OWNER'S
MANUAL
STARTING SERIAL #:
L111-131001
MODEL NO.
QBT14560A
QBT18560A
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
1602 Corporate Dr., WARRENSBURG, MO 64093
Manufacturing quality lawn care equipment since 1945
18372 Rev 11-131
60" FINISH CUT
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE 660-747-8183 FAX 660-747-8650
Made In The
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QUADBOSS QBT14560A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Swisher QUADBOSS QBT14560A

  • Page 1 OWNER’S MANUAL STARTING SERIAL #: L111-131001 MODEL NO. QBT14560A QBT18560A 60” FINISH CUT TRAILMOWER IMPORTANT Assembly Read and follow all Safety Precautions Operation and Instructions before operating this Service and Adjustment equipment. Repair Parts Made In The 1602 Corporate Dr., WARRENSBURG, MO 64093 PHONE 660-747-8183 FAX 660-747-8650 Manufacturing quality lawn care equipment since 1945 18372 Rev 11-131...
  • Page 2: Limited Warranty

    Should you have any questions concerning this warranty, please contact us toll -free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.
  • Page 4 For model year 2006 the EECS on your mower includes the liquid fuel lines, fuel line connectors, and fuel line clamps. Where a warrantable condition exists, Swisher will repair at no cost to you.
  • Page 5: Safety Decals

    SAFETY DECALS Replace decals immediately if damaged. Order by part number from Swisher. OD11- No step Decal OD45- Warning Decal OD55- Triangle Danger Decal OD33- Speed Decal OD43- Flying Debris Decal OD29- Danger Decal...
  • Page 6 REQUIRED ASSEMBLY FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut and washers from caster shaft. 2. Place one washer on the shaft of the caster/wheel sub-assembly. 3. Slide same shaft through the bearing/frame with wheel towards the ground. 4. Place the other washer on the shaft; it should be resting on the top bearing. 5.
  • Page 7: Intended Use

    STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. TrailMowers with electric start engines will need a battery (sold separately). Swisher recommends using a standard “U 1 R” lawn & garden battery.
  • Page 8 • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. • Check spark plug wire, oil, and fuel. • Check all electrical connections (See Schematics). • Make sure toggle switch is turned “ON” and the red tether is properly attached. •...
  • Page 9: General Troubleshooting

    ALTERNATIVE STOPPING METHOD • Bring vehicle to complete stop, shut off engine, and set parking brake. • Disengage blade engage lever (17611). • Manually shut toggle and key switches to their “OFF” positions. • Always remember to remove keys to avoid irresponsible usage. TRANSPORTING MOWER •...
  • Page 10: Mower Maintenance

    MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trailmower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season.
  • Page 11: Frame Assembly

    FRAME ASSEMBLY ITEM # QTY. PART NO. DESCRI PTION ITEM # QTY. PART NO. DESCRIPTION NB126 Pin - 1/8" X 1" Cott er 3664 Bar - Right Sway 3665 Bar - Left Sway T2PB Bushing - Plast ic 17600TC Weldment - T60 Frame NB178 Washer - 5/8 I D X 1 OD 10 GA NB149...
  • Page 12 CENTER BLADE DRIVER DETAIL I TEM # QTY. PART NO. DESCRIPTION 9057TK Housing - Bearing NB690 Bolt - Serrt d Flange 1/4-20 X 3/4 Gr 5 Bearing 9054 Shaft - Cent er 5.75" NB179 Washer - 3/4 ID X 1 1/4 OD 18 Ga B98W Washer - Flat 3/4 ID X 1 3/4 OD 6114...
  • Page 13 ITEM # . QTY . PART NO. DESCRIPTION MOWER DECK DETAIL See Motor Base Det ail See Safety Swit ch & Bracket Det ail See Outer Blade Driver Det ail See Center Blade Driver Detail See Grass Chut e & Spring Det ail See Engage Lever Det ail See Idler Detail See Deck Hanger Detail...
  • Page 14 MOTOR BASE DETAIL Slide plastic tube snug Against toggle switch. Item # 24 Item # 26 Battery shown is for representation only PARTS NOT SHOWN 18057 Harness - Wiring, Briggs (13-20 hp) Bat tery (BCI Group # : U1R) BCSR Cable - Battery (10"...
  • Page 15 Engage Lever Detail Height Adjust Handle Detail Safety Switch & Bracket Detail ITEM # QTY. PART # DESCRI PTI ON I TEM # QTY . PART # DESCRIPTION ITEM # QT Y. PART # DESCRIPTION 17733TK Mount - Swit ch Safety NB199 Bolt - 3/8-16 X 5 HCC GR5 ZP H7N1TK* Tube - Height Adjust...
  • Page 16: How To Order Repair Parts

    The model number for the engine will be found on the top of the blower fan housing. QBT14560A All mower parts listed herein may be ordered directly from Swisher or your nearest Swisher dealer. QBT18560A All engine parts may be ordered from the nearest dealer of the engine supplied with your mower Color cannot be guaranteed on service parts.
