FMI C42MW-LS Owner's Operation And Installation Manual

Wood burning fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WOOD BURNING FIREPLACE
OWNER'S OPERATION AND
INSTALLATION MANUAL
PFS
®
C
US
ICC-ES # ESR-2542
MODEL C42MW-LS
SAVE THIS BOOK
This book is valuable. In addition to instructing you
f i r e - p a r t s . c o m
on how to install and maintain your appliance, it also
contains information that will enable you to obtain re-
placement parts or accessory items when needed. Keep
it with your other important papers.
This fireplace is approved for use as a wood burning fire-
place or for use with a vented gas log approved to ANS
Z21.60 or Z21.84 standards or for use with a vent-free gas
log heater approved to ANS Z21.11.2 standard. A hood must
be installed when using a vent-free log heater (see , page
18).
This wood burning fireplace complies with UL127-
CAN/ULS-S610-M87 standard as a FACTORY BUILT
APPLIANCE.
FOR CANADA: The authority having jurisdiction (such
as the municipal building department, fire department,
etc.) should be contacted before installation to deter-
mine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.fmiproducts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C42MW-LS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FMI C42MW-LS

Summary of Contents for FMI C42MW-LS

  • Page 1 OWNER’S OPERATION AND INSTALLATION MANUAL ® ICC-ES # ESR-2542 MODEL C42MW-LS SAVE THIS BOOK This book is valuable. In addition to instructing you f i r e - p a r t s . c o m on how to install and maintain your appliance, it also contains information that will enable you to obtain re- placement parts or accessory items when needed.

  • Page 2: Table Of Contents

    - p a r t s . c o m appliance should be located • This FMI PRODUCTS, LLC fireplace and out of traffic and away from its components are safe when installed furniture and draperies.

  • Page 3: Specifications

    SPECIFICATIONS 1" AIRSPACE TO COMBUSTIBLE MATERIAL GAS LINE RIGHT SIDE 0" TO KNOCK OUTS TOP SPACERS NO COMBUSTIBLE MATERIAL ON FACE 8.25" 7" COMBUSTIBLE WALL BOARD 3/4" AIR SPACE GAS LINE BACK AIR KIT KNOCK OUTS KNOCK OUT SIDES LEFT SIDE NOT LESS THAN 14"...

  • Page 4: Fireplace Installation

    FIREPLACE INSTALLATION SELECTING LOCATION 3. Set fireplace directly in front of this open- ing and slide unit back until nailing flanges To determine safest and most efficient location touch side framing. for fireplace, you must take into consideration 4. Check level of fireplace and shim with the following guidelines: sheet metal if necessary.
  • Page 5 FIREPLACE INSTALLATION Continued HEARTH EXTENSION Seal Gap Fireplace Front A hearth extension projecting a minimum of 20" in front of and a minimum of 12" beyond each side of fireplace opening is required to Ember Protector protect combustible floor construction in front of fireplace.
  • Page 6 FMI PRODUCTS, LLC voids warranty. Fan within 12" of fireplace opening (and within 9" is operated by pressing rocker switch (see of top louver opening).

  • Page 7: Venting Installation

    Mesh & Slip "* CHIMNEY PIPE Section FMI PRODUCTS, LLC chimney system * The lineal gain for the terminations is consists of 12", 18", 24", 36" and 48" snap- measured to the flue gas outlet height. lock, double-wall pipe segments, planned for maximum adaptability to individual site requirements.
  • Page 8 VENTING INSTALLATION Continued ASSEMBLY AND INSTALLATION OF installing double wall snap-lock chimney to- gether, it is important to assure joint between DOUBLE WALL CHIMNEY SYSTEM chimney sections is locked. Check by pulling Each double wall chimney section consists chimney upward after locking. Chimney will of a galvanized outer pipe, a stainless steel not come apart if properly locked.
  • Page 9 VENTING INSTALLATION Continued See Detail A Ceiling Support Pipe 12S-8DM 2" Min. See Detail B Straps Straps Straps Straps Detail A Detail B Return Elbow Angle Firestop Figure 10 - Ceiling Support Pipe 12S-8DM OFFSET RISE CHIMNEY LENGTH 48" 36" 24" 18" 12" f i r e - p a r t s .
  • Page 10 VENTING INSTALLATION Continued FIRESTOP SPACERS (FS-8DM) 4. Remove shingles around opening mea- sured. Cut out this section. Firestop spacers are required at each point 5. Add next sections of pipe until end where chimney penetrates a floor space. penetrates roof line. Check to see that Their purpose is to establish and maintain proper clearances are maintained.
  • Page 11 VENTING INSTALLATION Continued Overlap Terminations with 16" slip pipe sections are Storm Collar Shingles Top available. RTT-8DM and RTTL-8DM are Flashing and Sides Only approved for flashing installations. When Cone needed, these adjustable terminations may Nail Only be used in combination with pipe assembly Outer to achieve correct chimney height.
  • Page 12 VENTING INSTALLATION Continued 10 FOOT RULE FINISHING FIREPLACE All flue gas outlet chimney terminations must Combustible materials, such as wallboard, extend a minimum of 3 feet in height above gypsum board, sheet rock, drywall, plywood, highest point where it passes through roof and etc., may make direct contact with sides and must be at least 2 feet above highest point of top around fireplace face.

  • Page 13: Optional Gas Line Installation

    OPTIONAL GAS LINE INSTALLATION Gas line hook up should be done by your Note: A FMI PRODUCTS, LLC hood must be supplier or a qualified service person. installed when using an unvented gas log set (see Accessories on page 18).

  • Page 14: Operation And Maintenance

    OPTIONAL GAS LINE INSTALLATION Continued WARNING: If the fireplace WARNING: When using has been used for wood burn- a decorative vented gas log, ing, firebox and chimney must damper must be removed or be cleaned of soot, creosote and permanently locked in fully open ashes be a qualified chimney position and glass doors must cleaner.

  • Page 15: Technical Service

    You may have further questions about installation, operation, or troubleshooting. If so, contact FMI PRODUCTS, LLC at 1-866-328-4537. When calling please have your model and serial numbers of your heater ready. You can also visit our web site at www.fmiproducts.com.

  • Page 16: Parts

    PARTS WOOD BURNING FIREPLACE MODEL C42MW-LS f i r e - p a r t s . c o m www.fmiproducts.com 126134-01A...
  • Page 17 PARTS WOOD BURNING FIREPLACE MODEL C42MW-LS This list contains replaceable parts used in your fireplace. When ordering parts, see Replace- ment Parts on page 15 of this manual. NO. PART NO. DESCRIPTION QTY. Insulation Pan Air Separator Firebox Top 108302-01...

  • Page 18: Accessories

    PARTS Continued EMBER PROTECTOR 20093 STANDARD BRICK LINER Left - 106971-01 Right - 106970-01 Rear - 108310-01 Bottom Rear 108312-01 Bottom Front 108311-01 ACCESSORIES DOUBLE WALL PIPE f i r e - p a r t s . c o m 12-8DM 18-8DM 24-8DM...
  • Page 19 ACCESSORIES Continued FIRESTOP SPACER FS-8DM OUTSIDE AIR KIT FOR SIDE WALL INSTALLATION - AK4 FAN KIT - BK3 OUTSIDE AIR KIT FOR FLOOR INSTALLATION - AK4F f i r e - p a r t s . c o m ROUND TOP TERMINATIONS RT-8DM, RTL-8DM ROUND TOP TERMINATIONS WITH...
  • Page 20 f i r e - p a r t s . c o m 2701 S. Harbor Blvd. Santa Ana, CA 92704 126134-01 1-866-328-4537 Rev. A www.fmiproducts.com 01/12...
