- Page 1 VDA110S-IP H.264 IP PTZ CAMERA IP PTZ Camera Network Manual Ver. 1.1 H.264 IP PTZ Camera Network Manual...
-
Page 2: Table Of Contents
CONTENTS Introduction About This Manual Features System Connections 2. System Operation RemoteVideo Monitoring Initialization of IP Address 3. True Manger True Manager Software Server Registration and Removal Server Connection Management Server Status Monitoring Network and System Diagnostics F/W Upgrade Remove Configuration and Video Monitoring 4. -
Page 3: Introduction
INTRODUCTION About This Manual This User Manual provides information on network part of IP Camera, VDA110S. In this guide, information on operation and configuration of VDA110S is explained as well as how to shoot troubles when problems arise. Features VDA110S is a video and audio surveillance transmission system based on IP network through LAN, ADSL/VDSL, and Wireless LAN. -
Page 4: About This Manual
INTRODUCTION System Connections VDA110S systems can be connected in either 1-to-1 fashion where a server is connected a PC client or a decoder system or 1-to-multiple fashion where a server can be simultaneously connected to many PC and many decoder systems. - Page 5 INTRODUCTION Multicast Mode Within the network that supports multicasting, a large number of decoders can be used to receive video effectively from a VDA110S using a single streaming of video and audio. Relaying Site Decoder Decoder Remote Center #1 Remote Center #2 VDA110S In this arrangement, video and audio can be retransmitted from a center to another center.
-
Page 6: System Operation
SYSTEM OPERATION ● Part Names and Function ◆ Cable Configuration 12VDC Composite out ALARM INPUT Ethernet 6/41 H.264 IP Camera Network Manual... -
Page 7: Remotevideo Monitoring
SYSTEM OPERATION Remote Video Monitoring There are two ways to view video between the site and center system. In order for a proper operation, an IP address must be set accordingly and please refer to True Manager in Chapter 3 or Remote Setting in Chapter 4 for a further details. -
Page 8: Initialization Of Ip Address
SYSTEM OPERATION Initialization of IP Address If a system IP address is lost, the system can be reset to the system default IP address using the reset button in the back side of the system. ① While system is in operation, press the reset button for more than 5 seconds. ②... -
Page 9: True Manager Software
USING TRUEMANAGER True Manager Software True Manager is a program used for basic configuration, diagnostics and F/W upgrade of VDA110S. True Manager provides the following features. Finding servers on the LAN and assigning IP address Monitoring server status: encoding/decoding etc. ... - Page 10 USING TRUEMANAGER If the server is registered on DDNS server, domain name can be used instead of IP address. When the IP address of the server is forgotten, it is possible to find the IP address of the server with IP Discovery function. (Please refer to IP Discovery section).
- Page 11 USING TRUEMANAGER IP Discovery With IP Discovery function, all servers on the same LAN where the PC executing True Manager is located can be found. Furthermore, it is possible to change IP address of a server easily. IP Discovery dialog is invoked by pressing IP Discovery button on Add Server dialog, and it shows all VDA110S on the same LAN.
-
Page 12: Server Connection Management
USING TRUEMANAGER Server Connection Management Server connection If the check box on the first column in Servers (or Channels/Peripheral) tab, True Manager tries to connect to the server. If the server is running and the network where the server is in is normal, it will be connected immediately and State will be changed to Connected. -
Page 13: Server Status Monitoring
USING TRUEMANAGER USING TRUEMANAGER Server Status Monitoring Servers tab – General information Servers tab shows general information on a connected server: MAC address, product model, system mode(Type) F/W version and startup time. This information comes only for connected servers. ... -
Page 14: Network And System Diagnostics
USING TRUEMANAGER Network and System Diagnostics True Manager provides various diagnostic features. Connection between two VDA110S, or between VDA110S and CMS(Central Monitoring System) is established. Video, audio or serial data are not delivered as configured. Video and/or audio outputs don‟t come on output port. ... - Page 15 USING TRUEMANAGER Network test Network Test dialog is invoked by selecting Network Test on Tools menu. Network test can be used for measuring effective bandwidth and/or packet loss rate between a server and PC running True Manager by generating test traffic of constant bitrate. This feature is useful for identifying the reason why video quality comes poorer than expected.
- Page 16 USING TRUEMANAGER System Check System Check tests if H/W components are fine and board ID and MAC address are displayed. Video Out Check / Display Color Bar It displays color bar on video output port. This function works for Decoder or Duplex mode, and is useful for checking if video output port or external display device is normal.
-
Page 17: F/W Upgrade
USING TRUEMANAGER F/W Upgrade When Update is selected on Tools menu, the dialog for F/W upgrade comes. ① Select a server to upgrade (check the check box in Sel column). More than one server can be upgraded simultaneously. ② Select an upgrade file. ③... -
Page 18: Remote Configuration
REMOTE CONFIGURATION Using Internet Explorer The server can be configured using web browser. Type IP address in the address input area of Internet Explorer, then a live viewing screen will be displayed. Press Setup button located in the upper right area of the monitoring screen, then the setup page for server setup will be displayed. -
Page 19: Use Osd(On Screen Display)
REMOTE CONFIGURATION Use OSD(On Screen Display) MENU ON CAM NAME,LENS,EXPOSURE,DAY/NIGHT.WDR/BLC/ECLPS WHITE BALANCE,3D-DNR,EFFECTS,SPECIAL, Please, refer to the camera part of VDA110S user manual For further configuration. Drection key .Left /Right/Top/Bottom button. Digital Zoom button 19/41 H.264 IP Camera Network Manual... -
Page 20: System Configuration
REMOTE CONFIGURATION System Configuration Video Standard Select NTSC or PAL System ID Alphanumeric System ID to be transferred to remote software Language Language to be used for web-based configuration(English, Japanese and Korean) Firmware version Current firmware version ... - Page 21 Time Zone Select time zone of where the system is installed. Depending on the time zone, Daylight Saving Time will work automatically Automatically Synchronize system time with an NTP server using NTP(network time protocol). Name of the NTP server should be registered on NTP server Name. synchronize with NTP server ...
-
Page 22: Video Configuration
REMOTE CONFIGURATION Video Configuration 22/41 H.264 IP Camera Network Manual... - Page 23 REMOTE CONFIGURATION Encoding Mode There are two encoding modes, Field Encoding and Frame Encoding. Since field encoding shows better quality of video, it is recommended to use field encoding mode as long as the decoder in the client can decode field encoded stream. In order to support clients which are able to decode frame encoded stream only, encoding has been made configurable.
- Page 24 REMOTE CONFIGURATION Sensitivity A condition to trigger an event with motion detection. The value determines the sensitivity of the motion detection within a block: the smaller, the more sensitive Brightness Controls input video brightness by selecting values between 0 and 100. ...
-
Page 25: Audio Configuration
REMOTE CONFIGURATION Audio Configuration Mode Select audio operation mode Mode Action No operation Tx-Only Transmit only Rx-Only Receive only Tx & Rx Transmit and Receive Input Gain Set audio input gain 25/41 H.264 IP Camera Network Manual... -
Page 26: Network Configuration
REMOTE CONFIGURATION Network Configuration 26/41 H.264 IP Camera Network Manual... - Page 27 REMOTE CONFIGURATION IP Mode Three IP modes are supported. Depending on the selected mode, further configuration items come as follows. IP Mode Selection Description Fixed IP Local IP Fixed IP address Local Gateway Gateway IP address Local Subnet Subnet mask DHCP ☞...
- Page 28 REMOTE CONFIGURATION Flow Control When several clients connect to a server, bandwidths of networks clients may differ and some clients may not receive encoded stream fully. To handle such situation, three flow Mode control modes which can be chosen according to users‟ preference are provided Mode Description The bitrate is automatically adjusted to a client with smallest...
-
Page 29: Serial Port Configuration
REMOTE CONFIGURATION REMOTE CONFIGURATION Serial Port Configuration RS-485 serial port configurations must be same as configurations of connected analog PTZ camera. Default value of PTZ type, Pelco-D must be the same as protocol and ID of the analog PTZ camera ... -
Page 30: Event Configuration
Sensor Type There is one sensor input port on VDA110S. The sensor port can be configured to the following. Function Operation Not used The port is normally open and activated when NO (Normally Open) closed. The port is normally closed and activated when NC (Normally Closed) opened. - Page 31 REMOTE CONFIGURATION REMOTE CONFIGURATION When a decoder system instead of a PC client is connected to a VDA110S, one system becomes a Local system and the other becomes a Remote system (Generally a system which is being used by the user is called as Local system). Then, actions for events can be configured for events from remote system as well as from local system.
- Page 32 . The following table lists the possible actions for events. Action Description Sensor In One sensor in port Alarm out Alarm (relay) port will be triggered E-mail will be sent to the specified address. AVI file can E-mail be attached AVI file will be uploaded to a specified FTP server Preset It is available for PTZ cameras...
- Page 33 REMOTE CONFIGURATION REMOTE CONFIGURATION event action Server Address: Enter an address of an FTP server to receive video files Port: Specify a port for FTP operation (Port 21 is the default port in FTP operation. If a different port is configured in the FTP server, this port needs to be changed accordingly.).
-
Page 34: Preset Configuration
Preset Configuration Preset Configuration Preset Name Move PTZ Camera to normal view Save Press Set Button Set the PTZ Presets by following the next steps. ① Move cameras to desired view using PTZ control buttons. ② Enter Preset name. -
Page 35: Record Configuration
REMOTE CONFIGURATION Record Configuration Disk (USB, SD Card etc) Recording Disk Recording is not supported in VDA110S 35/41 H.264 IP Camera Network Manual... - Page 36 REMOTE CONFIGURATION General Off Record Recording function will not be used when “Off” is selected. Use Disk Use record: To use disk for recording, select “Use Disk” Record File Format: Select Record file format between AVI or TCS (for CMS) ...
- Page 37 REMOTE CONFIGURATION Use FTP While enabling FTP recording, “FTP upload by event” function is not available automatically This feature is to record video data to specified folder of FTP server using standard FTP protocol. The type of recorded file is ES stream of the H.264 video. The file name shows the date and time : “Date_Begin Time_End Time.es”...
- Page 38 REMOTE CONFIGURATION When one of its multiple clients system is disconnected, this doesn‟t happen. • Event Type: Records when an event configured in Event Type setting happens. Checking the status of recording Recording status can be shown on the main view page. ...
-
Page 39: User Configuration
REMOTE CONFIGURATION User Configuration User can be registered and authority level of a user can be specified. User configuration is allowed only to admin user. MAX. 16 users can be registered and each user can have one of four authorities. Authority Level Allowed Operations Remarks... - Page 40 REMOTE CONFIGURATION Modify Privilege Level Pressing Modify Privilege button after selecting a user shows a page for changing the authority. It is not allowed to change the authority level of admin user. Login Policy Skip Login is provided for convenient access to the server when authentication is not required. When Skip Login is set to Enable, login step is skipped.
-
Page 41: Specifications
SPECIFICATIONS Specifications Network Interface Ethernet 10/100 Base-T(RJ45) Network TCP/IP,UDP, Multicast, DHCP, SMTP, HTTP, SNMP Network Protocol RTSP, RTP Standard H.264 Data Rate 32Kbps ~ 4Mbps NTSC : 720480, 720240, 352480, 352240, 176x120 Resolution Video : 720576, 720288, 352576, 352288, 176x144 Max Frame Rate NTSC : Max.
