- Page 1 ’ ’ Revision 1.0 Jan 2008...
-
Page 2: Information To User
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 3 CBV704EW Series Cable Modem User’s Manual Warranty Items sold by manufacturer/distributor/agent, hereinafter called "Seller", are warranted only as follows: Except as noted below Seller will correct, either by repair or replacement at its option, any defect of material or workmanship...
-
Page 4: Table Of Contents
Table of Contents FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT ......................II ....................NFORMATION TO INTRODUCTION....................1 ........................1 EATURES .....................1 YSTEM EQUIREMENTS ..................2 NPACKING AND NSPECTION ....................2 AFETY RECAUTIONS HARDWARE OVERVIEW................3 ...................3 RONT ANEL AND ETHERNET INSTALLATION................6 USB DRIVER INSTALLATION ...............7 XP ......................7 INDOWS 2003 ......................9 INDOWS ......................11... -
Page 5: Introduction
CBV704EW-to-CBV704EW. And with the integration of 4 ports switch and IEEE 802.11g wireless functionality, the CBV704EW series could also be used as a Wireless Cable Modem Residential Gateway in your home or small office. The ability to route data information into your broadband network could help you easily extend your local network via wire or wireless. -
Page 6: Unpacking And Inspection
CBV704EW Series Cable Modem User’s Manual Unpacking and Inspection Included in the kit is the following: 1 x EMTA CBV704EW 1 x Quick Installation Guide 1 x RJ-45 CAT 5 Cable 1 x 15V/1.0A Power Supply Adaptor 1 x CD-ROM containing USB Driver & User’s Manual... -
Page 7: Hardware Overview
CBV704EW Series Cable Modem User’s Manual Hardware Overview Front Panel and LEDs There are fourteen Light-Emitting-Diodes (LEDs) located on the front panel top provide status information to the user. NAME COLOR MODE STATUS Connected with power Power Green Power failure or disconnect... - Page 8 CBV704EW Series Cable Modem User’s Manual New voice message or in calling Blinking Line 2 is registered in the network TEL2 Green Line 2 is not registered in the network Blinking No phone call Wifi Green Connecting Blinking WPS Activating...
- Page 9 CBV704EW Series Cable Modem User’s Manual Step 4: Connect the AC Adapter to the cable modem by inserting the barrel- shaped connector into the mating power connector on the back of the cable modem. Exercise carefully to ensure the connectors are properly aligned prior to insertion and ensure the two connectors engage completely.
-
Page 10: Ethernet Installation
CBV704EW Series Cable Modem User’s Manual Ethernet Installation The LAN port you are using is auto-negotiating 10/100Mbps (Switch) Ethernet Interface. You can use the Ethernet port to connect to the Internet with an Ethernet network device such as NIC/Hub/Switch through RJ45. -
Page 11: Usb Driver Installation
CBV704EW Series Cable Modem User’s Manual USB Driver Installation Using the USB port to connect to the Internet allows you to install the cable modem more quickly and easily than connecting to the Internet using the Ethernet port, since you do not need to install a network interface card (NIC). - Page 12 CBV704EW Series Cable Modem User’s Manual Windows will locate the driver automatically. Please click Continue Anyway to continue the installation process. Windows shall find the location of USB driver and complete the installation. Click Finish.
-
Page 13: Windows 2003
CBV704EW Series Cable Modem User’s Manual Windows 2003 Connect USB cable from PC to cable modem. Connect RF cable and power on Cable Modem. Wait until it register, it will take about 40 seconds to 4 minutes depends on network traffic. Cable Modem may reboot if you previously connect it through Ethernet port. - Page 14 CBV704EW Series Cable Modem User’s Manual Windows will locate the driver automatically. Please click Continue Anyway to continue the installation process. Windows shall find the location of USB driver and complete the installation. Click Finish.
-
Page 15: Windows Vista
CBV704EW Series Cable Modem User’s Manual Windows Vista Connect USB cable from PC to cable modem. Connect RF cable and power on Cable Modem. Wait until it register, it will take about 40 seconds to 4 minutes depends on network traffic. Cable Modem may reboot if you previously connect it through Ethernet port. - Page 16 CBV704EW Series Cable Modem User’s Manual During the driver installation, your system may pop-up a dialogue as below window, just click “Install this driver software anyway”. During the driver installation, your system may pop-up a dialogue as below window, just click “Install this driver software anyway”.
-
Page 17: Web Management
CBV704EW Series Cable Modem User’s Manual Web Management For easy-changing the default setting or quick-checking diagnostics for troubleshooting, a Web-based GUI is built-in for your access. Enter Modem's IP address Use the following procedures to login to your CBV704EW. Open your web browser. -
Page 18: Status
CBV704EW Series Cable Modem User’s Manual Status The Status page shows hardware and software information about the CBV704EW that may be useful to your cable service provider. 5.1.1 Software Status The Software page shows how long the CBV704EW has operated since last being powered up, and some key information the CBV704EW received during the initialization process with your cable service provider. -
Page 19: Dhcp
CBV704EW Series Cable Modem User’s Manual 5.1.2 DHCP The DHCP page allows you to activate/deactivate the DHCP server function of the CBV704EW, and, if the DHCP server is activated, to see DHCP leases it has provided. With this function activated, your cable service provider’s DHCP server provides one IP address for the CBV704EW, and the CBV704EW’s DHCP... -
Page 20: Options
CBV704EW Series Cable Modem User’s Manual 5.1.3 Options The Options page allows you to enable/disable some advanced features supported by CBV704EW. Check the option you want to use and click Apply button to enable the function(s). WAN Blocking: To prevent others on the WAN side from being able to ping your CBV704EW. -
Page 21: Mac Filtering
CBV704EW Series Cable Modem User’s Manual These PCs can still communicate with each other on your LAN, but packets they originate to WAN addresses are blocked by the CBV704EW. To enable IP Filtering feature of CBV704EW, check the Enable box and click Apply button. -
Page 22: Forwarding
CBV704EW Series Cable Modem User’s Manual example, you could block access to worldwide web browsing (HTTP port 80) but still allow email service (SMTP port 25 and POP3 port 110). To enable port filtering, enter the Start port and End port for each range. -
Page 23: Port Triggers
CBV704EW Series Cable Modem User’s Manual 5.1.8 Port Triggers The Port Triggers page allows you to configure dynamic triggers to specific devices on the LAN. This allows for special applications that require specific port numbers with bi-directional traffic to function properly. Applications such as video conferencing, voice, gaming, and some messenging program features may require these special settings. -
Page 24: Firewall
CBV704EW Series Cable Modem User’s Manual Firewall The CBV704EW provides built-in firewall functions, enabling you to protect the system against denial of service (DoS) attacks and other unwelcome or malicious accesses to your LAN. 5.1.10 Local Log The Local Log page allows you to configure the firewall event log reported via email alert, and these attack records are also visible in the table on the bottom of this page. -
Page 25: Parental Control
CBV704EW Series Cable Modem User’s Manual Parental Control 5.6.1 User Setup This page allows configuration of users. “White List Only” feature limits the user to visit only the sites, specified in the Allowed Domain List of his/her content rule. 5.6.2 Basic Setup This page allows basic selections of rules which block certain Internet content and certain Web sites. - Page 26 CBV704EW Series Cable Modem User’s Manual 5.6.3 Time of Day Access Policy This page allows configuration of time access policies to block all internet traffic to and from specific network devices based on time of day setting. 5.6.4 Event Log...
-
Page 27: Wireless
CBV704EW Series Cable Modem User’s Manual Wireless 5.1.11 Basic The Wireless Connection Status page allows configuration of the Access Point parameters including the SSID and channel number. 5.1.12 Security This page allows configuration of the WEP keys and/or passphrase. -
Page 28: Access Control
CBV704EW Series Cable Modem User’s Manual 5.1.13 Access Control This page allows configuration of the Access Control to the AP as well as on the connected clients. 5.1.14 Advanced This page allows configuration of data rates and WiFi thresholds. -
Page 29: Bridging
CBV704EW Series Cable Modem User’s Manual 5.1.15 Bridging This page allows configuration of WDS features. 5.1.16 WMM This page allows configuration of the Wi-Fi Multimedia QoS. 5.1.17 Guest Network This page allows configuration of a guest network.. -
Page 30: Mta
CBV704EW Series Cable Modem User’s Manual Section MTA has 5 sub-items, which indicate the status of MTA. These information can help you to understand the parameters of MTA operation. 5.1.18 Status This page displays initialization status of the MTA. -
Page 31: Appendix: Cable Modem Specification
CBV704EW Series Cable Modem User’s Manual Appendix: Cable Modem Specification Table 1. RF Downstream Specification (DOCSIS) Parameter Value Notes Frequency range 88 MHz to 860 MHz +/- 30 kHz Demodulation 64QAM. 256QAM Input power range -15 dBmV to +15 dBmV... - Page 32 CBV704EW Series Cable Modem User’s Manual Table 4. RF Upstream Specification (for EuroDOCSIS system) Parameter Value Frequency Range 5 MHz to 65 MHz Modulation QPSK, 8QAM, 16QAM, 32QAM, 64QAM, 128QAM (TCM only) Symbol Rate TDMA: 160K, 320K, 640K, 1280K, 2560K,...
- Page 33 CBV704EW Series Cable Modem User’s Manual Table 8. RF Specification Parameter Value Frequency Band 2.412 – 2.462GHz(2.4GHz ISM Band) Number of Channels 11 Channels. Modulation DBPSK,DQPSK,CCK DSSS for 802.11b & g; DPSK,QPSK,16QAM OFDM for 802.11g Supported Rates 1,2,5.5,11 Mbps for 802.11b;6,9,12,18,24,36,48,54 Mbps for...
