- Page 1 Page:1/18 LOCAL AIR CONDITIONER PAH-9016 Instructions Manual Read and save these instructions...
-
Page 2: Table Of Contents
Page:2/18 Content I.Attention Matters………………………………………………………….…..............3 II.Features and Components………………………………………………………………………………………….…………4 III. Control Setting………………………………………………………………………………………………………...….……5 IV. Protection function………………………………………………………………………………………….…………………6 V. Installation and adjustment……………………………………………………………………………………………………7 VI.Drainage Instructions………………………………………………………………………………….………………………9 VII. Maintenance…………………………………………………………………………………………………………………10 VIII.Out-of-season save…………………………………………………………………………………………………………10 IX.Troubleshooting………………………………………………………………………………………….……………………11 X.Addendum………………………………………………………………………………………………………………………11 Please read these instructions before use and repair. The drawings provided in this manual may not be the same as the physical objects. Please refer to the physical objects. -
Page 3: I.attention Matters
Page:3/18 I. Attention Matters Warnings: 1. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. 2. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.) 3. -
Page 4: Ii.features And Components
Page:4/18 gently to avoid damaging wind-guide strips. When moving the machine, make sure that it is in an upright position. The machine should stay away from gasoline, flammable gas, stoves and other heat sources. Don't disassemble, overhaul and modify the machine arbitrarily, otherwise it will cause a ... - Page 5 Page:5/18 adopts a user-friendly remote control design. Air filtration capability. Timing switch function. Protection function of automatically restarting the compressor after three minutes, a variety of other protection functions. Max operation temperature for the air conditioner Cooling: 35/24℃; heating:20/12 ℃; Temperature ...
-
Page 6: Control Setting
Page:6/18 Exhaust Pipe Assembly Window Sealing Plate Assembly 排 热 管 组 件 件 III. Control Setting 1. Control panel operation instructions 1 ） operation interface ： 1. Power Key 2. Mode Selection Key 3. Sleep Key 4. Down Key 5. -
Page 7: Protection Function
Page:7/18 value. Timing values can be set in 1-24 hours and the timing value is adjusted up or down by one hour. Sleep Mode: Press this Key to turn on the sleep mode, then the unit will work on Energy-Saving and quiet type. Note: 1. -
Page 8: Installation And Adjustment
Page:8/18 machine will automatically return to the original state. 3.3 Automatic Defrosting (cooling models have this function): The machine has automatic defrosting function. Defrosting can be achieved through four - way valve reversing. 3.4、Protection Function of the Compressor To increase the service life of the compressor, it has a 3-minute delay booting protection function after the compressor is turned off. - Page 9 Page:9/18 Notes: 1) The flat end of the exhaust pipe joints must be snapped into place. 2) The pipe cannot be distorted nor has substantial turning (greater than 45 °). Keep the ventilation of the exhaust pipe not blocked. Figure 2 Figure 3 1.3 Install the body 1.
-
Page 10: Vi.drainage Instructions
Page:10/18 Figure 5 Figure 6 Important Notice: The length of the exhaust hose shall be 280~1,500mm, and this length is based on the specifications of the air conditioning. Do not use extension tubes or replace it with other different hoses, or this may cause a malfunction. -
Page 11: Maintenance
Page:11/18 VII. Maintenance Cleaning: before cleaning and maintenance, turn off the machine and unplug the plug. 1．Clean the surface Clean with surface of machine with a wet soft cloth. Don't use chemicals, such as benzene, alcohol, gasoline, etc; otherwise, the surface of the air conditioning will be damaged or even the whole machine will bedamaged. - Page 12 Page:12/18 Note: ensure that the body is placed in a dry place and keep all machine components properly. IX.Troubleshooting 1. Information on servicing 1) Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised.
- Page 13 Page:13/18 – The ventilation machinery and outlets are operating adequately and are not obstructed; – If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant; – Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected;...
- Page 14 Page:14/18 other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. 5. Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks.
- Page 15 Page:15/18 Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them. – Cylinders shall be kept upright. – Ensure that the refrigeration system is earthed prior to charging the system with refrigerant. –...
- Page 16 Page:16/18 associated shut-off valves in good working order. Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants. In addition, a set of calibrated weighing scales shall be available and in good working order.
-
Page 17: Ix.troubleshooting
Page:17/18 IX.Troubleshooting Do not repair or disassemble the air conditioning by yourself. Unqualified repair will lead to failure of the warranty card, and may cause damage to users or their properties. Problems Reasons Solutions Turn it on after connecting it to a socket There is no electricity. -
Page 18: X.addendum
Page:18/18 X.Addendum Schematic diagram for air conditioning （The specific technical parameters of the machine shall be subject to the nameplate on the product） Capillary Condenser Compressor Evaporator NOTICE ABOUT RECYCLING Your product is designed and manufactured with high quality materials and components which can be recycled and reused.
