GETTING STARTED GUIDE
NI PXIe-7975R
NI FlexRIO
FPGA Module for PXI Express
This document explains how to install your NI FlexRIO system, comprised of the
NI PXIe-7975R (NI 7975R) FlexRIO FPGA module and an NI FlexRIO adapter module.
For information about the device specifications, refer to the NI PXIe-7975R Specifications,
available at Start»All Programs»National Instruments»NI FlexRIO, and at
manuals.
For detailed information about the features and configuration options specific to the
NI FlexRIO FPGA module, refer to the NI FlexRIO Help, available at Start»All Programs»
National Instruments»NI FlexRIO, and at ni.com/manuals.
Contents
How to Use Your NI FlexRIO Documentation Set...................................................................2
Required Components...............................................................................................................3
Installing the Application Software and Driver........................................................................ 5
Installing the NI FlexRIO Devices............................................................................................6
Unpacking......................................................................................................................... 6
Preparing the Environment............................................................................................... 6
Installing the NI FlexRIO FPGA Module.........................................................................7
Device......................................................................................................................... 8
Installing the NI FlexRIO Adapter Module...................................................................... 9
Installing PXI EMC Filler Panels........................................................................................... 10
NI FlexRIO FPGA Module Signals........................................................................................ 10
Compliance and Certifications................................................................................................12
Safety.............................................................................................................................. 12
Electromagnetic Compatibility....................................................................................... 12
CE Compliance .............................................................................................................. 12
Online Product Certification........................................................................................... 13
Environmental Management........................................................................................... 13
Electromagnetic Compatibility Guidelines............................................................................. 13
Worldwide Support and Services............................................................................................ 14
ni.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexRIO PXIe-7975R and is the answer not in the manual?

Questions and answers

Summary of Contents for National Instruments FlexRIO PXIe-7975R

  • Page 1: Table Of Contents

    This document explains how to install your NI FlexRIO system, comprised of the NI PXIe-7975R (NI 7975R) FlexRIO FPGA module and an NI FlexRIO adapter module. For information about the device specifications, refer to the NI PXIe-7975R Specifications, available at Start»All Programs»National Instruments»NI FlexRIO, and at ni.com/ manuals.
  • Page 2: How To Use Your Ni Flexrio Documentation Set

    How to Use Your NI FlexRIO Documentation Set Figure 1. How to Use Your NI FlexRIO Documentation Set Getting Started Guide for your FPGA module INSTALL Hardware and Software Specifications document for your FPGA module Getting Started Guide CONNECT Signals for your adapter module and LearnAbout Specifications document...
  • Page 3: Required Components

    You can use the NI FlexRIO FPGA module without an adapter module for coprocessing or peer-to-peer streaming. The adapter module installation instructions in this document do not apply to these circumstances. The following figure shows the combined module. NI PXIe-7975R FPGA Module Getting Started Guide | © National Instruments | 3...
  • Page 4 Figure 2. Combining Your Adapter Module and FPGA Module NI FlexRIO NI FlexRIO NI FlexRIO Device Adapter Module FPGA Module • The following software packages: – LabVIEW – LabVIEW FPGA Module – NI FlexRIO Support Note The most recent version of NI FlexRIO Support is available at ni.com/downloads.
  • Page 5: Installing The Application Software And Driver

    Refer to the NI FlexRIO Adapter Module Support Readme on the NI FlexRIO Adapter Module Support installation media for system requirements and installation instructions. Documentation for NI FlexRIO Adapter Module Support is available at ni.com/manuals NI PXIe-7975R FPGA Module Getting Started Guide | © National Instruments | 5...
  • Page 6: Installing The Ni Flexrio Devices

    Start»All Programs»National Instruments»NI FlexRIO»NI FlexRIO Adapter Module Documentation. Related Information Required Components on page 3 NI FlexRIO FPGA Module Signals on page 10 Installing the NI FlexRIO FPGA Module on page 7 Installing the NI FlexRIO Devices Note You must install the software before installing the hardware.
  • Page 7: Installing The Ni Flexrio Fpga Module

    Express module edges into the module guides at the top and bottom of the chassis, and slide the module into the chassis until the module is fully inserted, as shown in the figure below. NI PXIe-7975R FPGA Module Getting Started Guide | © National Instruments | 7...
  • Page 8: Confirming That Measurement & Automation Explorer (Max) Recognizes The Device

    Confirming that Measurement & Automation Explorer (MAX) Recognizes the Device Use Measurement & Automation Explorer (MAX) to configure your National Instruments hardware. MAX informs other programs about which devices reside in the system and how they are configured. MAX is automatically installed with NI FlexRIO Support.
  • Page 9: Installing The Ni Flexrio Adapter Module

    Launch LabVIEW to begin configuring your NI FlexRIO system. Note MAX only recognizes FPGA modules that are in the chassis. Your adapter module will not appear in MAX. NI PXIe-7975R FPGA Module Getting Started Guide | © National Instruments | 9...
  • Page 10: Installing Pxi Emc Filler Panels

    Installing PXI EMC Filler Panels To ensure specified EMC performance, PXI EMC filler panels must be properly installed in your NI FlexRIO system. The PXI EMC filler panels (National Instruments part number 778700-01) must be purchased separately. Remove the captive screw covers.
  • Page 11 GPIO_57_n GPIO_67_n GPIO_57 GPIO_67 Note Pins S72 and S146 are shorted together on the NI 7975R. Related Information Installing the Application Software and Driver on page 5 NI PXIe-7975R FPGA Module Getting Started Guide | © National Instruments | 11...
  • Page 12: Compliance And Certifications

    Compliance and Certifications Safety This product is designed to meet the requirements of the following electrical equipment safety standards for measurement, control, and laboratory use: • IEC 61010-1, EN 61010-1 • UL 61010-1, CSA 61010-1 Note For UL and other safety certifications, refer to the product label or the Online Product Certification section.
  • Page 13: Online Product Certification

    Furthermore, any changes or modifications to the product not expressly approved by National Instruments could void your authority to operate it under your local regulatory rules. NI PXIe-7975R FPGA Module Getting Started Guide | © National Instruments | 13...
  • Page 14: Worldwide Support And Services

    Using the NI 7975R in a manner not described in this document may impair the protection the NI 7975R provides. Worldwide Support and Services The National Instruments website is your complete resource for technical support. At ni.com/ support, you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers.
  • Page 15 Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the file on your media, or the National Instruments Patent Notice at .
