WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-399
P36 Zero Clearance
Direct Vent Gas Fireplace
MODELS:
P36-NG10 Natural Gas
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
REGENCY FIREPLACE PRODUCTS. 6988 Venture St., Delta, BC Canada, V4G 1H4
P36-LP10 Propane
Owners & Installation Manual
P36 Video
01.26.15
Advertisement
Table of Contents
Related Manuals for Regency P36-LP10
Summary of Contents for Regency P36-LP10
- Page 1 - Installation and service must be performed by a qualified installer, service agency or the gas supplier. Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. REGENCY FIREPLACE PRODUCTS. 6988 Venture St., Delta, BC Canada, V4G 1H4 919-399 01.26.15...
-
Page 2: To The New Owner
To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY FIREPLACE PRODUCTS. The P36 has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. -
Page 3: Mobile/Manufactured Homes Information
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Vented Gas Fireplace Heater to the following standards: CAN/CGA-2.17-M91, and ANSI Z21.88-2014 • CSA 2.33-2014. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada. -
Page 4: Table Of Contents
table of contents First Fire ..............47 To the New Owner ............2 Aeration Adjustment ............47 Mobile/Manufactured Homes Information......3 Normal Operating Sounds of Gas Appliances .....47 Safety Decal ..............5 Maintenance Instructions..........48 MA Code - CO Detector..........6 General Vent Maintenance ..........48 (for the State of Massachusetts only) Log Replacement ............48 Unit Dimensions with Vignette Faceplate ......7 Thermopile/Thermocouple...........48... -
Page 5: Safety Decal
The safety label is located on the front inside base of the unit. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 6: Ma Code - Co Detector
installation MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 7: (For The State Of Massachusetts Only) Unit Dimensions With Vignette Faceplate
dimensions UNIT DIMENSIONS WITH VIGNETTE FACEPLATE 8 " (841mm) 16 " 15" (381mm) (916mm) 34-3/16” 16 " 16 " (864mm) (56mm) (325mm) Optional 3 sided finishing trim (not shown) 38" W x 33-3/4" H P36-10 Zero Clearance Direct Vent Gas Fireplace |... -
Page 8: Important Message
installation IMPORTANT MESSAGE 4) This appliance must be connected to the speci- YOUNG CHILDREN SHOULD BE CARE- fied vent and termination cap to the outside of SAVE THESE the building envelope. Never vent to another FULLY SUPERVISED WHEN THEY ARE room or inside a building. -
Page 9: Installation Checklist
installation INSTALLATION LOCATING YOUR 7) We recommend that you plan your installation on CHECKLIST GAS FIREPLACE paper using exact measurements for clearances and floor protection before actually installing this 1) Locate appliance. Refer to the following 1) When selecting a location for your fireplace, appliance. -
Page 10: Clearances
installation CLEARANCES The clearances listed below are Minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. Clearance to Combustibles from: Back 0"... -
Page 11: Combustible Mantel Clearances
installation CLEARANCES Min. 6" (152mm) COMBUSTIBLE MANTEL CLEARANCES Because of the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in the diagram below. Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible board. -
Page 12: Combustible Mantel Leg Clearances
REGENCY ® MANTEL LEG CLEARANCES Combustible mantel leg clearances as per diagram: Maximum 1-1/2" projection at 2" minimum clearance. 12 | P36-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 13: Framing And Finishing
installation FRAMING AND FINISHING 1) Determine the total thickness of facing mate- rial (e.g. non combustible plus ceramic tiles) 2) Frame in the enclosure for the unit with 3) For exterior walls, insulate the enclosure to allow the finished surface to be flush with framing material. -
Page 14: Finishing
installation FINISHING IMPORTANT FINISHING DETAIL NOTE: Before placing unit into final position - it is important to know the total thickness / height of finished hearth (tile, carpet, etc.) The base of the fireplace should be level or higher than the finished hearth height. Diagram 1 Note: All non-combustible and combustible facing material should... -
Page 15: Wall Mount On / Off Switch Receiver Installation
installation WALL MOUNT ON / OFF SWITCH AND REMOTE RECEIVER INSTALLATION REQUIRED FOR ALL INSTALLATIONS - INCLUDING PROFLAME REMOTE CONTROLS IMPORTANT INSTALLATION NOTE: The Receiver must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE. -
Page 16: Unit Assembly Prior To Installation
installation Top Facing Support & UNIT ASSEMBLY "C" Screw Position: Side Nailing Strips For a facing material depth of 1-1/4" (32mm), PRIOR TO the top facing support must be reversed. Determine the total thickness of facing material INSTALLATION (e.g. non combustible plus ceramic tiles) to allow the finished surface to be flush with the front of The Top Facing Support, the Side Nailing Strips the unit. -
Page 17: Exterior Vent Termination Locations
installation EXTERIOR VENT TERMINATION LOCATIONS Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 18"(46cm) 18"(46cm) from the center line of the terminal (check with the local code) -
Page 18: Venting
Warnock Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in the "Exterior Vent Termination Locations" section. Regency Direct Vent (Flex) System Termination Kit (Part # 946-515) includes all the parts needed to install the P36 with a maximum run of 4 feet. -
Page 19: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
4DT-FS 4DFSP 4DFS SV4BF TM-4CS Trim Plate-Black 4DT-TP 4DFPB 4DcP SV4LA TM-4TP Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fi re.com P36-10 Zero Clearance Direct Vent Gas Fireplace |... - Page 20 Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fi re.com...
-
Page 21: Rigid Pipe Venting Arrangements
The Regency AstroCap and Regency Riser Vent terminal are certified for installations using Regencyventing systems as well as Simpson Dura-Vent ® Direct Vent , American Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. -
Page 22: Rigid Pipe Venting Arrangements
installation RIGID PIPE VENTING ARRANGEMENTS HORIZONTAL TERMINATIONS RegencyDIRECT VENT SYSTEM (FLEX) (Propane & Natural Gas) The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 elbow (two 45 elbows equal one 90 elbow). Note: Must use optional rigid pipe adaptor (Part # 510-994) when using Rigid Pipe venting systems. All Rigid Pipe Systems 4"... - Page 23 installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 W i t h t h e s e o p t i o n s , 0' Min. 2' Max. maximum total pipe length 1' Min.
-
Page 24: Venting Arrangements - Vertical Termination
installation RIGID PIPE VENTING ARRANGEMENTS VERTICAL TERMINATIONS (Propane & Natural Gas) The shaded area in the diagram shows all allowable combinations of straight vertical and elbow, with Rigid Pipe vent systems for Propane offset to vertical terminations, using two 90 and Natural Gas. - Page 25 installation • Vent must be supported at offsets. • Firestops are required at each floor level and whenever passing through a wall. • Maintain clearances to combustibles. Note: Must use optional rigid pipe adaptor when using rigid vent systems (Part # 510-994). P36-10 Zero Clearance Direct Vent Gas Fireplace |...
- Page 26 installation Vertical Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option V + V1 With these options, 0' Min. 2' Max. 1' Min. max. total pipe length 1' Min. 4' Max. 2' Min. is 30 feet with min. of 6 feet total vertical 2' Min.
-
Page 27: Vertical Termination - Co-Linear Flex System
installation VERTICAL TERMINATION - CO-LINEAR FLEX SYSTEM INTO A MASONRY CHIMNEY THE APPLIANCE MUST NOT BE Masonry chimneys may take various contours which the flexible liner will accommodate. However, CONNECTED TO A CHIMNEY FLUE keep the flexible liner as straight as possible, avoid unnecessary bending. SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. - Page 28 installation VENTING ARRANGEMENTS - VERTICAL TERMINATION with Co-linear Flex System for both Residential & Manufactured Homes into Masonry Fireplaces Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. 28 | P36-10 Zero Clearance Direct Vent Gas Fireplace...
-
Page 29: Dura-Vent Horizontal Terminations
installation DURA-VENT HORIZONTAL b) Horizontal runs of vent must be supported every three feet. Wall straps TERMINATIONS are available for this purpose. Install the vent system according to the 5) Mark the wall for a 10" x 10" square hole. The manufacturer's instructions included with center of the square hole should line up with the components. -
Page 30: Dura-Vent Vertical Terminations
installation DURA-VENT VERTICAL 4) Assemble the desired lengths of pipe and TERMINATIONS elbows. Ensure that all pipes and elbow connections are in the fully twist-locked position and sealed. 1) Maintain the 1-1/4" clearances (air spaces) to combustibles 5) Cut a hole in the roof centered on the small when passing through ceilings, drilled hole placed in the roof in Step 2. -
Page 31: Direct Vent System (Flex) Installation Procedures
installation be increased. A poor draft, or down drafting N o t e : To m a k e 4) Separate the 2 halves of the wall thimble and can result from high wind conditions near big t h e i n s t a l l a t i o n securely fasten the one with the tabs to the trees or adjoining roof lines, in these cases,... -
Page 32: System Data
The gas line connection may be made of rigid (High) 11"+/- 0.2" w.c. Vent System or Regency Direct Vent System (Flex) pipe, copper pipe or an approved flex connector. Electrical: 120 V A.C. System. (If you are using rigid pipe, ensure that the valve Circulation Fan: variable speed 130 CFM. -
Page 33: Pilot Adjustment
installation PILOT ADJUSTMENT GAS PIPE PRESSURE SIT 829 VALVE DESCRIPTION TESTING 1) Gas on/off knob Periodically check the pilot flames. Correct 2) Electronically Operated Hi/Lo flame pattern has three strong blue flames: 3) Pilot Adjustment The appliance must be isolated from the gas 1 flowing around the thermopile, 1 around 4) Thermocouple Connection - option supply piping system by closing its individual... -
Page 34: Conversion From Ng To Lp
installation CONVERSION FROM NG TO LP Conversion from NG to LPG for FOR P36-10 USING SIT 829 NOVA GAS VALVE P36D-10 / P36-10 THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Remove burner orifice with a 1/2"... -
Page 35: Optional Brick Panels
installation OPTIONAL BRICK PANELS 5. Install the 2 brick retaining clips, one on each side. 1. Remove Faceplate, Safety Screen if already installed. 2. Undo the bottom 2 door latches and open and remove glass door. Remove logs. Note: The logs must not be in the unit. 3. -
Page 36: Log Set Installation
GAS FIREPLACE installation LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The gas log kit (Part # 512-930) contains the following: Place Log 02-49 on the rear log support pins with the fl... - Page 37 GAS FIREPLACE installation Position Log 02-53 across the cutouts in Logs 02-49 and Sit Log 02-50 on the front left side of the burner. Push the 02-51 with the notch on the left side of the log fi tting into back of the log against the 2 front brackets with the notch the 2nd grate tab.
- Page 38 GAS FIREPLACE installation 10) Place the embers on the front of the burner tray in the Place Log 02-52 between Logs 02-51 and 02-49 and on the indentation on Log 02-54. The bottom right end sits places shown on the photo. behind the rear grate tab.
-
Page 39: Standard Flush Door
installation STANDARD FLUSH DOOR The standard flush door comes with a black frame. To install the frame, Be careful that the glass gasket does not roll up; there must be a gap simply hook the top door flange onto the top of the unit and swing the between the gasket and the door lip to ensure that the door sits securely door towards the unit, see Diagram 1. -
Page 40: Vignette Faceplate And Safety Screen Installation
installation VIGNETTE FACEPLATE AND SAFETY SCREEN INSTALLATION Vignette faceplate and safety screen installation 1. Hook the outer Vignette frame onto the unit. Brackets on the frame hook on to tabs in the unit. Note: Use the inner slots for the P36/P36E units and the outer slots for the P36D. P36D P36/P36E 2. -
Page 41: Optional Finishing Trim
installation OPTIONAL FINISHING TRIM OPTIONAL FINISHING TRIM NOTE: Remove the safety screen, Vignette Faceplate (P33 units only: remove 2 screws securing lower legs of Faceplate) and glass door prior to installing the Finishing Trim. Install the Finishing Trim sides as shown in the diagram, line up the holes in the side trim with the holes in the firebox side. -
Page 42: Wall Thermostat (Optional)
installation WALL THERMOSTAT DC SPARK IGNITER (OPTIONAL) BATTERY INSTALLATION A wall thermostat may be installed if desired, Install the supplied battery into the DC Sparker Box connect the wires as per the wiring diagram. by opening the battery compartment. Use the table below to determine the maximum wire length. -
Page 43: Wiring Diagrams
installation WIRING DIAGRAMS NOTE: Even if the fan is not purchased This heater does not require a 120V A.C. sup- (Do not cut the ground terminal off under with the unit, it is still a good idea to ply for operation. In case of a power failure, the any circumstances.) bring power to the receptacle box burner switch and the optional remote control/... -
Page 44: Optional Fan Installation
installation OPTIONAL FAN INSTALLATION OPTIONAL FAN INSTALLATION 120 Volt AC power is needed for the fan. The fan can be hard wired if desired. The outlet should be installed in the recep- tacle box on the left hand side by a qualified electrician. The neutral (wider) slot of the polarized outlet should be at the top. -
Page 45: Operating Instructions
operating instructions OPERATING LIGHTING SHUTDOWN INSTRUCTIONS PROCEDURE PROCEDURE IMPORTANT 1) Read and understand these instructions 1. Press "OFF" on the remote or slide receiver switch Prior to igniting or re igniting before operating this appliance. from remote to "OFF". the pilot, remove the glass 2) Check to see that all wiring is correct and 2. -
Page 46: Lighting Plate Instructions
operating instructions COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 47: First Fire
DO NOT BURN THE APPLIANCE WITH- Blower: Regency gas appliances use high tech blowers OUT THE GLASS FRONT IN PLACE. to push heated air farther into the room. It is not unusual for the fan to make a "whirring" sound During the first few fires, a white film when ON. -
Page 48: Maintenance Instructions
When cleaning the logs, use a soft clean paint 4. Inspect joints, to verify that no pipe sections or brush as the logs are fragile and easily dam- Your Regency fireplace is supplied with high tem- fittings have been disturbed, and consequently aged. -
Page 49: Removing Valve
maintenance REMOVING VALVE INSTALLING VALVE 10. Remove 10 screws securing the valve tray as- sembly in place (Diagram 3) and then lift the entire assembly out (Diagram 4). 1. Shut off the gas and electrical supply. 1. Attach the valve to the valve bracket with the 4 (m5x8 metric) screws provided. -
Page 50: Main Assembly
parts list MAIN ASSEMBLY Part # Description Part # Description Burner 948-045 Chain 438-917 Fan Assembly 120V 948-025 Spring 910-428 Duplex Receptacle 910-331/P Fan Motor (120 V) 910-429 Box - Receptacle 510-994 Rigid Pipe Adaptor 910-430 Cover - Receptacle 904-687 Clamp Connector 946-556 Heat Wave Duct Kit (Optional) - Page 51 parts list MAIN ASSEMBLY P36-10 Zero Clearance Direct Vent Gas Fireplace |...
-
Page 52: Burner Assembly & Log Set
parts list BURNER ASSEMBLY & LOG SET Part # Description 515-474/P Valve Assy - Natural Gas 515-476/P Valve Assy - Propane Valve Tray - NG/LP 430-055 Gasket - Valve Access Plate 911-084 SIT Valve 829 - NG 911-085 SIT Valve 829 - NG Valve Bracket Firebox Base 910-038... -
Page 53: Vignette Faceplate And Finishing Trim
parts list VIGNETTE FACEPLATE AND FINISHING TRIM Part # Description 515-923 Vignette Black Chrome 515-924 Vignette Black 515-926 Vignette Tuscan Sunset P36-10 Zero Clearance Direct Vent Gas Fireplace |... - Page 54 notes 54 | P36-10 Zero Clearance Direct Vent Gas Fireplace...
-
Page 55: Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-field service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers. - Page 56 Dealer Name & Address: ____________________________________________________ _________________________________________________________________________ P36 Video Installer: _________________________________________________________________ Phone #: _________________________________________________________________ Date Installed: ____________________________________________________________ Serial No.: __________________________________________________________ Printed in Canada Panorama, AstroCap,Tripoli, HeatWave and Heat Release are trademarks of Fireplace Products International Ltd. © Copyright 2014 Regency Fireplace Products. All rights reserved.
