OWNER'S
MANUAL
STARTING SERIAL #:
L117-045001
MODEL NO.
QBFC14560
QBFC14560-CA
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
1602 CORPORATE DRIVE, WARRENSBURG, MO 64093
Manufacturing quality lawn care equipment since 1945
18372 REV 17-045
60" FAST FINISH
TRAIL MOWER
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
PHONE 660-747-8183 FAX 660-747-8650
ade I The
USA
of US and Global Parts
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swisher QUADBOSS QBFC14560-CA
Summary of Contents for Swisher QUADBOSS QBFC14560-CA
- Page 1 Instructions Operation before operating this equipment. Service and Adjustment Repair Parts SWISHER ACQUISITION INC. ade I The 1602 CORPORATE DRIVE, WARRENSBURG, MO 64093 PHONE 660-747-8183 FAX 660-747-8650 Manufacturing quality lawn care equipment since 1945 of US and Global Parts...
-
Page 2: Limited Warranty
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. -
Page 4: Safety Decals
SAFETY DECALS Replace decals immediately if damaged. Order by part number from Swisher. OD11- No step Decal OD45- Warning Decal OD55- Triangle Danger Decal OD33- Speed Decal OD43- Flying Debris Decal OD29- Danger Decal... - Page 5 REQUIRED ASSEMBLY FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut and washers from caster shaft. 2. Place one washer (NB195) on the shaft of the caster/wheel subassembly. 3. Slide same shaft through the bearing/frame with wheel towards the ground. 4. Place the other washer (NB195) on the shaft; it should be resting on the top bearing. 5.
-
Page 6: Intended Use
STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. Trail Mowers with electric start engines will need a battery (sold separately). Swisher recommends using a standard “U 1 R” lawn & garden battery. -
Page 7: Starting To Mow
• Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. • Check spark plug wire, oil, and fuel. • Check all electrical connections (See Schematics). • Make sure toggle switch is turned “ON” and the red tether is properly attached. •... -
Page 8: General Troubleshooting
ALTERNATIVE STOPPING METHOD • Bring vehicle to complete stop, shut off engine, and set parking brake. • Disengage blade engage lever (18976). • Manually shut toggle and key switches to their “OFF” positions. • Always remember to remove keys to avoid irresponsible usage. TRANSPORTING MOWER •... -
Page 9: Mower Maintenance
MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trail Mower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season. -
Page 10: Frame Assembly
FRAME ASSEMBLY ITEM # QTY. PART NO. DESCRIPTION ITEM # QTY . PART NO. DESCRIPTION 3664 Bar - Right Sway NB126 Pin - 1/8" X 1" Cot ter 3665 Bar - Left Sway T2PB Bushing - Plast ic 17600* Weldment - T60 Frame NB178 Washer - 5/8 ID X 1 OD 10 GA F4157WK Wheel/Tire 5/8"... - Page 11 CENTER BLADE DRIVER DETAIL ITEM # QTY. PART # DESCRIPTION NB175 Nut - Jam 3/4-16 Grade 2 AS155 Washer - Belleville1.5 X .761 X .098 6114 Pulley - 5.50" 6065PM Spacer - 3/4 ID X 1-1/2 NB179 Washer - 3/4 ID X 1 1/4 OD 18 Ga Bearing NB690 Bolt - Serrt d Flange 1/4-20 X 3/4 Gr 5...
- Page 12 ITEM # QTY PART NO DESCRIPTION See Mot or Base Det ail See Safet y Swit ch Bracket Det ail MOWER DECK DETAIL See Out er Blade Driver Det ail See Cent er Blade Driver Det ail See Grass Chut e & Spring Det ail See Engage Lever Det ail See Idler Det ail T2PB...
- Page 13 MOTOR BASE DETAIL Slide plastic tube snug Item # 24 Against toggle switch. PARTS NOT SHOWN 18057 Harness - Wiring, Briggs (13-20 hp) BCSR Cable - Battery (10" Red) BCLB Cable - Battery (19 1/2"or 20" Black) Item # 26 Keys - For Key Switch (set of two) BCBT Boot - Rubber, Small, Battery Cable...
- Page 14 Engage Lever Detail Height Adjust Handle Detail Safety Switch & Bracket Detail ITEM # QTY. PART # DESCRIPTION ITEM # QTY. PART # DESCRIPTION ITEM # QTY . PART # DESCRIPTION 18390* Mount - Switch Safety NB155 Bolt - 1/2-13 X 5 HCC GR5 ZP H7N1TK** Tube - Height Adjust NB121...
- Page 15 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
-
Page 16: How To Order Repair Parts
All mower parts listed herein may be ordered directly from QBFC14560-CA Swisher or your nearest Swisher dealer. All engine parts may be ordered from the nearest dealer of the engine supplied with your mower Color cannot be guaranteed on service parts.
