Viakom CV-S200THC30SHT Quick Start Manual

Specification
Model CV-S200THC30SHT
Image Sensor 1/2.9" SONY 2.4MP CMOS Sensor
Resolution 1080P
Signal System PAL / NTSC
Minimum Illumination 0.001 Lux/F1.2
S/N Ratio More than 50dB
Synchronous System Internal
IR Distance 30 Meters (with Φ5 (12µ) x 36 PCS Infrared LED)
IR Power On Photodiode AUTO Control
AHD/CVI/CVBS/TVI
Video Output
Power/Current DC12V(+/-10%)/700mA
Lens 2.8-12mm Manual Zoom Lens
Weather Proof
Dimension (mm) Φ131 x 93(H)
Weight (g) 800
Operating Conditions
-10~+50
Accessories list
Name
Camera
User Guide
Switch the output signal by OSD button
Press "left" key after 5 seconds then release : CVBS
Press "right" key after 5 seconds then release : TVI
Press "up" key after 5 seconds then release : AHD
Press "down" key after 5 seconds then release : CVI
/
RH95% MAX
Number
1
1
CV-S200THC30SHT 4in1 Camera
Weatherproof IR Camera
Thank you for using our product.
Before providing power for the camera, please read
this manual carefully before use.
We adopt the latest technical of sensor and driver.
It owns the characters of high definition and stability,
strong anti-jamming, rich and real color. Fixing and
using this model are convenient too. It is very good
for you to apply to your CCTV system.
