page 87: Power Indicator

    Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Do not remove the battery pack while the computer is in Sleep Mode.

  • Page 88: Real Time Clock Battery

    The computer's RTC battery is a lithium ion battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed of.
  • Page 89 Press ENTER key. BIOS setup will terminate and the computer will be rebooted. After configuring the date and time it is recommended that you switch the computer on and then leave it in this state so that the Real Time Clock battery can be charged.

  • Page 90: Care And Use Of The Battery Pack

    Power and Power-Up Modes Care and use of the battery pack The battery pack is a vital component of portable computing. Taking proper care of it will help ensure longer operating time on battery power as well as a longer life for your battery pack. Follow the instructions in this section carefully to ensure safe operation and maximum performance.
  • Page 91 Never use the computer again until it has been checked by a TOSHIBA service provider. It might generate smoke or fire, or the battery pack might rupture. 3. Make sure the battery is securely installed in the computer before attempting to charge the battery pack.

  • Page 92: Charging The Batteries

    Power and Power-Up Modes 6. Be sure to monitor the remaining battery power. If the battery pack and real time clock battery discharge completely, Sleep Mode will not function and data in memory will be lost. Also, the computer might register an incorrect time and date.

  • Page 93: Battery Charging Notice

    Time Refer to User Information Guide about Charging time. The charging time when the computer is on is affected by ambient temperature, the temperature of the computer and how you use the computer. If you make heavy use of external devices, for example, the battery might scarcely charge at all during operation.

  • Page 94: Monitoring Battery Capacity

    Power and Power-Up Modes Monitoring battery capacity Remaining battery power can be monitored using the following methods. ■ Clicking the battery icon on the task bar ■ Via the Windows Mobility Center window ■ Wait at least 16 seconds after turning on the computer before trying to monitor the remaining operating time.

  • Page 95: Retaining Data With Power Off

    Retaining data with power off Refer to User Information Guide about Retaining time. Extending battery life To maximize the life of your battery pack: ■ At least once a month, disconnect the computer from a power source and operate it on battery power until the battery pack fully discharges. Before doing so, follow the steps below.

  • Page 96: Replacing The Battery Pack

    Power and Power-Up Modes Replacing the battery pack Please be aware that the battery pack is classified as a consumable item. The operating life of the battery pack will gradually reduce through repeated charging and discharging, and will need to be replaced when it reaches the end of its operating life.

  • Page 97: Removing The Battery Pack

    Removing the battery pack To remove a discharged battery, follow the steps below. 1. Save your work. 2. Turn the computer's power off. Make sure the Power indicator is off. 3. Remove all cables connected to the computer. 4. Close the display panel and turn the computer upside down. 5.

  • Page 98: Installing The Battery Pack

    Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Do not touch the latch while holding the computer. Or you may get injured by the dropped battery by unintentional release of the latch.

  • Page 99: Power-Up Modes

    Power-up modes The computer has the following power-up modes: ■ Boot Mode: Computer shuts down without saving data. Always save your work before you turn the computer off in boot mode. ■ Hibernation Mode: Data in memory is saved to the hard disk. ■...

  • Page 100: Chapter 7 Hw Setup

    Chapter 7 HW Setup This chapter explains how to use TOSHIBA HW Setup program to configure your computer. TOSHIBA HW Setup lets you configure settings for General, Password, Display, Boot Priority, Keyboard, LAN, and USB. Accessing HW Setup To run HW Setup, click...

  • Page 101: User Password

    HW Setup Password This tab allows you to set or reset the user password for power on. User Password Lets you register a new password or un-register an existing password. Not Registered Registered Owner String This blank field is used to display a message when the password field is displayed on startup.
  • Page 102 Keyboard Wake-up on Keyboard When this feature is enabled and the computer is in Sleep Mode, you can turn on the computer by pressing any key. It is effective only for the internal keyboard and only when the computer is in Sleep Mode. Enabled Disabled USB Keyboard/Mouse/FDD Legacy Emulation...
  • Page 103 HW Setup To access BIOS setup menu, press F2 when booting up the computer. User’s Manual...

  • Page 104: Chapter 8 Optional Devices

    Optional Devices Optional devices can expand the computer's capabilities and its versatility. This chapter describes connection or installation of the following devices, which are available from your TOSHIBA dealer: Cards/memory ■ Secure Digital™ (SD) Card (SD memory card, SDHC memory card, miniSD Card, microSD Card) ■...

  • Page 105: Bridge Media Slot

    Optional Devices Bridge media slot The computer is equipped with a bridge media slot that can accommodate SD/SDHC/MMC/Memory Stick/Memory Stick Pro memory cards. These memory cards let you easily transfer data from devices, such as digital cameras and Personal Digital Assistants, which use flash-memory. Card Type SDHC Memory Stick...

  • Page 106: Installing A Memory Card

    2. Press gently to ensure a firm connection. Inserting a memory card (Satellite T130, Satellite Pro T130, PORTEGE T130) Inserting a memory card (Satellite T110, Satellite Pro T110, PORTEGE T110) Be sure the memory card is oriented properly before you insert it.

  • Page 107: Removing A Memory Card

    3. Gently press the memory card inside the socket to eject it. 4. Grasp the card and remove it. Removing a memory card (Satellite T130, Satellite Pro T130, PORTEGE T130) Removing a memory card (Satellite T110, Satellite Pro T110, PORTEGE T110) User’s Manual...

  • Page 108: Memory Card Care

    ■ Make sure the memory card indicator is out before you remove the card or turn off the computer's power. If you remove the card or turn off the power while the computer is accessing the card you may lose data or damage the card.

  • Page 109: Memory Expansion

    RAM. This section describes how to install and remove a memory module. ■ Use only memory modules approved by TOSHIBA. ■ Do not try to install or remove a memory module under the following conditions. You can damage the computer and the module. Also, data will be lost.
  • Page 110 1. Memory Module Cover 6. Lift one side of the insulator sheet and fit the module's connectors into the computer's connectors at about a 30 degree angle. Press the module carefully to ensure a firm connection. Do not touch the connectors on the memory module or on the computer. Debris on the connectors may cause memory access problems.

  • Page 111: Removing A Memory Module

    Optional Devices 8. Seat the cover and secure it with the screws. 9. Replace the battery pack as described in Chapter 6, Modes. 10. Turn the power on and make sure the added memory is recognized. Open System in the Control Panel and click the General tab. Removing a memory module To remove the memory module, make sure the computer is in boot mode then:...

  • Page 112: Additional Battery Pack

    6. Seat the cover and secure it with screws and replace the battery pack. Additional battery pack You can increase the portability of the computer with additional battery packs. If you're away from an AC power source and your battery runs low, you can replace it with a freshly charged battery.

  • Page 113: External Monitor

    Optional Devices External monitor An external analog monitor can be connected to the external monitor port on the computer. Refer to Appendix B, supports several video modes. To connect a monitor, follow the steps below. 1. Turn the computer off. 2.

  • Page 114: Troubleshooting

    Chapter 9 Troubleshooting TOSHIBA designed the computer for durability. However, should problems occur, following the procedures in this chapter can help to determine the cause. All readers should become familiar with this chapter. Knowing what might go wrong can help prevent problems from occurring.

  • Page 115: Preliminary Checklist

    Troubleshooting Preliminary checklist Consider the simplest solution first. The items in this checklist are easy to fix and yet can cause what appears to be a serious problem. ■ Make sure you turn on all peripheral devices before you turn on the computer.

  • Page 116: Hardware And System Checklist

    Software Hardware Hardware and system checklist This section discusses problems caused by your computer's hardware or attached peripherals. Basic problems may occur in the following areas: ■ System start-up ■ Self test ■ Power ■ Real Time Clock ■ Keyboard ■...

  • Page 117: Self Test

    This message remains on the screen for a few seconds. If the self test is successful, the computer tries to load the operating system, depending on how the Boot Priority is set in the TOSHIBA HW Setup program. If any of the following conditions are present, the self test failed: ■...

  • Page 118: Ac Power

    AC power If you have trouble turning on the computer with the AC adaptor connected, check the Battery indicator. Refer to Chapter 6, Modes for more information. Problem AC adaptor doesn't power the computer Battery If you suspect a problem with the battery, check the Battery indicator. For information on indicator and battery operation refer to Chapter 6, and Power-Up Problem...

  • Page 119: Disposing Of Pc And Pc Batteries

    Troubleshooting Problem Battery doesn't power the computer as long as expected Disposing of PC and PC batteries ■ Discard this PC in accordance with applicable laws and regulations. For further information, contact your local government. ■ This PC contains rechargeable batteries. After repeated use, the batteries will finally lose their ability to hold a charge and you will need to replace them.

  • Page 120: Real Time Clock

    ■ Reformatting the media ■ Reinstalling an operating system from the recovery media or HDD. The procedures above delete only the initial part of the data used for file management. This makes the file invisible to the operating system, but the data can still be read by specialized utilities.

  • Page 121: Lcd Panel

    Troubleshooting LCD panel Apparent LCD problems may be related to the computer's setup. Problem No display Problems above remain unresolved or other problems occur ® Intel Display Power Saving Technology: Your model may include the Intel feature that can save the computer's power consumption by optimizing picture contrast on the internal LCD.

  • Page 122: Hard Disk Drive

    Simply follow the instructions in "Restoring the preinstall software from your creating Recovery Media" section in this manual. You will be directed to select "Restore Original Factory Image" from the drop-down menu. If you have not created "Recovery Media", please contact TOSHIBA support for assistance. Troubleshooting...

  • Page 123: Pointing Device

    Troubleshooting Pointing device If you are using a USB mouse, also refer to the USB section in this chapter and to your mouse documentation. Touch Pad Problem On-screen pointer does not respond to Pad operation Double-tapping does not work The mouse pointer moves too fast or too slow The response of the...

  • Page 124: Usb

    Problem Double-clicking does not work The mouse pointer moves too fast or too slow The mouse pointer moves erratically Also refer to your USB device's documentation. Problem USB device does not work User’s Manual Procedure Try changing the double-click speed setting in the mouse control utility.

  • Page 125: Usb Sleep And Charge Function

    The setting of "USB Sleep and Charge function" may be disabled. Check the "USB Sleep and Charge" check box to enable this function in the TOSHIBA USB Sleep and Charge Utility. When there is a current overflow of the external...

  • Page 126: Memory Expansion

    TOSHIBA USB Sleep and Charge Utility. When "USB Sleep and Charge function" is enabled in the TOSHIBA USB Sleep and Charge Utility, the "USB WakeUp function" does not work for ports that support the USB Sleep and Charge function.

  • Page 127: Sound System

    Troubleshooting Sound system Refer also to documentation for your audio devices. Problem No sound is heard Monitor Refer also to Chapter 8, documentation. Problem Monitor does not turn No display Display error occurs Problem Cannot access LAN Wireless LAN If the following procedures do not restore LAN access, consult your LAN administrator.

  • Page 128: Bluetooth

    Problem Cannot access Wireless LAN Bluetooth For more information on wireless communication, refer to Chapter 4, Operating Basics. Problem Cannot access Bluetooth device SD/MuliMedia Card Refer also to Chapter 8, Problem Memory card error occurs You cannot write to the memory card You cannot read a file Using Windows...

  • Page 129: Toshiba Support

    They are your best sources for current information and support. Where to write If you are still unable to solve the problem and suspect that it is hardware related, write to TOSHIBA at the nearest location listed on the below. 9-16 ®...
  • Page 130 Outside of Europe Australia TOSHIBA Australia Pty. Ltd. Information Systems Division Building C, 12-24 Talavera Rd, North Ryde, 2113, NSW, Australia Canada TOSHIBA of Canada Ltd. 191 McNabb Street, Markham, Ontario L3R 8H2 China TOSHIBA Personal Computer & Network (Shanghai) Co., Ltd.

  • Page 131: Specifications

    Appendix A Specifications This appendix summarizes the computer's technical specifications. Physical Dimensions Refer to User Information Guide about Size. Environmental Requirements Ambient temperature 5°C to 35°C Thermal gradient Relative humidity (non condensing) Altitude (from sea level) Power Requirements AC adaptor Computer User’s Manual Operating...

  • Page 132: Appendix B Display Controller

    Appendix B Display Controller Display controller The display controller interprets software commands into hardware commands that turn particular pels on or off. A high-resolution external monitor connected to the computer can display up to 1920 horizontal and 1200 vertical pixels at 16 M colors. (Depends on the model you purchased.) The display controller also controls the video mode, which uses industry standard rules to govern the screen resolution and the maximum number of...

  • Page 133: Appendix C Wireless Lan

    Appendix C Wireless LAN This appendix is intended to help you get your Wireless LAN network up and running, with a minimum of parameters. Card Specifications Form Factor Compatibility Network Operating System Media Access Protocol The Wireless LAN feature is not available on all models. User’s Manual PCI Express Mini Card ■...

  • Page 134: Radio Characteristics

    Wireless LAN Radio Characteristics Radio Characteristics of Wireless LAN Cards may vary according to: ■ Country/region where the product was purchased ■ Type of product Wireless communication is often subject to local radio regulations. Although Wireless LAN wireless networking products have been designed for operation in the license-free 2.4GHz band, local radio regulations may impose a number of limitations to the use of wireless communication equipment.
  • Page 135 Subject to the radio regulations that apply in the countries/regions, your Wireless LAN card may support a different set of 2.4 GHz channels. Consult your Authorized Wireless LAN or TOSHIBA Sales office for information about the radio regulations that apply in the countries/regions.

  • Page 136: Ac Power Cord And Connectors

    Appendix D AC Power Cord and Connectors The power cord's AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Length: Wire size:...
  • Page 137 AC Power Cord and Connectors In Europe, power cords must be VDE type, H05VVH2-F and two conductor. For the United States and Canada, plug configuration must be a 2-15P (250 V) or 1-15P (125 V) as designated in the U.S. National Electrical code handbook and the Canadian Electrical Code Part II.

  • Page 138: Toshiba Pc Health Monitor

    ■ Once enabled, you may disable the TOSHIBA PC Health Monitor at any time by uninstalling the software via Uninstall a program in the Control Panel. Doing so will automatically delete all collected information from the HDD.

  • Page 139: Starting The Toshiba Pc Health Monitor

    TOSHIBA PC Health Monitor Toshiba's obligations under its standard limited warranty in any way. Toshiba's standard limited warranty terms and limitations apply. Starting the TOSHIBA PC Health Monitor The TOSHIBA PC Health Monitor can be started using the following methods: ■ Click Start Monitor.
  • Page 140 Appendix F Legal Footnotes This chapter states the Legal Footnotes information applicable to TOSHIBA computers. In the text in this manual, *XX is used to show which Legal Footnotes description is related to TOSHIBA computers. Description(s) related to this computer are marked with a blue *XX in this manual.
  • Page 141 86°F) or >25°C (77°F) at high altitude (all temperature references are approximate and may vary depending on the specific computer model - please refer to your computer documentation or visit the TOSHIBA website at http://www.pcsupport.toshiba.com for details). CPU performance may also vary from specifications due to design configuration.
  • Page 142 Published battery life numbers are achieved on select models and configurations tested by TOSHIBA at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power.

  • Page 143: Copy Protection

    Legal Footnotes Wireless LAN The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.
  • Page 144 Glossary The terms in this glossary cover topics related to this manual. Alternate naming is included for reference. Abbreviations AACS: advanced access content system AC: Alternating current ACPI: Advanced Configuration and Power Interface AMT: Intel Active Management Technology ASCII: American Standard Code for Information Interchange BIOS: basic input/output system bps: bits per second CD: compact disc...
  • Page 145 Glossary HDMI-CEC: high definition multimedia interface consumer electronics control IDE: integrated drive electronics IEEE: Institute of Electrical and Electronics Engineers IMSM: Intel Matrix Storage Manager I/O: input/output IRQ: interrupt request KB: kilobyte LAN: local area network LCD: liquid crystal display LED: light emitting diode MB: megabyte MMC: multi media card...
  • Page 146 alphanumeric: Keyboard characters including letters, numbers and other symbols, such as punctuation marks or mathematical symbols. alternating current (AC): Electric current that reverses its direction of flow at regular intervals. analog signal: A signal whose characteristics such as amplitude and frequency vary in proportion to (are an analog of) the value to be transmitted.
  • Page 147 Glossary cache memory: A section of very fast memory in which frequently used information is duplicated for quick access. Accessing data from cache is faster than accessing it from the computer's main memory. See also L1 cache, L2 cache. capacity: The amount of data that can be stored on a magnetic storage device such as a floppy diskette or hard disk drive.
  • Page 148 computer program: A set of instructions written for a computer that enable it to achieve a desired result. computer system: A combination of hardware, software, firmware, and peripheral components assembled to process data into useful information. configuration: The specific components in your system (such as the terminal, printer, and disk drives) and the settings that define how your system works.
  • Page 149 Glossary documentation: The set of manuals and/or other instructions written for the users of a computer system or application. Computer system documentation typically includes procedural and tutorial information as well as system functions. double click: To press and release the pointing device's primary button rapidly twice without moving the pointing device.
  • Page 150 The computer's feature in which certain keys in combination with the extended function key, FN, can be used to set system parameters, such as speaker volume. HW Setup: A TOSHIBA utility that lets you set the parameters for various hardware components. User’s Manual...
  • Page 151 Glossary icon: A small graphic image displayed on the screen or in the indicator panel. In Windows, an icon represents an object that the user can manipulate. i.LINK (IEEE1394): This port enables high-speed data transfer directly from external devices such as digital video cameras. input: The data or instructions you provide to a computer, communication device or other peripheral device from the keyboard or external or internal storage devices.
  • Page 152 Liquid Crystal Display (LCD): Liquid crystal sealed between two sheets of glass coated with transparent conducting material. The viewing-side coating is etched into character forming segments with leads that extend to the edge of the glass. Applying a voltage between the glass sheets.
  • Page 153 Glossary OCR: Optical Character Recognition (reader). A technique or device that uses laser or visible light to identify characters and input them into a storage device. online state: A functional state of a peripheral device when it is ready to receive or transmit data.
  • Page 154 Power Saver: A TOSHIBA utility that lets you set the parameters for various power-saving functions. program: A set of instructions a computer can execute that enables it to achieve a desired result. See also application. prompt: A message the computer provides indicating it is ready for or requires information or an action from you.
  • Page 155 TFT display: A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology with thin film transistor (TFT) to drive each cell. Touch Pad: A pointing device integrated into the TOSHIBA computer palm rest. USB: Universal Serial Bus. This serial interface lets you communicate with several devices connected in a chain to a single port on the computer.
  • Page 156 window: A portion of the screen that can display its own application, document or dialog box. Often used to mean a Microsoft Windows window. Wireless LAN: Local Area Network (LAN) through wireless communication. Wireless WAN: Wide Area Network (WAN) through wireless communication.
  • Page 157 Index AC adaptor, 1-4 additional, 1-14 connecting, 3-2 Additional AC adaptor, 8-9 Additional battery pack, 8-9 ASCII characters, 5-7 Battery charging, 6-8 extending battery life, 6-11 indicator, 6-1 Monitoring capacity, 6-10 real time clock, 1-4, 6-4 safety precautions, 6-6 save mode, 1-9 types, 6-3 Battery pack, 1-4 replacing, 6-12...
  • Page 158 Monitor, 9-14 overheating power down, Pointing device, 9-10 Power, 9-4 Real Time Clock, 9-7 Self test, 9-4 Sound system, 9-14 Support from TOSHIBA, 9-16 System start-up, 9-3 USB, 9-11 Wireless LAN, 9-14, 9-15 Processor, 1-3 Restarting the computer, 3-10 Security lock, 8-10...
  • Page 159 ScrLock, 5-3 Sound System, 1-7 headphone jack, 1-7 microphone jack, 1-7 mute hot keys, 5-3 TOSHIBA ConfigFree, 1-12 TOSHIBA Disc Creator, 1-12 Touch Pad, 1-6 using, 4-1 USB, 1-6 Video modes, B-1 Video RAM, 1-4 Wireless communication switch, 4-10 indicator, 4-11...

This manual is also suitable for:

Satellite t130Satellite pro t110Portege t130Portege t110

Table of Contents
