- Page 1 Volume OPERATIONAL MANUAL MODEL: TYP-75 MAGNETIC DRILLING MACHINE by BLUEROCK ® Tools...
- Page 2 T Y P - 7 5 M A G D R I L L UNPACKING THE ITEM Caution: This machine is packed together with items that may be sharp, oily and overly heavy objects. Remove the machine from the packaging in a safe manner. Check to ensure all accessories are included with the item while unpacking.
-
Page 3: Table Of Contents
T Y P - 7 5 M A G D R I L L Table of Contents SAFETY PRE-OPERATIONAL SAFETY CHECKS OPERATIONAL SAFETY CHECKS SPECIFICATIONS INCLUDED ACCESSORIES ADDITIONAL AVAILABLE ACCESSORIES BLUEROCK ® T DDITIONAL ACCESSORIES FOR THIS MACHINE CAN BE FOUND IN OOLS ONLINE SHOP AT BLUEROCKTOOLS COM OR FROM YOUR LOCAL RETAILER OPERATIONS... -
Page 4: Safety
Chapter T Y P - 7 5 M A G D R I L L Safety DO NOT USE THIS MACHINE UNLESS YOU HAVE READ THE OPERATING INSTRUCTIONS! Safety glasses must be worn at all Long and loose hair must be times in work areas. - Page 5 T Y P - 7 5 M A G D R I L L Ø DO allow machine to reach operating speed before starting a hole. Ø DO unplug machine while changing or adjusting cutting bits so as not to accidentally turn machine on.
- Page 6 T Y P - 7 5 M A G D R I L L Ø DO NOT operate this machine on the same work surface where welding is being performed. This could result in severe damage to the machine or personal injury to the user. Ø...
-
Page 7: Specifications
T Y P - 7 5 M A G D R I L L Chapter Specifications ELECTRICAL DATA Voltage 120V, 60Hz Current 15.4 Amps Motor Size 1850W Power Connection US Standard 3 Prong Type B Plug MECHANICAL DATA Motor Reverse Cutter Range Annular Cutter: 7/16”... -
Page 8: Additional Available Accessories
T Y P - 7 5 M A G D R I L L Note UPON RECEIPT, CHECK CAREFULLY TO ENSURE THAT THE MACHINE IS IN GOOD CONDITION AND HAS ALL ACCESSORIES LISTED ABOVE. Additional Available Accessories Additional accessories for this machine can be found in BLUEROCK ® Tools online shop at www.bluerocktools.com or from your local retailer. -
Page 9: Operations
OPERATING THIS MACHINE! PURPOSE Ø The purpose of the TYP-75 is to drill through steel using annular cutters or standard twist drill bits (when using the optional drill chuck). Ø These drills are designed to magnetically adhere to a ferrous surface using their electromagnetic base. - Page 10 T Y P - 7 5 M A G D R I L L Ø This machine has one primary adjusting point for the travel between the magnetic base frame and the drill rail. The main way to increase or decrease the users ability to move the drill by hand is with this system.
-
Page 11: Transporting The Machine
T Y P - 7 5 M A G D R I L L TRANSPORTING THE MACHINE Ø When transporting the machine, always use the carrying handle. Ø Ensure the drilling head is at the lowest position. Ø DO NOT transport the machine with cutters or bits in the tool holder. Ø... - Page 12 T Y P - 7 5 M A G D R I L L § To remove the hose later, press in the plastic piece around the hose towards the tool holder while simultaneously pulling the plastic hose away from the tool holder. Make sure the oil bottle valve is in the off position.
-
Page 13: Installing Annular Cutters
T Y P - 7 5 M A G D R I L L Ø Make sure to keep the cutting material adequately lubricated. Ø Ease up on feed pressure as the cutter starts breaking through the backside of the material. - Page 14 T Y P - 7 5 M A G D R I L L Ø Insert the annular cutter into the ¾” adapter. Ø Align the two “flat” sides of the annular cutter with the flat sides of the adapter. CAUTION: Make certain the hex screw is seated into the flat side and not simply on the round side of the cutter shank.
-
Page 15: Troubleshooting
T Y P - 7 5 M A G D R I L L Chapter Troubleshooting Note SERVICING SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. DON’T FORGET TO UNPLUG POWER TO UNIT PRIOR TO SERVICE! PROBLEM SOLUTION Motor does not turn on. 1) Magnet not turned on. -
Page 16: General Maintenance
T Y P - 7 5 M A G D R I L L Chapter General Maintenance Ø Inspect electrical cords and electrical connections. Ø Keep machine clean and free of debris. Ø Check for misalignment, binding and breakage of all moving parts. If damaged, repair tool before use. -
Page 17: Parts List
T Y P - 7 5 M A G D R I L L Chapter Parts List Flexible cable Magnetic switch 53. Bearing 6000 M5×35 screw Switch Magnetic base 54. Gear Motor holder cap Fuse cap M5 screw nut 55. 5×5×35 key Drill holder plate Fuse M5×16 screw... -
Page 18: Breakdown View - Motor/Gearbox Close-Up
T Y P - 7 5 M A G D R I L L Breakdown View – Motor/Gearbox Close-Up... -
Page 19: Breakdown View - Frame/Electrical Close-Up
T Y P - 7 5 M A G D R I L L Breakdown View – Frame/Electrical Close-Up...
