OWNER'S
MANUAL
STARTING SERIAL #:
L111-002001
MODEL NO.
QBT2066
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Rev 11-005
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
PHONE 660-747-8183 FAX 660-747-8650
Manufacturing quality lawn care equipment since 1945
13318
66" FINISH CUT
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
Made In The
USA
Advertisement
Related Manuals for Swisher QBT2066
Summary of Contents for Swisher QBT2066
- Page 1 OWNER’S MANUAL STARTING SERIAL #: L111-002001 MODEL NO. QBT2066 66” FINISH CUT TRAILMOWER IMPORTANT Assembly Read and follow all Safety Precautions Operation and Instructions before operating this Service and Adjustment equipment. Rev 11-005 Repair Parts 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093...
- Page 2 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.
- Page 3 SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.
- Page 4 For model year 2006 the EECS on your mower includes the liquid fuel lines, fuel line connectors, and fuel line clamps. Where a warrantable condition exists, Swisher will repair at no cost to you.
- Page 5 SAFETY DECALS Replace decals immediately if damaged.Order by part number from Swisher OD11- No step Decal OD45- Warning Decal OD55- Triangle Danger Decal OD33- Speed Decal OD43- Flying Debris Decal OD29- Danger Decal...
- Page 6 REQUIRED ASSEMBLY FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut and washers from caster shaft. 2. Place one washer on the shaft of the caster/wheel sub-assembly. 3. Slide same shaft through the bearing/frame with wheel towards the ground. 4. Place the other washer on the shaft; it should be resting on the top bearing. 5.
- Page 7 STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. TrailMowers with electric start engines will need a battery (sold separately). Swisher recommends using a standard “U 1 R” lawn & garden battery.
- Page 8 • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. • Check spark plug wire, oil, and fuel. • Check all electrical connections (See Schematics). • Make sure toggle switch is turned “ON” and the red tether is properly attached. •...
- Page 9 ALTERNATIVE STOPPING METHOD • Bring vehicle to complete stop, shut off engine, and set parking brake. • Disengage blade engage lever (6008). • Manually shut toggle and key switches to their “OFF” positions. • Always remember to remove keys to avoid irresponsible usage. TRANSPORTING MOWER •...
- Page 10 MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trailmower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season.
- Page 11 Item # Description Part # FRAME DETAIL Tongue Hitch 661* Solid Stock Hitch 661A* Detail Bushing (for height adjustment assembly) 10579 Safety Hitch Pin Caster/Wheel Assembly 6774* See Detail 3/4 - 16 Nyloc Nut NB122 Caster Fork 665TC Washer NB195 Wheel Spacer 663L 5/8 - 11 2 Way Lock Nut...
- Page 12 MOWER DECK DETAIL BELT IDLER DETAIL Item # Description Part # Belt Cover 12523TK Grass Chute 9902TK Chute Bracket 6030TK Anti-Scalp Roller AS001 Deck 12520* Torsion Spring 166X34 Sway Bar Left 3665 Sway Bar Right 3664 Deck Idler 6055 3/8 - 16 X 1 1/4 Bolt NB618 Spacer 6040...
- Page 13 MOTOR BASE DETAIL Slide plastic tube snug against toggle switch. Item No. Description Part # Heat Shield 6052TK Throttle 686N Toggle Switch 685SP Control Console 10737* Ignition Switch 3623 Motorbase 12522* Belt Guide 6066 Belt Guide 6000 Top Idler Assembly 10735 IDLER DETAIL 5/16 - 18 Nyloc Nut...
- Page 14 ENGINE DETAIL* Item # Description Part # UPPER SPACER 689L 5-1/2'' ENGINE PULLY 1/4/ X 1'' KEY STOCK 9031 LOWER SPACER 689S 3/8 BELLEVILLE WASHER FLAT WASHER TR150W 3/8-24 X 1BOLT [BRIGGS ] NB452N 7/16-20 X 1 BLOT [TECUMSEH ] NB238N 5/16-18 X 1-3/4 BOLT NB515...
- Page 15 WIRING SCHEMATICS...
- Page 16 The model number for the engine will be found on the top of the blower fan housing. All mower parts listed herein may be ordered directly from Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the engine supplied with your mower Color cannot be guaranteed on service parts.
