Summary of Contents for Bluerock Tools TYP-28A
- Page 1 Volume OPERATIONAL MANUAL MODEL: TYP-28A MAGNETIC DRILLING MACHINE by BLUEROCK ® Tools...
- Page 2 T Y P - 2 8 A M A G D R I L L UNPACKING THE ITEM Caution: This machine is packed together with items that may be sharp, oily and overly heavy objects. Remove the machine from the packaging in a safe manner. Check to ensure all accessories are included with the item while unpacking.
- Page 3 T Y P - 2 8 A M A G D R I L L Table of Contents SAFETY PRE-OPERATIONAL SAFETY CHECKS OPERATIONAL SAFETY CHECKS SPECIFICATIONS INCLUDED ACCESSORIES ADDITIONAL AVAILABLE ACCESSORIES BLUEROCK ® T DDITIONAL ACCESSORIES FOR THIS MACHINE CAN BE FOUND IN OOLS ONLINE SHOP AT BLUEROCKTOOLS COM OR FROM YOUR LOCAL RETAILER OPERATIONS...
-
Page 4: Safety
Chapter T Y P - 2 8 A M A G D R I L L Safety DO NOT USE THIS MACHINE UNLESS YOU HAVE READ THE OPERATING INSTRUCTIONS! Safety glasses must be worn at all Long and loose hair must be times in work areas. - Page 5 T Y P - 2 8 A M A G D R I L L Ø DO allow machine to reach operating speed before starting a hole. Ø DO unplug machine while changing or adjusting cutting bits so as not to accidentally turn machine on.
- Page 6 T Y P - 2 8 A M A G D R I L L Ø DO NOT operate this machine on a lower voltage as it may result in the electromagnet being at a reduced power level and the machine could become unstable while cutting. This could also limit the motor life.
-
Page 7: Specifications
T Y P - 2 8 A M A G D R I L L Chapter Specifications ELECTRICAL DATA Voltage 120V, 60Hz Current 7.9 Amps Motor Size 950W Power Connection US Standard 3 Prong Type B Plug MECHANICAL DATA Cutter Range Annular Cutter: 7/16”... -
Page 8: Additional Available Accessories
T Y P - 2 8 A M A G D R I L L Note UPON RECEIPT, CHECK CAREFULLY TO ENSURE THAT THE MACHINE IS IN GOOD CONDITION AND HAS ALL ACCESSORIES LISTED ABOVE. Additional Available Accessories Additional accessories for this machine can be found in BLUEROCK ® Tools online shop at www.bluerocktools.com or from your local retailer. -
Page 9: Operations
THOROUGHLY READ THROUGH THE ENTIRE MANUAL BEFORE OPERATING THIS MACHINE! PURPOSE Ø The purpose of the TYP-28A is to drill through steel using annular cutters or ¾” Weldon shank type drill bits. Ø These drills are designed to magnetically adhere to a ferrous surface using their electromagnetic base. -
Page 10: Transporting The Machine
T Y P - 2 8 A M A G D R I L L 1) Gearbox 2) Feed Handle 3) ¾” Weldon Shank Tool Holder 4) Machine Carrying Handle 5) Drill Motor 6) Brush Holder 7) Motor Off Switch 8) Motor On Switch 9) Magnetic Base TRANSPORTING THE MACHINE... - Page 11 T Y P - 2 8 A M A G D R I L L Ø Ensure the work surface and bottom of magnet are free of debris, oil, etc. Ø Select and set up oiling method or cutting pastes. If drilling overhead or horizontal use cutting paste liberally applied to the cutting bit.
-
Page 12: Installing Annular Cutters
T Y P - 2 8 A M A G D R I L L NOTE: Do not force the hole. Let the machine do most of the work. Excessive physical effort should be avoided as it can cause damage to the machine or the user. - Page 13 T Y P - 2 8 A M A G D R I L L 1) Oil Bottle Input 2) ¾” Weldon Shank Tool Holder 3) Annular Cutter (not included) 4) ¾” Adapter Hex Set Screws (2 total)
-
Page 14: Troubleshooting
T Y P - 2 8 A M A G D R I L L Chapter Troubleshooting Note SERVICING SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. DON’T FORGET TO UNPLUG POWER TO UNIT PRIOR TO SERVICE! PROBLEM SOLUTION Motor does not turn on. 1) Check external power source (extension cord, breaker, etc). -
Page 15: General Maintenance
T Y P - 2 8 A M A G D R I L L Chapter General Maintenance Ø Inspect electrical cords and electrical connections. Ø Keep machine clean and free of debris. Ø Periodically check and lubricate the drilling spindle as necessary using molybdenum grease. Ø... -
Page 16: Parts List
T Y P - 2 8 A M A G D R I L L Chapter Parts List Catch spring Catch spring Axle cap Oil bottle Spring stop Gear stop Handle Spring M5x6 screw Flexible cable Catch spring Gear Cable protector Oil hold Bearing Cable hold... -
Page 17: Breakdown View
T Y P - 2 8 A M A G D R I L L Breakdown View...
