Viakom KHS-122CZ40 User Manual

Safety Instruction

Thank you for purchasing this HD CCTV Camera. Please read these
instructions carefully for a thorough understanding of how the camera
operates.
1.Operating requirements
1.1 Before using the camera ,please read this manual carefully and keep it
safe for later use.
1.2 Installation should be proceed by professional service and follow
manufacturer's instructions, do not dismantle without authorization.
1.3 In order to prevent sensor ,do not expose lens to intense light source in
long time.
1.4 Do not touch sensor directly. Please cover the dustproof cover when the
camera is not being used.
1.5 Please use a dry soft cloth to clean the camera. If dirt is difficult to clean,
use detergent with water and wipe dry the camera.
1.6 Do not install camera under air conditioning's air gate ,or else lens blur
with condensation of moisture.
1.7 Please ensure that all electric power sources are turned off when not
open , installation ,clean, etc operation.
1.8 Please transporting , using and storing the camera in allowable
temperature and humidity.
1.9 If the camera was broken, for example power cord or plug
damaged ,splash liquid
raining ,wetting ,etc can't work situation ,please contact manufacturer or
maintenance center (modify and maintenance without permission ,you
must be responsible for the problems)
2.Statement
2.1 All photos here are for reference only .Specifications are subject to
physical product.
2.2 This manual is subject to change without further notice.
2.3 Please contact with customer service for the newest procedures and
supplementary specification.
2.4 This manual list several model numbers for reference , please user
according actual product to operating.
2.5 We will do the best to keep this manual complete and accurate, but some
data may has deviation. If any doubt or dispute ,company retain the final
right of the product.

Feature

■ ACCE ( Adaptive Color & Contrast Enhancement)
■ NTSC/PAL Selectable
■ DC Lens/ RS485

Specification

Imaging Sensor
Scanning System
S/N Ratio
Video Output Mode
HD-SDI /1.0 Vp-p (75Ω，Composite)
Video Output Level
Lens
Min. Illumination
IR Distance
OSD
Electronic Shutter
AGC
2D/3D-NR
Digital Zoom/PIP
Freeze/Mirror/D-Zoom/NEG.IMAGE
D-DFFECT
Voltage/Current
Operating temperature
Dimension (mm)
Weight (g)
or foreign matter fall
1/3" 2.1Megapixel CMOS
Progressive Scan
More than 50dB (AGC Off)
1080P(1920 X 1080)
2.8-12mm Manual Zoom Lens
1.0Lux(Color),0.5Lux(BW)
40M(with ￠5X42PCS LED)
Built-in
Auto/FLK/1/25,30sec ~ 1/50000sec
Low/Middle/High
2DNR/3DNR/SMART NR
On/Off(x2 ~ x64)
DC12V+10% / 800mA
-10°~ +50°C
290(W)X110(H)X90(D)mm
1600

INTRODUCTION:

This camera which has 2.1Mega Pixels is specially designed for security
monitoring. It applies the latest 2.1Mega Pixes progressive scan CMOS. It is a
heavyweight new-designed HD camera which applied DC 12V and support user
into camera,
customize the output parameter settings.

Packing List

NO.
1
2
3
1
Wire ports

Application method

3
HD CCTV CAMERA

USER MANUAL

Name Model
Camera KHS-122CZ40
Power line
—
Warranty
—
Card
Number
1
1
1
2
4
