Panorama
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
919-980h
REGENCY FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
®
P36E Zero Clearance
Direct Vent Gas Fireplace
MODELS:
P36E-NG11 Natural Gas
ANSI Z21.88-2017
CSA 2.33-2017
P36E-LP11 Propane
Installer: Please complete the details on the back cover and leave this
manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners & Installation Manua
l
03.29.22
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Panorama P36E-NG11
Summary of Contents for Regency Panorama P36E-NG11
- Page 1 Installer: Please complete the details on the back cover and leave this Certified to/Certifié pour: CSA 2.17-2017 manual with the homeowner. ANSI Z21.88-2017 CSA 2.33-2017 Homeowner: Please keep these instructions for future reference. 919-980h REGENCY FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 03.29.22...
- Page 2 The model P36E has been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. Front...
- Page 3 INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Vented Gas Fireplace Heater to the following standards: CAN/CGA-2.17-2017, and ANSI Z21.88-2017 • CSA 2.33-2017. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
-
Page 4: Table Of Contents
table of contents Exterior Vent Termination Locations ........27 Owner’s Information Venting - Direct Vent System (Flex) ........28 4” x 6-5/8” Rigid Pipe Cross Reference Chart .......29 opy of Safety Decal for P36E-11 ...........5 Rigid Pipe Venting Systems ...........31 Decal Location .................5 Rigid Pipe Venting Arrangements ..........32 Important Information ............10 Venting Arrangements Vertical Termination ......35... -
Page 5: C Opy Of Safety Decal For P36E-11
The safety label is located on the front inside base of the unit. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 6: Ma Code - Co Detector
MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 7: Dimensions
dimensions UNIT DIMENSIONS WITH VIGNETTE AND VIGNETTE FINISHING TRIM 2 " 2" (953mm) 1-1/4” (26mm) 4 " (324mm) Optional 3 sided Vignette finishing trim (not shown) 38" (965mm) W x 33-3/4" (838mm) H 4 " (375mm) UNIT DIMENSIONS WITH SAFETY SCREEN (#515-929) AND OPTIONAL LOUVERS 36"... -
Page 8: Gas Installation Checklist
This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. - Page 9 REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed?
-
Page 10: Important Information
owner's information IMPORTANT MESSAGE YOUNG CHILDREN SHOULD BE CARE- 3. See general construction and assembly in- SAVE THESE INSTRUCTIONS FULLY SUPERVISED WHEN THEY ARE structions. The appliance and vent should be enclosed. IN THE SAME AREA AS THE APPLI- 4. This appliance must be connected to the speci- The P36E-NG or P36E-LP Direct Vent Fireplace must ANCE. -
Page 11: Lighting Procedure
owner's information LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has 3. After approximately 4 seconds the spark ignition system will spark for 60 several options for starting/operating the appliance using the power button seconds to light the pilot. and ON/OFF key on the hand held transmitter. -
Page 12: Copy Of The Lighting Plate Instructions
owner's information COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 13: Proflame Ii Remote Control Operating Instructions
owner's information PROFLAME I REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 1 is an integrated part of the TECHNICAL DATA Proflame 1 System, which consists of these elements: • Proflame 1 Transmitter, to be used in conjunction with: REMOTE CONTROL •... - Page 14 owner's information Temperature indication Display Remote-Flame Control With the system in the "OFF" position, press the Thermostat Key and The Proflame has six (6) flame levels. With the system on, and the flame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the flame height by one step until the flame is turned off.
- Page 15 owner's information Smart Thermostat (Transmitter Operation) Remote Dimmer Control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual room to the AUX icon (fig.
- Page 16 owner's information OW BATTERY POWER DETECTION Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (Fig.
-
Page 17: Proflame I Remote Receiver Battery Replacement
installation PROFLAME I REMOTE RECEIVER BATTERY REPLACEMENT & BATTERY BACKUP IF 120V POWER IS LOST WITHIN HOME Remote Receiver/Battery Holder Battery Replacement & Battery Back up if 120 volt If no fan control module or AC adaptor is installed, 4 AA batteries are mandatory in the remote receiver to operate the appliance when using power is lost witihin home the remote control. -
Page 18: Installation Checklist
installation 2) If required, adjusting the primary air to ensure INSTALLATION CHECKLIST that the flame does not carbon. First allow the Note: For vent terminations see the unit to burn for 15-20 min. to stabilize. " E x t e r i o r Ve n t Te r m i n a t i o n 1) Locate appliance. -
Page 19: Clearances
Minimum Clearance from Top of Unit to: Ceiling from top of unit. 32" (1016mm) Side Wall Clearances: 6"* (152mm) * Measured from edge of unit. See the "Regency Clearances for dimensions" section. Horizontal Vent Clearances: 2" (51mm) Side 1-1/2" (38mm) Bottom 1-1/2"... -
Page 20: Mantel Leg Clearances
installation CLEARANCES Min. 6" (152mm) MANTEL LEG CLEARANCES Combustible mantel leg clearances as per diagram: Maximum 1-1/2" projection at 2" minimum clearance. 7-1/2” Side Wall Unit width 36-1/6" Top View Allowable mantel leg projection P36E-11 Zero Clearance Direct Vent Gas Fireplace... -
Page 21: Combustible Mantel Clearances
installation COMBUSTIBLE MANTEL CLEARANCES Because of the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in the diagram below. Note: Mantel starts at *1" deep and ends at *12" deep. **For Vignette with Vignette Finishing Trim flush finish, all materials (framing & finishing) below the The non-combustible mantle when mantel and the width of the Vignette finishing trim, (37 1/2") must be non-combustible if a lower mantel is desired. -
Page 22: Framing
installation FRAMING 1. Determine the total thickness of facing material (e.g. non combustible plus ceramic tiles) to allow the finished surface to be flush with the front of the unit. Total facing thickness can vary from 1/2" (13mm) to 1-1/4" (32mm) thick with Vignette only, Vignette + Vignette Finishing Trim Stepped Finish and Safety Screen and Louvers. - Page 23 installation FRAMING WITH VIGNETTE FRAMING WITH VIGNETTE FRAMING WITH FACEPLATE & VIGNETTE FACEPLATE & FINISHING TRIM LOUVERS AND SAFETY SCREEN FINISHING TRIM, STEPPED FINISH FINISHED FLUSH Frame in the enclosure for the unit with framing Frame in the enclosure for the unit with framing material.
-
Page 24: Finishing
installation FINISHING IMPORTANT FINISHING DETAIL NOTE: Before placing unit into final position - it is important to know the total thickness / height of finished hearth (tile, carpet, etc.) The base of the fireplace should be level or higher than the finished hearth height. Diagram 2 Diagram 1 Note:... -
Page 25: Wall Mount On/Off Switch And Remote Receiver Installation
installation WALL MOUNT ON/OFF SWITCH AND REMOTE RECEIVER INSTALLATION Required for all installations - including Proflame remote controls IMPORTANT INSTALLATION NOTE: The Receiver must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE. -
Page 26: Unit Assembly Prior To Installation
installation UNIT ASSEMBLY 2) Fold out the two nailing strips on each side. 1) Mount Top Facing Support using the 3 supplied screws into the three pre-punched screw holes PRIOR TO on the top front of the unit. Use hole positions INSTALLATION A, B, or C depending on your facing depth. -
Page 27: Exterior Vent Termination Locations
installation EXTERIOR VENT TERMINATION LOCATIONS Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 18"(46cm) 18"(46cm) from the center line of the terminal (check with the local code) -
Page 28: Venting - Direct Vent System (Flex)
The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in the "Exterior Vent Termination Locations" section. Regency Direct Vent (Flex) System Termination Kit (Part # 946-515) includes all the parts needed to install the P36E with a maximum run of 4 feet. -
Page 29: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
4” X 6-5/8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from Regency. Note: Olympia Ventis DV is only approved for certain models. See list of approved models in cross-reference chart. - Page 30 TM-4TR VDV-FS04 * Not available from Regency ***Olympia Ventis DV application for the following units only when using 4" x 6-5/8" vent system: B36XTE, B36XTCE, all City Series 40 models, CV72E/CB72E (power-vented models only), G600C, G600C-1, G600EC, G800C, G800C-1, G800EC, P36, P36E, and RC500E.
-
Page 31: Rigid Pipe Venting Systems
The Regency AstroCap and Regency Riser Vent terminal are certified for installations using Regency venting systems as well as any specific chimney systems listed in this manual. AstroCap is a proprietary trademark of Regency Fireplace Products. -
Page 32: Rigid Pipe Venting Arrangements
RIGID PIPE VENTING ARRANGEMENTS HORIZONTAL TERMINATIONS Regency DIRECT VENT SYSTEM (FLEX) (Propane & Natural Gas) The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 elbow (two 45 elbows equal one 90 elbow). Note: Must use optional rigid pipe adaptor (Part # 510-994) when using Rigid Pipe venting systems. - Page 33 installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 W i t h t h e s e o p t i o n s , 0' Min. 2' Max. maximum total pipe length 1' Min.
- Page 34 installation Vertical Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option V + V1 With these options, 0' Min. 2' Max. 1' Min. max. total pipe length 1' Min. 4' Max. 2' Min. is 30 feet with min. of 6 feet total vertical 2' Min.
-
Page 35: Venting Arrangements Vertical Termination
installation RIGID PIPE VENTING ARRANGEMENTS Vertical Terminations (Propane & Natural Gas) elbow, with Rigid Pipe The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two 90 vent systems for Propane and Natural Gas. •... - Page 36 installation The P36E is approved for a 40 ft. straight vertical, with rigid pipe vent systems for Propane and Natural Gas, as per the diagram 1. The shaded area in the diagram 1 shows all allowable combinations of straight vertical and offset to vertical terminations with rigid pipe vent systems for Propane and Natural Gas.
-
Page 37: Vertical Termination - Co-Linear Flex System
installation VERTICAL TERMINATION - CO-LINEAR FLEX SYSTEM THE APPLIANCE MUST NOT BE Masonry chimneys may take various contours which the flexible liner will accommodate. However, keep the CONNECTED TO A CHIMNEY FLUE flexible liner as straight as possible, avoid unnecessary bending. SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. -
Page 38: Venting Arrangement - Vertical Terminations
installation VENTING ARRANGEMENTS - VERTICAL TERMINATION with Co-linear Flex System for both Residential & Manufactured Homes into Masonry Fireplaces Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. P36E-11 Zero Clearance Direct Vent Gas Fireplace... -
Page 39: Dura-Vent Horizontal Termination
installation DURA-VENT HORIZONTAL b) Horizontal runs of vent must be supported every three feet. Wall straps are available for TERMINATIONS this purpose. Install the vent system according to the 5) Mark the wall for a 10" x 10" square hole. The manufacturer's instructions included with the center of the square hole should line up with components. -
Page 40: Dura-Vent Vertical Terminations
installation DURA-VENT VERTICAL 4) Assemble the desired lengths of pipe and elbows. Ensure that all pipes and elbow con- TERMINATIONS nections are in the fully twist-locked position and sealed. 1) Maintain the 1-1/4" clearances 5) Cut a hole in the roof centered on the small (air spaces) to combustibles when drilled hole placed in the roof in Step 2. -
Page 41: Direct Vent System (Flex) Installation Procedures
installation NOTE: Note that for steep roof pitches, the vertical height Note: To make Horizontal sections must be must be increased. A poor draft, or down drafting the installation a l l i d e W Furstrp.eps O u t s more aesthetically can result from high wind conditions near big trees supported at intervals not exceeding... -
Page 42: Vertical Termination - 4" X 6-7/8" Venting
installation VERTICAL TERMINATION VERTICAL TERMINATION 4" X 6-7/8" VENTING 4" X 6-7/8" VENTING - VERTICAL FLEX VENT KIT (946-755) 1. Maintain the 1-½” (38 mm) clearance (air space) to combustibles when 11. Secure inner fl ex pipe to pipe adaptor by using Mill-Pac over the adaptor. passing through ceilings, walls, fl... -
Page 43: Vertical Flue Extension Kit (Part #946-756)
installation VERTICAL FLUE EXTENSION KIT (PART #946-756) VERTICAL FLUE EXTENSION KIT (PART # 946-756) 20 foot (6.1 m) Flex pipe Extension CEILING FIRESTOP/FIRESTOP SPACER (Used in conjunction with the 946-755 Vertical Flex kit and 948-367/P flex 4" (102 mm) inner ( PART # 946-757) to flex adaptor). -
Page 44: System Data
Circulation Fan: variable speed 130 CFM. For USA installations follow local codes and/or the Log Set: Ceramic fibre, 7 per set. Vent System or Regency Direct Vent System current National Fuel Gas Code, ANSI Z223.1. (Flex) Vent System: Simpson Dura-Vent Direct Vent... -
Page 45: Pilot Adjustment
1/2 psig. (3.45 kPa). Disconnect piping from valve at pressures over 1/2 psig. Note: If you have an incorrect flame pattern, contact your Regency ® The manifold pressure is controlled by a regulator dealer for further instructions. -
Page 46: Conversion From Ng To Lp
installation P36E-11 CONVERSION FROM NG TO LP Conversion from NG to LPG P36E-11 using SIT 885 Gas Valve for P36E-11 using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 9) Disconnect the cable from the pressure Each Kit contains one LP Pull off the pilot cap to expose the pilot regulator motor. -
Page 47: Optional Brick Panels
installation OPTIONAL BRICK PANELS 5) Install the 2 brick retaining clips, one on each side. 1) Remove Faceplate if installed. 2) Undo the bottom 2 door latches and open and remove glass door. Remove logs. Note: The logs must not be in the unit. 3) Insert the back brick panel first by carefully slipping it between the back wall of the firebox and the rear log bracket. -
Page 48: Optional Enamel Panels
installation P36D / P36DE/ P36E OPTIONAL ENAMEL PANELS OPTIONAL ENAMEL PANELS Before installation, panels must be handled and cleaned as per instructions noted below: Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for dam- age after installation will not receive consideration. -
Page 49: Oak Log Set Installation
GAS FIREPLACE installation OAK LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The gas log kit (Part # 512-930) contains the following: Place Log 02-49 on the rear log support pins with the fl... - Page 50 GAS FIREPLACE installation Position Log 02-53 across the cutouts in Logs 02-49 and Sit Log 02-50 on the front left side of the burner. Push the 02-51 with the notch on the left side of the log fi tting into back of the log against the 2 front brackets with the notch the 2nd grate tab.
- Page 51 GAS FIREPLACE installation 10) Place the embers on the front of the burner tray in the Place Log 02-52 between Logs 02-51 and 02-49 and on places shown on the photo. the indentation on Log 02-54. The bottom right end sits behind the rear grate tab.
-
Page 52: Standard Flush Door
installation STANDARD FLUSH DOOR Note: Flush door must be installed prior to the installation of the Be careful that the glass gasket does not roll up; there must be a gap Vignette faceplate. between the gasket and the door lip to ensure that the door sits securely on the unit, see Diagram 2. -
Page 53: Vignette Faceplate And Safety Screen Installation
installation Vignette faceplate and safety screen installation VIGNETTE FACEPLATE AND SAFETY SCREEN INSTALLATION 1. Hook the outer Vignette frame onto the unit. Brackets on the frame hook on to tabs in the unit. Note: Use the inner slots for the P36/P36E units and the outer slots for the P36D. P36D P36/P36E Adjustable Mounting Brackets are in increments... -
Page 54: Vignette Finishing Trim Installation
installation VIGNETTE FINISHING TRIM INSTALLATION VIGNETTE FINISHING TRIM *If finishing the unit Flush with Vignette Finishing Trim - remove top nailing strip from unit if installed–use nailing strip supplied with top trim piece. Side nailing strips are bent around side trim piece in flush finish application. See nailing strip section in manual for details. *If finishing the unit Flush with Vignette Finishing Trim - remove top nailing strip from unit if installed–use nailing strip supplied with top trim piece. -
Page 55: Optional Vignette Inlay Installation
installation OPTIONAL VIGNETTE INLAY OPTIONAL VIGNETTE INLAY INSTALLATION NOTE: Inlay not exactly as shown below. 1. Remove Inner Vignette Frame from unit if already installed. 5. Secure the Inlay in position with supplied brackets, washers, and nuts as shown. 2. Line up the inlay top bracket in the space between the safety screen frame and Vignette Frame. -
Page 56: Optional Finishing Trim
installation OPTIONAL FINISHING TRIM OPTIONAL FINISHING TRIM NOTE: Remove the safety screen, Vignette Faceplate (P33 units only: remove 2 screws securing lower legs of Faceplate) and glass door prior to installing the Finishing Trim. Install the Finishing Trim sides as shown in the diagram, line up the holes in the side trim with the holes in the firebox side. -
Page 57: Safety Screen Installation - With Optional Louvers
installation SAFETY SCREEN INSTALLATION - SAFETY SCREEN INSTALLATION - MUST BE USED WITH OPTIONAL LOUVERS MUST BE USED WITH OPTIONAL LOUVERS 1. Hook the safety screen frame over the glass door frame. 2. Gently lower screen on to glass door frame–two (2) magnets located on inside lower part of the screen frame will secure the screen to the glass door frame. 3. To remove–reverse steps. Magnet locations OPTIONAL FLUSH LOUVERS INSTALLATION - USED WITH SAFETY SCREEN # 515-929 07.21.15 919-558a 1. -
Page 58: Ac Power Adaptor Installation (For Surefire Systems)
installation AC POWER ADAPTOR INSTALLATION (FOR SUREFIRE SYSTEMS) AC POWER ADAPTOR INSTALLATION (FOR SUREFIRE SYSTEMS) An AC power adaptor is supplied with this appliance and may be installed as a constant power source for the SureFire system. NOTE: AC power adaptor is not required when using GTMF Remote with fan control module and must be disconnected. IMPORTANT: Recommend removing the 4-AA batteries in the SureFire receiver. -
Page 59: Wiring Diagram
installation WIRING DIAGRAM Though this heater does not require 120 volt AC supply for burner operation, it is recommended as a primary power source and is required for the optional blower. Batteries should only be used as a secondary power source when power is lost within the home. (Do not cut the ground terminal off under any circumstances.) NOTE: Even if the fan is not purchased with the unit, it is still a good idea to bring power to the receptacle box (provided with the unit) in case the fan is installed at a later date. -
Page 60: Wiring Diagram With Optional Fan
installation WIRING DIAGRAM WITH OPTIONAL FAN SureFire™ Switch 0.584.622 Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 61: Optional Fan Installation
installation OPTIONAL FAN INSTALLATION OPTIONAL FAN INSTALLATION 120 Volt AC power is needed for the fan. The fan can be hard wired if desired. The outlet should be installed in the recep- tacle box on the left hand side by a qualified electrician. The neutral (wider) slot of the polarized outlet should be at the top. -
Page 62: Optional Wall Thermostat Installation
installation OPTIONAL WALL THERMOSTAT INSTALLATION 4. Connect the other thermostat lead to male connector disconnected This installation must be completed during initial install with the front access from Step1using a female spade connector - see picture below. panel removed. A wall thermostat may be installed if desired. Recommended: The wall thermostat should be mounted beside the Remote/Unit Receiver which comes standard with the appliance. -
Page 63: Operating Instructions Operating Instructions
Blower: glass removed. CAUTION: Carbon will be produced if air shutter Regency gas appliances use high tech blowers is closed too much. to push heated air farther into the room. It is not 5) Verify that the venting and cap are unobstructed. -
Page 64: Lighting Procedure / Shutdown Procedure
operating instructions LIGHTING PROCEDURE 3. After approximately 4 seconds the spark ignition system will spark for 60 IMPORTANT: The remote control system supplied with this appliance has seconds to light the main burner. several options for starting/operating the appliance using the power button and ON/OFF key on the hand held transmitter. -
Page 65: Copy Of The Lighting Plate Instructions
operating instructions COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 66: Maintenance Maintenance Instructions
Flush Door" section. Remove the 4 glass clips from each corner. Slide in the new replacement glass. Note: Never operate the appliance without Your Regency fireplace is supplied with high tem- Push the 4 glass clips back onto the frame. The the glass properly secured in place. -
Page 67: Removing Valve
maintenance REMOVING VALVE 9) Remove the rear log stand by removing the 2 screws. 1) Shut off the gas and electrical supply. 10) Remove the 10 screws securing the valve tray assembly in place (Diagram 2) Remove the faceplate, safety screen and glass 2) and then lift the entire assembly out door–see detailed instructions in manual. -
Page 68: Gas Maintenance
Gas Maintenance GAS MAINTENANCE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter • Pressure relief gaskets/doors •... -
Page 69: Main Assembly
parts list MAIN ASSEMBLY Part # Description Part # Description 438-917 Fan Kit Complete 948-045 Chain 948-025 Spring 910-331/P Replacement Fan Motor (120 V) 910-428 Duplex Receptacle 911-159 120 Volt Power Cord 910-429 Box - Receptacle 910-430 Cover - Receptacle 510-994 Rigid Pipe Adaptor 904-687... - Page 70 parts list P36E-11 Zero Clearance Direct Vent Gas Fireplace...
-
Page 71: Burner Assembly & Log Set
parts list BURNER ASSEMBLY & LOG SET Part # Description 515-578E/P Valve Assy - Natural Gas 515-780E/P Valve Assy - Propane Valve Tray - NG/LP 430-055 Gasket - Valve Access Plate 911-084 SIT Valve 885 - NG 911-085 SIT Valve 885 - NG 911-276 Pilot Assy - S.I.T. -
Page 72: Vignette Faceplate And Finishing Trim
parts list VIGNETTE FACEPLATE AND FINISHING TRIM Part # Description 515-922 Vignette Platinum 515-923 Vignette Black Chrome 515-924 Vignette Black 515-926 Vignette Tuscan Sunset 515-918 Vignette Door Inlay Black Chrome 515-919 Vignette Door Inlay Metallic Black 515-920 Vignette Door Inlay Tuscan Sunset 515-922 Vignette Front Platinum 515-928... -
Page 73: Safety Screen And Louvers
SAFETY SCREEN AND LOUVERS Part # Description 510-922 Flush louvers black 515-929 Safety Screen 948-223 Regency ® Logo Plate 515-986 3 Sided Finishing Trim P36E-11 Zero Clearance Direct Vent Gas Fireplace... -
Page 74: Warranty
FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: February 2019 Regency Gas Products Warranty P36E-11 Zero Clearance Direct Vent Gas Fireplace... - Page 75 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: February 2019 Regency Gas Products Warranty P36E-11 Zero Clearance Direct Vent Gas Fireplace...
- Page 76 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 77 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 78 warranty P36E-11 Zero Clearance Direct Vent Gas Fireplace...
- Page 79 P36E-11 Zero Clearance Direct Vent Gas Fireplace...
- Page 80 Dealer Name & Address: ___________________________________ ________________________________________________________ Installer: ________________________________________________ Phone #: ________________________________________________ Date Installed: ___________________________________________ Serial #: _________________________________________________ Printed in Canada Regency® and SureFire are trademarks of Regency Fireplace Products International Ltd. © Copyright 2022, Regency Fireplace Products International Ltd. All rights reserved.
