U-Line H-5200 Manual

H-5200
PORTABLE AIR
CONDITIONER
Exhaust Hose x 1
Window Slider Kit x 1
Remote Control x 1
NOTE: Check that all accessories are included in the package
and refer to installation instructions for usage.
WARNING! Read this section before attempting
to operate air conditioner. Unit must be upright
one hour prior to operating.
The power cord contains a current device that senses
damage to the cord. To test your power cord, do the
following:
1. Plug in the air conditioner.
2. The power cord will have two buttons on the plug
head. Press the TEST button. You will notice a click as
the RESET button pops out.
3. Press the RESET button. Again, you will notice a click
as the button engages. (See Figure 1)
4. The power cord is now supplying electricity to the unit.
PAGE 1 OF 30
1-800-295-5510
uline.com
ACCESSORIES INCLUDED
Unit/Exhaust Adapter A x 1
1/2" Screw x 4
Sash Lock x 1
SAFETY
Pour le français, consulter les pages 21-30.
Window/Exhaust Adapter B x 1
3/4" Screw x 2
Battery (For Remote Control) x 2
NOTE: Do not use this device to turn the unit
on or off. Always make sure the RESET button
is pushed in for correct operation. The power
cord must be replaced if it fails to reset when
either the TEST button is pushed or if it cannot
be reset. If power supply cord is damaged,
it cannot be repaired. It must be replaced.
Contact Uline Customer Service for assistance
at 1-800-295-5510.
Figure 1
Para Español, vea páginas 11-20.
Foam Seal x 3
1/2" Hex Head
Cap Screw x 2
0721 IH-5200
